- Page 1 Sauter GmbH Ziegelei 1 Phone : +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 e-mail: info@kern-sohn.com Internet: www.sauter.eu Instruction manual motorized test bench SAUTER TVM-N Version 2.0 01/2020 PROFESSIONAL MEASURING TVM-N-BA-e-2020...
-
Page 2: Table Of Contents
V. 2.0 01/2020 Instruction manual motorized test bench Congratulations on the purchase of the SAUTER TVM-N test bench. We hope you enjoy your quality measurement system with its wide range of functions and high reproducibility. If operated correctly, this high-quality product will give you many years of use. -
Page 3: Introduction
Various force measuring devices can be mounted on the test stand for the measurements. SAUTER offers optional software and accessories to make the measuring system more versatile in use. Please contact SAUTER or the SAUTER supplier or visit our website www.sauter.eu. -
Page 4: Possible Applications
5 Possible applications The TVM-N test stand has been designed to accommodate most SAUTER force measuring devices without any great difficulty. It has a wide range of applications and can be operated manually. It can also perform individual functions independently. -
Page 5: Technical Data
Speed accuracy 1-100 mm/min ±2 mm/min; > 100 mm/min ±10% Maximum travel 200mm distance Maximum number 1000 of cycles Nominal voltage 220V 50/60Hz Rated current 1,5A Backup Operating 20±10°C temperature Storage and -5°C~40°C transport temp. Relative air 15%~80% humidity TVM-N-BA-e-2020... -
Page 6: Control Panel
The number of cycles completed is Cycles: displayed here Reset button: Zeroing of the driven cycles The movement of the test bench is defined by the lower and upper limiting ring. These limiting rings must be adjusted for each test. TVM-N-BA-e-2020... -
Page 7: Application
The test stand has two 9-pin connectors to connect a force gauge and one connector for communication with the PC. The test stand can be operated with SAUTER AFH software. This allows the motion control and number of cycles to be set directly on the PC. -
Page 8: Warnings
(Max) of the test bench or measuring instrument or which do not act axially on the instrument via the test bench Note: To view the CE declaration, please click on the following link: https://www.kern-sohn.com/shop/de/DOWNLOADS/ TVM-N-BA-e-2020... -
Page 9: Assembly Instructions For The Test System
• The external load cell is mounted to the AFM 41 bracket with an M12x40 screw, included in the scope of delivery • Connecting the measuring cell to the display unit of the force gauge (Here as an example with a FH 1K) TVM-N-BA-e-2020... -
Page 10: With External Load Cell (Tvm 20Kn100 And Tvm 30Kn)
(Here as an example with a FH 20K) 10.4 Wiring of the test bench (model independent) • The force gauge screwed to the test stand is now connected to the test stand at the equipment port by means of the RS232 cable TVM-N-BA-e-2020... -
Page 11: Cabling Tvm With A Force Measuring And Length Measuring Device
PPPPPPPPPPP PPPPPPPport 10.5 Cabling TVM with a force measuring and length measuring device • Wire the force gauge wiring as described in previous points of section 10 • Connect the linear encoder to the PC via a USB-RS232 adapter TVM-N-BA-e-2020... -
Page 12: Technical Drawings
11 Technical drawings TVM-N-BA-e-2020... - Page 13 Position AxBxC [mm] D [mm] E [mm] F [mm] G [mm] H [mm] I [mm] 250x380x410 5000N230N 250x380x410 1120 5000N230NL 250x380x410 1120 10kN120N 295x545x480 1135 20kN120N 250x240x400 1120 30kN70N TVM-N-BA-e-2020...
