Related Manuals for Riedel SmartPanel RSP-1216HL
Summarization of Contents
Preface
Information
Provides details on symbols, warnings, and general handling precautions for the equipment.
Change History
Details recent updates and additions to the user manual and product features.
Firmware Version
Explains how to check and identify the current firmware version on the SmartPanel.
About 1200 Series SmartPanels
Introduces the 1200 series SmartPanels, highlighting key features and design philosophy.
RSP-1216HL SmartPanel
Operating Elements
Identifies and describes the physical controls and connectors on the front and rear of the RSP-1216HL.
Status LEDs
Explains the meaning and function of various status indicator lights on the panel.
Lever Key Numbering
Details the numbering scheme for the lever keys on the RSP-1216HL panel.
Power-Up
Guides the user through the initial power-on sequence and boot process of the SmartPanel.
Volume
Describes how to adjust master, sidetone, and port volumes using rotary encoders.
Info-Display
Explains the functionality and information displayed on the panel's info screen.
Technical Specifications
Lists detailed technical data, including dimensions, connectivity, and audio performance.
Reset
Outlines the procedure for performing a system reset or reboot on the SmartPanel.
RSP-1232HL SmartPanel
Operating Elements
Identifies and describes the physical controls and connectors on the front and rear of the RSP-1232HL.
Status LEDs
Explains the meaning and function of various status indicator lights on the panel.
Lever Key Numbering
Details the numbering scheme for the lever keys on the RSP-1232HL panel.
Power-Up
Guides the user through the initial power-on sequence and boot process of the SmartPanel.
Volume
Describes how to adjust master, sidetone, and port volumes using rotary encoders.
Info-Display
Explains the functionality and information displayed on the panel's info screen.
Replacing the Air Filter
Provides step-by-step instructions for replacing the air filters in the device.
Technical Specifications
Lists detailed technical data, including dimensions, connectivity, and audio performance.
Reset
Outlines the procedure for performing a system reset or reboot on the SmartPanel.
Panel-Menu
Transport
Selects the protocol for connecting the SmartPanel to the matrix (AES3 or AES67).
Brightness
Adjusts the brightness of the displays and key rings on the SmartPanel.
Device-Info
Displays current date, firmware version, and serial number of the SmartPanel.
Network
Configures IP addresses, subnet masks, and gateway for network settings.
Matrix
Shows information about the connected matrix, like net, node, and port numbers.
Service
Provides access to log files, reboot options, and demo modes for troubleshooting.
SmartPanel Firmware
Licensing
Explains the requirement for license files to activate panel applications.
Intercom App
Details the features and operation of the SmartPanel's intercom application.
Web Interface
Describes how to access and use the web interface for configuration.
Firmware Update
Outlines methods for updating the SmartPanel's firmware via USB or web interface.
AES67 4-wire App
Details the steps to activate and configure AES67 4-wire operation.
Appendix
Ports / Pinouts
Provides detailed pinout diagrams for various connectors like Ethernet, Matrix, and GPI.
Maintenance Recommendations
Offers guidelines for maintaining the system to prevent malfunctions.
Service
Lists contact information and procedures for technical support and repairs.
Need help?
Do you have a question about the SmartPanel RSP-1216HL and is the answer not in the manual?
