Page 1: Installation Guide
The Digital Communication Platform Installation Guide interstage Phistersvej 31, 2900 Hellerup, Danmark Telefon 3946 0000, fax 3946 0040 www.interstage.dk - pro audio with a smile... - Page 2 We are always happy to help you with any questions you might have. RIEDEL – Communications GmbH Rudower Chaussee 3 / R1 12489 Berlin Germany Tel. +49-(0)30 678261-0 Fax +49-(0)30 678261-59 www.riedel.net Copyright 2000 RIEDEL Funk- und Intercomtechnik Thomas Riedel – Wuppertal / Deutschland...
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ARTIST m – Digital Matrix Intercom ..........4 MATRIX Rear view Matrix................. 22 CONTROL PANELS Alarm Contacts..................Panel Types................... 5 Serial Interface Connection..............Connections: Control Panel Rear View..........6 Fiber Connection Up / Downstream..........Headset connection on the front of the unit........ -
Page 4: Artist M - Digital Matrix Intercom
ARTIST m - Digital Matrix Intercom ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 5: Panel Types
ARTIST m Control Panel Types xpansion ontrol anel ECP1016E ackmount ontrol anels RCP1012E RCP1028E esktop ontrol anel DCP1016E ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 6: Connections: Control Panel Rear View
Connections: Control Panel Rear View J10 Unicom J1 Matrix connection via CAT5 (optional) J2 Matrix connection via Coax J7 GPI Out J8 Audio In J6 GPI In J9 Audio Out J5 Headset B J3 Expansion J4 Headset A requires GPI-Option RCP-GPI-E requires Audio-Option RCP-AIO-E ARTIST m –... -
Page 7: Headset Connection On The Front Of The Unit
Headset connection on the front of the unit (+ 5V A/B power ) Front view of the connectors ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 8: Headset Connection On The Rear Of The Unit
Headset connection on the rear of the panel By unsymmetrical connection of a electrec microphone the micro + is on PIN 1 and micro shield is switched to PIN 6 and PIN 2. This results in A/B power for the electret microphone. + 5V Phantom Power + 5V Phantom Power Front view of the connectors... -
Page 9: Connection Of An External Microphon
Connection of an external microphone to the rear of the Conrol Panel + 5V Phantom Power By unsymmetrical connection of a electrec microphone the micro + is on PIN 4 and micro shield is switched to PIN 9 and PIN 5. This results in A/B power for the electret microphone. -
Page 10: Connection Of An External Loudspeaker
Connection of a Loudspeaker to the rear of the panel Output wattage: 2 W /4 Ohm Front view of the connectors requires Audio-Option RCP-AIO-E ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 11: Connection To Gpi Input / Output Contacts
Connection to GPI Input / Output Contacts Eg. External 5V relays Eg. external contacts 4 +5V 4 +5V Notes: Front view of the connectors • The carrying capacity of Pin 4 totals 50 mA • The contact carrying capacity of the outputs is 300 mA (protected by self resetting fuse) •... -
Page 12: Connection Of External Analog Audio Sources
Connection of external analog audio sources Level: norm +6dBu maximal +18dBu Level: normal +6dBu maximal +18dBu Input Impedance: >20kOhm Output Impedance: < 10Ohm Front view of the connectors requires Audio-Option RCP-AIO-E ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 13: Control Panel Including Audio And Gpi Options
Control Panel including Audio and GPI Option ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 14: Connection Of A Panel Via Cat5
Connection of a Panel via CAT5 to an ARTIST m Matrix Cable Specifications • Type: Cat5 (4x2 AWG24) Rear view: ARTIST m Frame Twisted pair with overall braid screen • Connectors: RJ 45 • Cable Length: max. 300 meters Pin Connections Rear view: Control Panel, here a RCP-1028 ARTIST m –... -
Page 15: Connection Of A Panel Via Coax
Connection of a Panel via Coax to an ARTIST m Matrix Rear view: ARTIST m Frame Cable Specificaitons • Type: RG59 – 20 AWG Video Kabel 75 Ω / 0,8 / 3,7 FRNC – halogen free • Cable Length: max. 650 Meter 75 Ω... -
Page 16: Connection Of An Expansion Panel
Connection of an Expansion Panels Rackmount Panel, here a RCP1028E Cable Specifications • Type: Cat5 (4x2 AWG24) Twisted pair with overall braid screen Expansion Panel –1, ECP1016E • Connector: RJ 45 • Cable Length: max. 2 Meter Expansion Panel Adresse 1 Expansion Panel –2, ECP1016E Expansion Panel Adresse 2 max. -
Page 17: Front And Rear View Rif 2064
Front and Rear View RIF 2064 RIF 2064 Front View RIF 2064 Rear View ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 18: Connector Pin Assignment Rif 2064
Connector Pin Assignment RIF 2064 Funktion IN 1 IN 1 „GPI-Input“ * "Mainframe" "Audio Out" "Audio IN" IN 2 IN 3 D-Sub 9 Female RJ45 3 pol XLR Male 3 pol XLR Female IN 4 IN 5 IN 6 Signal Pin Signal Pin Signal Pin Signal... -
Page 19: Connection To Gpi Input/Output Contacts Rif 2064
Connection to GPI Input/Output Contacts RIF 2064 Eg. External 5V relay Eg. external contacts 4 +5V 4 +5V Front view of the connectors ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 20: Connection Of Audio Input / Output Rif 2064
Connection of Audio Input / Output RIF 2064 2 Audio Out + 1 Shield 3 Audio Out 3 Audio In 2 Audio In + 1 Shield XLR 3 Male XLR 3 Female Level: nominal +6dBu maximal +18dBu Level: nominal +6dBu maximal +18dBu Output impedance: <... -
Page 21: Connecting A Rif2064 Via Cat5 To A Artist M Matrix
Connecting a RIF2064 via CAT5 to a ARTIST M Matrix Cable specification Rear view: ARTIST M Frame ype: Cat5 (4x2 AWG24) Twistedpair and shielded onnector type: RJ 45 Cable layout able length: max. 300 Meter Rear view: RIF 2064 ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 22: Rearview Matrix
Rearview Matrix Note: The 16 client card slots can be filled with the following cards: Alarm •COAX-108 Serial Port 1 •CAT5-108 10/100BaseT •AIO-108 •AIO-108D •TRK-108 •GPI-116 Connection for power cord 85-265V, 47-63Hz Port 8 PSU-128 -2 (Front view right) TRK-108 Fiber Connection for power cord AIO-108... -
Page 23: Alarm Contacts
Alarm Connections "CPU-128" "A larm" D-Sub 9 Male Pin Signal A larm 1 Out A A larm 2 Out A A larm In + 24 V n.c. A larm 1 Out B A larm 2 Out B A larm In — Please Note: •... -
Page 24: Serial Interface Connection
Serial Interface Connection Serial RS422 "CPU-128" RxD + "Serial Interface" RxD — RJ45 TxD + Pin Signal TxD — R xD + (R S422) R xD — (R S422) RJ45 TxD + (R S422) R xD (R S232) Serial GND (R S232) RS232 TxD —... -
Page 25: Fiber Connection Up / Downstream
Fiber Connection Up and Downstream CPU-128 Client Card‘s Ethernet Transmit Fiber (Primary) Receive Fiber (Primary) Communications Upstream Interface Interface Applications Downstream Transmit Fiber Secondary) Interface Interface Receive Fiber (Secondary) CPU-128 CAT5-108 AIO-108 COAX-108 Application: Audio, Video, etc. ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 26: Ethernet Connection 10/100Bt
Ethernet Connection 10/100BT "CPU-128" "10/100BT" RJ45 Pin Signal TxD + TxD — R xD + n.c. n.c. R xD — n.c. n.c. Note: Connector: RJ45 • Connection uses “PC”-pin assignment. • When connected to a Hub a1:1 cable is required! •... -
Page 27: Connection Of Gpi Input / Output
Connetion of GPI Inputs / Outputs ex. external contacts Front view Ex. Extern 24V relays Note: • The carrying capacity of Pins 17 and 18 together is 100 mA! • Bond Strength of the outputs is 300 mA (protected by a self resetting fuse) •... -
Page 28: Control Panel 19" Rcp10Xx
Pin Assignment Control Panel 19“ RCP10xx "Matrix" „GPI-Input“ * „Headset A “ ** „A udio In“ ** “Headset A ” RJ45 D-Sub 9 F emale D-Sub 9 F emale D-Sub 9 F emale XL R 4 Male (vorne) Signal P in Signal Signal Signal... -
Page 29: Expansion Panel
Pin Assignment Expansion Control Panel "EXP IN RJ45 Signal Data + Data – "EXP OUT RJ45 Signal Data + Data – n.c. n.c. n.c. n.c. n.c. n.c. ARTIST m – Instalation Guide 2.3 – 12.06.2003... -
Page 30: Desktop Panel
Pin Assignment Desktop Control Panel "Matrix" „GPI-Input“ * “Headset A ” „A udio In“ ** "Unicom" RJ45 D-Sub 9 F emale XL R 4 Male D-Sub 9 F emale D-Sub 15 F emale Signal P in Signal Signal Signal Signal GP I 1 In + TxD + Shield... -
Page 31: Matrix 1/2: Cpu - And Client Card/S
Pin Assignment Matrix 1/2: CPU and Client Cards "CPU-128" "CPU-128" "CPU-128" "CA T5-108" "A IO-108" "Serial Interface" "A larm" "10/100BT" Kupplung 1 - 8 Kupplung 1- 8 RJ45 D-Sub 9 Male RJ45 RJ45 RJ45 - 4-Wire Signal Signal Signal Signal Signal R xD + (R S422) A la m 1 Out A... -
Page 32: Matrix 2/2: Gpi Input / - Output
Pin Assignment Matrix 2/2: GPI Input / - Output "GPI-Input" "GPI-Output" "GPI-116" "GPI-116" D-Sub 37 - F emale D-Sub 37 - Male Signal Signal Signal Signal GPI 1 In + GPI 1 In - GPI 1 Out A GPI 1 Out B GPI 2 In + GPI 2 In - GPI 2 Out A... -
Page 33: Panel Quick Guide Funktions
Standard Keys DISPLAY KEYS The 8 digit displays also serve as keys. The knobs to the right of the keys serve as individual volume controls for each cross point. Turning the knob right raises the volume while turning the knob to the left lower it. Pressing the knob longer mutes the signal . -
Page 34: Funktion Keys
Function Keys SHIFT Enables the switching between the two levels of destinations. RCP1012E: Keys 1 – 12 and keys 13 – 24 RCP1028E: Keys 1 – 28 and keys 29 – 56 DCP1016E: Keys 1 – 16 and keys 17 – 32 If ECP-1016E expansion panels are connected to a control panel the shift key also shifts to the second layer of the expansion panel‘s keys. -
Page 35: Opt Key
Function Keys Key OPT = Option Pressing the option (OPT) key causes the standard keys to display the option menu. Here the specific settings of the panel are displayed. • PORT ADDRESS and PANEL NAME The port where the panel is connected is displayed, along with the panel‘s display name. Ex. Net 1 Node 2 Port 2.3 Camera ARTIST m –... -
Page 36: Control Panel / Matrix
Technical Specification CONTROL PANELS MATRIX RCP-1012E Dimensions (W x H x D): 19“ x 5 RU x 36cm Dimensions (W x H x D): 19“ x 1 RU x 56mm Power Consumtion: 115 VA Weight: 1.0 kg AC-IN: 85-265V 47-63Hz Power Consumption: 30 VA Matrix Size:...
