- Page 1 TTL-ES TTL-EUI TTL-TREND Air curtain systems Assembly and operating instructions Translated English version...
-
Page 2: Table Of Contents
12. Fault analysis and remediation, measures and risks Manufacturer, contact, service adress Imprint Assembly and operating instructions for Air curtain systems type TTL-ES, TTL-EUI and TTL-TREND Translated English version 01 Manufacturer: TTL Torluftschleier GmbH 5. Edition January 2020: 1.500, printed at chloreene-free paper Reprint, also excerpts, only with written authorization. -
Page 3: Imprint
Observe notes in the user instructions! 2.2 Proper use Air curtain systems prevent the exchange of air in open doors or gates. The TTL air curtain systems types ES, EUI and TREND can be mounted over doors on the ceiling, on the wall or - depending on type - also to the side. - Page 4 Any other use is not considered intended use, and is therefore not permissible. This parti- cularly includes use as dryer. In such a case, TTL Torluftschleier GmbH does not accept any Assembly, disassembly, start-up, repair and changes of and to the air curtain system must only may only take place following consultation with the manufacturer or by TTL employees.
-
Page 5: Assembly
Air curtain systems ES / EUI / TREND 4. Transport, packaging, storage to the forwarder as appropriate. If in doubt, the air curtain device should not be used in the event of any damage. Packaging serves the sole purpose of protecting the air curtain device during transport to the place of use. -
Page 6: Fitting With Wall Mounting Brackets
Air curtain systems ES / EUI / TREND 5.1.1 Fitting with wall mounting brackets brochures. Type TREND -5/LNS 100 cm 1000 150 cm 1500 200 cm 2000 1920 1990 250 cm 2500 1210 1000 300 cm 3000 2990 1000 Type ES Type TREND •... -
Page 7: Fitting With A Ceiling Mounting Kit
Air curtain systems ES / EUI / TREND 5.1.2 Fitting with a ceiling mounting kit 1 Thread M8/M10 for ceiling mounting 2 Air intake grate foldable 3 Maintenance flap 5 Electrical connection Type ES, Height of case H = 225 mm Type ES 100 1000... - Page 8 Air curtain systems ES / EUI / TREND Types TREND -10/15/LNX/HE und EUI -3, Height of case H = 400 mm Type 1000 1100 1500 1100 2000 1100 1920 2500 1100 1210 3000 1100 2920 EUI -3/TREND 100 -15 1000 1150 EUI -3/TREND 150 -15 1500...
-
Page 9: Vertical Mounting On A Stand Base
Air curtain systems ES / EUI / TREND 5.1.3 Vertical mounting on a stand base Type EUI -1/2 107,5 TREND -5/8/LNS/HE-L/HE-XL EUI -3 TREND -10/15/LNX EUI -4 TREND -20 • Fasten the pedestal to the front or stand side of the air curtain unit, if not already done at the factory. - Page 10 Air curtain systems ES / EUI / TREND Not for air curtains with electric heating. Caution: Risk of hot surfaces or liquids! Risk of burning or scalding. Switch off heating before, close water curcuit, cool down for at least 30 minutes! Heating and voltage connections are always situated opposite and depending on the design at the right or left side.
- Page 11 Air curtain systems ES / EUI / TREND ES: Heating connections sideways or on top EUI/TREND: Variable heating connections sideways or on top • Remove possibly the seal plug. • • Only types EUI and TREND: screw the seal plugs on the open ports. •...
- Page 12 Air curtain systems ES / EUI / TREND Mounting of a thermal static control valve In case of delivery air curtain system with an thermostatic valve for output temperature control these valve have to be integrated into the heating circuit and the temperature sensor •...
- Page 13 Air curtain systems ES / EUI / TREND Warning: Risk posed by electrical voltage! • Accomplish ultimate the needed electrical fusings provided by the customer before. • Before doing any connecting works be shure that the main supply is disconnected: the repair switch must be switched off and the fuses must be removed! •...
-
Page 14: Start-Up
Air curtain systems ES / EUI / TREND Connection for units with pump hot water heating (PWW units) • EUI -1/2 and TREND -5/8/LNS/HE-L/HE-XL These devices with connection to alternating current are connected to a 3-pole connection box. The connection is made to the terminals L, N, PE. N PE •... -
Page 15: Operation Via The Operating Console
Note: Observe cleaning and replacement intervals! Air intake grille of air curtain unit ES The grates of the air curtain systems EUI and TREND are equipped with the TTL easy-klick locking system: Air intake grate of the air curtain systems EUI und TREND with TTL-easy-klick locking •... - Page 16 Air curtain systems ES / EUI / TREND are equipped with the TTL easy-klick locking system and secured against unintended swing out by an safety catch with arrester hook. Every grid is secured if the air curtain system is equipped with multiple air intake grids.
-
Page 17: Service
• • • • 9. Service TTL factory service. 10. Cleaning Caution: Risk posed by hot surfaces! Risk of burning. Before cleaning, switch off the heating and the air curtain system and allow Warning: Sharp or pointy edges! and avoid direct contact with edges. -
Page 18: Fault Analysis And Remediation, Measures And Risks
Air curtain systems ES / EUI / TREND 12. Fault analysis and remediation, measures and risks odours, blowing of fuses or triggering of protective mechanisms, leakage of heating media, Fault Possible cause Remedy 1 LED on circuit Jumper is incorrectly inserted to the 1 connection: insert jumper. - Page 19 In the event of any questions, please contact the manufacturer at the address above. TTL GmbH reserves the right to undertake any change or improvement to parts or their accessories without the obligation to update earlier products and existing documentation.
-
Page 20: Manufacturer, Contact, Service Adress
TTL Torluftschleier GmbH Fabrikstraße 5 • 73650 Winterbach Fon +49 (0) 71 81 / 40 09 - 0 Fax +49 (0) 71 81 / 40 09 - 10 info@luftschleier.de • www.luftschleier.de...
