ViewSonic VX800-3 - 18" LCD Monitor Service Manual page 9

2.3.2 TMDS digital Signals
2.3.2.1 Video type
2.3.3 Audio spec.
2.3.3.1 Line input connection
2.3.3.2 Line input signal & impedance
2.3.3.3 OUTPUT
2.3.3.4 Frequency Response
2.3.3.5 Connector PC99 requirement Audio in
2.3.3.6 Cable length
2.3.3.7 Audio DPMS
2.3.3.8 Speakers
2.3.4 Input Signal Connectors
2.3.4.1 Analog RGB Video Input:
ViewSonic Corporation
DVI 1.0 compliant
3.5 mm stereo jack x 1
1.0Vrms, 10 kOhm
SIGNAL AT SPEAKER TERMINAL
3W @ < 5% DISTORTION
400 Hz – 20 KHz
Lime Green pantone # 577C
1.8 m
Speakers stay on when the rest of the monitor is in power saving.
Impedance
Output Wattage
PIN NO. Separate Sync
1 RED
2 GREEN
3 BLUE
4 GROUND
5 GROUND
6 GROUND
7 GROUND
8 GROUND
9 +5V
10 GROUND
11 N.C
4 Ohm
3.0W (max.) x 2
15 pin mini D-sub
Confidential – Do Not Copy
VX800-3
