Encore ENL832-TX User Manual

10/100mbps fast ethernet lan card
Hide thumbs

Advertisement

Quick Links

Download this manual
ENL832-TX-EN
10/100Mbps Fast Ethernet LAN Card
User's Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the ENL832-TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Encore ENL832-TX

Summary of Contents for Encore ENL832-TX

  • Page 1 ENL832-TX-EN 10/100Mbps Fast Ethernet LAN Card User's Guide...

  • Page 2: Table Of Contents

    FCC COMPLIANCE STATEMENT This ENL832-TX-EN has been tested and found to comply with the limits of a Class B computing devices, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Features & Specifications

    1. Features & Specifications 1.1 Features & Benefits Supports 32-bit PCI Bus Master for high performance and low processor utilization. * Complies to PCI 2.1 and PCI 2.2 specification * Complies with the IEEE 802.3 CSMA/CD, 10/100Base-TX standard. * Full duplex design to double the performance to 20Mbps/200Mbps. * One STP connector for 100Mbps or 10Mbps network speed.

  • Page 4: Hardware Installation

    2. Hardware Installation Turn off the computer and remove its cover. 2. Insert the adapter into a PCI slot. 3. Secure this adapter to the rear of the computer chassis and put back the computer cover. 4. Connect the adapter to the network using twisted-pair cable. 5.
  • Page 5 Step 2: Insert the Driver Installation CD into CD-ROM drive, window below will appear then click Install Driver: Step 3: Please wait while during the wizard is installing driver.
  • Page 6 Step 4: After driver has successfully installed, below message prompts. Click “OK” to close. Step 5: Click “Exit” button to close the Setup program.
  • Page 7 Step 6: To check if the driver is installed properly: Right-click “My Computer” from desktop Choose “Properties” Select “Device Manager” (For Window Vista) (For Windows XP) (For Windows 2000)

  • Page 8: For Windows Me

    3.2 For Windows ME Step 1: When Windows boots up, operating system will detect the LAN card and Add New Hardware Wizard window will appear. Click Cancel. Step 2: Insert the Driver Installation CD into CD-ROM drive, window below will appear then click Install Driver:...
  • Page 9 Step 3: Please wait while during the wizard is installing driver. Step 4: When operating system finishes loading device driver, window below will appear then click OK to complete the installation.

  • Page 10: For Windows 98Se

    Step 5: To check if the driver is installed properly: Right-click “My Computer” from desktop Choose “Properties” Select “Device Manager” 3.3 For Windows 98SE Step 1: When Windows boots up, operating system will detect LAN card and Add New Hardware Wizard window will appear.
  • Page 11 Step 2: Insert the Driver Installation CD into CD-ROM drive, window below will appear then click Install Driver: Step 3: After OS finishes loading device driver, window below will appear then click OK to restart the system. Step 4: When system boots up, window below will appear. Click OK to continue:...
  • Page 12 Step 5: Click OK to continue. Step 6: When operating system finishes loading LAN card files, window below will appear. Click OK to reboot the system, when your system boots up again, you are ready to use the LAN card.

This manual is also suitable for:

Enl832-tx-en
