Summarization of Contents
1 General Information
Warranty
Details HP's warranty terms for hardware and software, including limitations and exclusions.
Instruments Covered By Manual
Identifies the specific HP models and options covered by this manual.
Weight and Dimensions
Provides physical specifications for the instrument, including weight and overall size.
Storage and Shipment
Specifies environmental conditions and procedures for storing and shipping the instrument safely.
Safety Precautions for the Operator
Outlines essential safety measures for operating, servicing, and repairing the instrument.
2 Installation
Initial Inspection
Procedures for checking the instrument and packaging for damage or missing components upon receipt.
Operating Environment
Defines the acceptable temperature, humidity, and altitude limits for instrument operation.
Preparation for Use
Steps to prepare the instrument for operation, including power requirements and fuse checks.
Connecting to the Power Supply
Guidance on safely connecting the instrument to a grounded power source.
Connecting to the Network
Details on connecting the instrument to various networks via different interface connectors.
Connecting Accessories
Information on connecting external accessories like printers, monitors, and interface buses.
Additional Precautions for Service Engineers
Specific safety and ESD precautions for personnel performing service or maintenance.
3 Performance Tests
Recall Default Settings
Procedure to reset the instrument to its default configuration prior to running performance tests.
Self Test
Steps to run self-tests to verify the integrity of the HP 37718A/19A before performance testing.
PDH/DSn Internal Transmitter Clock Accuracy & Offset
Tests the accuracy and offset of the PDH/DSn transmitter clock at various data rates.
SDH/SONET Transmitter Clock Accuracy
Tests the accuracy of the SDH/SONET transmitter clock output relative to a reference.
Multirate Optical Interfaces
Specifies and tests optical transmitter wavelengths, power output, and receiver sensitivity.
PDH Transmit/Receive Jitter Amplitude Accuracy
Measures PDH transmit/receive jitter amplitude accuracy across various bit rates.
SDH Transmit/Receive Jitter Amplitude Accuracy
Measures SDH transmit/receive jitter amplitude accuracy across various rates and interfaces.
4 Terms
ETSI/ANSI Conversion and Equivalent Terms
Provides tables of ETSI terms with their ANSI equivalents and earlier term counterparts.
5 Self Test Overview
Confidence Test
A quick verification of main functions using back-to-back loopback testing.
All Tests
An extensive back-to-back verification of instrument operation, running various subtests.
PDH Test
Comprehensive tests of PDH Transmit/Receive sections, dependent on PDH option.
BER Test
Extensive tests for SDH/SONET Electrical and Optical Transmit/Receive sections.
JITTER Test
Tests for HP 37718A option 204, 205, 206, focusing on PDH/SDH Tx/Rx Jitter.
6 Option Structure/Module Configuration
SDH/SONET Operation Interface Options
Details the available SDH/SONET interface options for the HP 37718A and 37719A.
PDH/Dsn Options
Lists the available PDH/DSn interface options for the HP 37718A and 37718/9A.
SDH/SONET 2.5Gb/s Multirate BER Options
Specifies options related to SDH/SONET 2.5Gb/s Multirate BER testing.
