ADDITIONAL FEATURES

ƒ Compact and lightweight
ƒ Four powerful CPUs (i7 4GB RAM) on board
ƒ Eight (up to 24) power-cycled USB
interfaces per MTP-4 unit
ƒ Up to four handsets per MTP-4 unit
ƒ Four (up to 12) PCIe MiniCard modules per
MTP-4 unit
ƒ Phone platform (up to five phones)
ƒ RF isolated version of phone platform
available
ƒ Test phones with dummy battery and
external antenna interface
ƒ Vehicle kit with quick and easy fixation of
MTP-4 units
ƒ Portable kit with battery for indoor
measurements
ƒ Easily accessible SIM card slots for all test
devices
ƒ Sensitive GPS on board
ƒ Gigabit backbone LAN
ƒ Cascading of MTP-4 chassis without
external switch
ƒ Dedicated communication module (WLAN/
mobile)
ƒ Extended input voltage range: 10 to
28VDC (continuous, short dips to 6VDC)
ƒ Integrated UPS functionality for use in
train or vehicle
ƒ Connection of two different power
supplies is possible
ƒ Battery swap during operation
ƒ Charge control and alarm of battery
ƒ DC output for auxiliary equipment
ƒ Hardware dongle inside
ƒ Mechanical protection of cables and
interfaces
ƒ Ruggedized (for handling, shock, and
vibration)
ƒ Wide temperature range (0 to 60
ƒ Extended temperature range on request
(-20 C)
°
ƒ All interfaces and display on one side
Ascom Network Testing Inc.
1943 Isaac Newton Square
Reston | VA | 20190-5006 | USA
www.ascom.com/tems

TESTING FEATURES

ƒ Best algorithms for speech, video, and
audio testing – industrial and ITU
standards
ƒ Video telephony clips feeding directly
into the mobile device
ƒ Video telephony clips on the mobile
device screen captured electronically
ƒ Referenced and non-referenced video
algorithms
ƒ Speech MOS values displayed in real-time
during tests
ƒ Compact measurement data files
ƒ Online display of AMR codec status
ƒ Video-quality MOS algorithm on mobile
video applications
ƒ Real speech quality
ƒ In-band audio problem detection with
silence, level jump, echo gaps
ƒ Mobile data tests: HTTP, FTP, UDP, WAP,
SMS/MMS, Ping, and e-mail
ƒ Mobile application protocol stack (MMS,
WAP)
ƒ Measurement trigger points precisely
defined per ETSI
ƒ Protocol messages recorded with air
interface Layer 3 data
ƒ Combined test mobile phone and scanner
measurements
ƒ Subscriber view of QoS in uplink and
downlink
ƒ Simulation of subscriber behavior
ƒ Live recording and call statistics
ƒ Detailed decoding of engineering data:
Layer 3, RLC/MAC messages
ƒ Measurements over different air
interfaces: GSM, GPRS, EDGE, WCDMA,
CDMA-1X, WiMAX
ƒ Supports current technologies: HSPA+,
WiMAX (4G), CDMA EV-DO
° C)
ƒ GPRS/EDGE transmission-specific data:
TBF usage, QoS fulfillment, time used/
time wasted
ƒ Detection of unlawful transmitters in the
LTE frequency bands
NEW IN RELEASE 6.0
ƒ Brand new MTP-4 hardware platform
ƒ New LTE devices including trace
ƒ PCIe modules for speech and data tests
ƒ SRU GSM/WCDMA scanner
ƒ Samsung UMTS phones
