6 TEMS™ SYMPHONY 6.0
TEST ANYWHERE, ANYTIME

KEY FEATURES

ƒ Compact, light, and portable multi-processor
benchmarking platform
ƒ Same equipment can be used in vehicle,
nomadic, walk, and stationary
ƒ Support of PCIe MiniCard modules for data
and voice
ƒ Daisy chain of multiple MTP-4 units
controlled by a single user interface
Detachable user interface
ƒ
notebook/tablet PC connected via LAN/
WLAN
ƒ Attractive pricing and scalable design
MTP-4 portable kit
TEMS Symphony with its flexible MTP-4 platform offers the ubiquitous
benchmark testing capabilities that mobile operators and
measurement service providers need.
environment

VEHICLE KIT

When mounted in a vehicle, phones and other external test devices such as
RF scanners can be secured on a phone platform which can be stacked on
top of an MTP-4 chassis. An RF combiner on this platform will reduce the
number of external antennas needed and guarantee the required isolation
running on a
between the RF devices.
and daisy-chained via a Gigabit LAN providing eight to 24 channels, all
controlled by the same GUI.
mechanics. The equipment can be removed with a unique release mechanism.
All interconnection cables between the MTP-4 chassis and the phone plat-
form are well protected for safe transport and installation.

PORTABLE KIT

The MTP-4 unit can also be used for pedestrian, indoor, and nomadic testing.
Due to the compact size of the MTP-4 and its relatively low power consump-
tion, multiple hours of autonomy can be assured. The total weight of an
MTP-4 unit, including four test phones, four USB modems, four MiniCards,
patch antennas, and RF combiners, is less than 14 kg. A customized back-
pack will allow walk testing in all types of terrain. The bag can also be
wheeled, which enables easy and inconspicuous movement during indoor
test locations. The integration of patch antennas and an RF combiner allow a
controlled operation of between four and eight mobile devices in a properly
controlled and repeatable manner.
If more channels are needed, a second MTP-4 chassis can be stacked
Mechanical fixation in a vehicle is done with integrated stackable
MTP-4 chassis
with phone platform
