Desa BLP375A Owner's Manual

Propane construction heaters heater size: 375,000 btu/hr - a series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONSTRUCTION
Heater Size: 375,000 Btu/Hr - A Series
IMPORTANT: Read and understand this manual before assembling, starting, or servic-
ing heater. Improper use of heater can cause serious injury. Keep this manual for future
reference.
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUC-
TIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH,
SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE
FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE IN-
STRUCTIONS SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS
AN INSTRUCTIONS MANUAL, LABELS, ETC. CONTACT THE MANU-
FACTURER.
PROPANE
HEATERS
OWNER'S MANUAL
Models: BLP375A, RLP375A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLP375A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Desa BLP375A

Summary of Contents for Desa BLP375A

  • Page 1 HEATERS OWNER’S MANUAL Heater Size: 375,000 Btu/Hr - A Series Models: BLP375A, RLP375A IMPORTANT: Read and understand this manual before assembling, starting, or servic- ing heater. Improper use of heater can cause serious injury. Keep this manual for future reference.

  • Page 2: Safety Information

    375,000 BTU/HR - A SERIES PROPANE CONSTRUCTION HEATER SAFETY INFORMATION WARNINGS WARNING: FIRE, BURN, IN- HALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUS- TIBLES, SUCH AS BUILDING MA- TERIALS, PAPER OR CARD- BOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY THE IN- STRUCTIONS.

  • Page 3: Product Identification

    PRODUCT IDENTIFICATION Hot Air Outlet (Front) Outer Shell On/Off Switch Inlet Connector BLP& VLP375 Figure 1 - 375,000 Btu/Hr Models 100416 OWNER’S MANUAL UNPACKING Handle Guard Power Cord Hose /Regulator Assembly LP-PFA/PV 008C Remove all packing items applied to heater for shipment. Keep plastic cover caps (attached to inlet connector and hose/regulator assembly) for storage.

  • Page 4: Theory Of Operation

    375,000 BTU/HR - A SERIES PROPANE CONSTRUCTION HEATER THEORY OF OPERATION The Fuel System: The hose/regulator assembly attaches to the propane gas sup- ply. The propane gas moves through the solenoid valve and out the nozzle. The Air System: The motor turns the fan. The fan pushes air into and around the combustion chamber.

  • Page 5: Installation

    INSTALLATION WARNING: Review and un- derstand the warnings in the Safety Information section, page 2. They are needed to safely op- erate this heater. Follow all local codes when using this heater. WARNING: Test all gas pip- ing and connections for leaks after installing or servicing.

  • Page 6: Maintenance

    375,000 BTU/HR - A SERIES PROPANE CONSTRUCTION HEATER OPERATION Continued TO STOP HEATER 1. Tightly close propane supply valve on propane tank(s). 2. Wait a few seconds. Heater will burn gas left in supply hoses. 3. Turn on/off switch to the OFF position. 4.

  • Page 7: Service Procedure

    SERVICE PROCEDURE WARNING: Never service heater while it is plugged in, con- nected to propane supply, oper- ating, or hot. Severe burns and electrical shock can occur. CLEANING FAN Clean fan every 500 hours of operation or as needed. 1. Remove screws on side cover using 5/16"...

  • Page 8: Wiring Diagrams

    375,000 BTU/HR - A SERIES PROPANE CONSTRUCTION HEATER WIRING DIAGRAMS Solenoid Valve Ignitor Orange Blue White Control Black Blue Blue Connector Green Figure 11 - Wiring Diagram Black Orange Black Green Black Green Line Figure 12 - Electrical Ladder Diagram Green Motor Orange...

  • Page 9: Specifications

    120 V/60 Hz Direct Spark 34 x 13 x 19.5 TECHNICAL SERVICE You may have further questions about this heater. If so, contact DESA International’s Technical Service Depart- ment at 1-800-323-5190. You can also visit DESA International’s Technical Service www.desatech.com.

  • Page 10: Illustrated Parts Breakdown

    375,000 BTU/HR - A SERIES PROPANE CONSTRUCTION HEATER ILLUSTRATED PARTS BREAKDOWN BLP375A RLP375A Note: Screws are standard hardware items 100416...

  • Page 11: Parts List

    100407-01 097815-05 097941-09 097895-05 097916-01 LPA1020 LPA2020 LPA4020 HA1210 100416 OWNER’S MANUAL DESCRIPTION Outer Shell Assembly (BLP375A) Outer Shell Assembly (RLP375A) Combustion Chamber Assembly Burner Assembly Ignitor Cleat Handle Ignitor Cable Motor Shorty Bushing Fan Guard Strain Relief Bushing Cord Assembly...

  • Page 12: Warranty And Repair Service

    Should your heater require service, return it to your nearest authorized service center. Proof of purchase must be presented with the heater. The heater will be inspected. A defect may be caused by faulty materials or workmanship. If so, DESA International will repair or replace the heater without charge.
