ASCOM 9DLD - DATASHEET 1 Datasheet page 2

product sheet: AscoM 9dLd
Features
Easy installation and service
Flexible precision
Position and direction
Proven technology
Robust construction
Simple upgrades
Tamper protection and surveillance reliability
Technical data
Dimensions: 160 x 120 x 90 mm
Supply voltage: 12- 24 VDC
Operation temperature: 0° – 40°C
Ascom
Wireless Solutions
p.o. Box 8783 se-402 76 Göteborg, sweden
t +46 31 55 93 00 | F +46 31 55 20 31
www.ascom.com
Once installed, it can be reprogrammed remotely, if required. The directional characteristics of the
locator coverage allow for flexible placement of the unit.
The Ascom 9d system offers flexible location precision that reaches from large zones with base
station location down to corridors or even rooms using the 9dLD. All depending on the specific
needs of the customer.
Easy determination of both position and direction of a person, thanks to the transmission of current
and previous location codes together with the current base station. A time stamp is also added to
each location code.
Fully DECT compliant
Robust, impact resistant housing. IP65 classified for water, dust and soil resistance.
Any Ascom system can be upgraded with location devices. No cabling required!
Should the output power fail, or the locator be tampered with, the monitor will immediately
be activated and call attention to the problem. For high security systems where surveillance
is demanded, a monitoring cable is necessary.
Flexible set up
Whether fixed to monitor a room, a corridor, a stairwell or an entire building,
the 9d Location device is highly precise. Both the cell size and the setup of
the location transmitter are customised to suit the specific needs of the
customer, depending on the risk level and the layout of the premises.
Furthermore, the 9dLd is designed to interact with previously installed
Ascom teleprotect systems and to coexist with other cordless alarm sys-
tems with minimum risk of interference.
A system to grow with
offering the highest accuracy and reliability, the 9dLd locator is built on
pure dect. previously installed Ascom 9d systems can be upgraded with
location, with no cabling required. this means that if the security require-
ments of your operations change, the 9dLd range and set-up can be ad-
justed to satisfy the new conditions with minimal effort. to make alterations
as simple, trouble-free and inexpensive as possible, upgrading is primarily
software-oriented.
Reliable systems at the cutting edge
experts in wireless communication, Ascom perpetually strives to stay ahead
of your needs. Built on a wealth of experience, and evolved from years of
close interaction with our customers, you can rely on our systems to enhance
your operations.
tenance costs, the locators can be placed inside and behind walls, in ceilings
etc to prevent sabotage. they can also be tamper protected to indicate
external damage.
to further increase the reliability of the system and to decrease main-
