ENERMAX GALAXY EVO PSU Datasheet

Galaxy evo psu series

Advertisement

Quick Links

GALAXY EVO
POWER TOMORROW
FEATURES
82PLUS ready!
High performance PSU series with max. 89% efficiency@ 20-100% load. Certified by 80 PLUS
12 CPU/GPU + 24 DRIVES MAX.
The world's most advanced design supporting the most diverse CPU, GPU & drive connector configurations.
99% 12V Power
World's strongest EPS12V PSU with 99% 12V output capability.
FUTURE CPU ready!
Ready for most upcoming CPU generations by 12P sockets for possible connector changes, by complying to latest EPS12V PSU design
guides for compatibility & by ZERO LOAD Design for C6 state functions.
FUTURE GPU ready!
Ready for most upcoming GPU generations by 12P sockets for possible connector changes, by six massive 12V rails for perfect load
distribution & by ZERO LOAD Design for Hybrid Mode functions.
AHD² Topology
Industry-leading "Asymmetric Hybrid DC-to-DC" topology with the world's highest efficiency & most stable performance.
24/7 @ 50°C ready!
Non-Stop industrial class performance at 50°C/122°F ambient.
PowerGuard
PSU status monitor with 4-mode LED (Off / Stand-by / OK / Fail).
SafeGuard
Industrial-leading octuple protection circuitry of OCP, OVP, UVP AC, UVP DC, OPP, OTP, SIP & SCP protects your system.
AirGuard
Patented air-inlet with optimal aero-dynamical design reducing noisy air turbulences.
HeatGuard
Keeping PSU fan running for 30-60 seconds after shut down to dissipate the remaining system heat and prolonging system lifetime.
SILENT ready!
Ultra-quiet 13.5cm fan with intelligent RPM control guarantees cool performance and silent operation.
SERVER ready!
SSI PSDG 2009 support for latest Intel
AMD GAME! Ultra systems and downward compatible with SSI PSDG 2008 1.0, EPS12V 2.92, 2.91, 2.8.
DXX ready!
For PCI Express 2.0/DXX next-generation graphic cards with 6+2P(8P) PCI-E connectors.
EMC ready!
Full-scale electromagnetic filtering protects your system against radiation interferences (CE EMC EN61204 compliance).
PSU SERIES
®
Core™ Extreme/i7, Xeon™ and AMD
850W/950W/1050W/1250W
®
organization.
®
Opteron™ and SLI™ or CrossFireX™ and AMD GAME! or
www.enermax.com forum.enermax.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the GALAXY EVO PSU and is the answer not in the manual?

Questions and answers

Summary of Contents for ENERMAX GALAXY EVO PSU

  • Page 1 AMD GAME! Ultra systems and downward compatible with SSI PSDG 2008 1.0, EPS12V 2.92, 2.91, 2.8. DXX ready! For PCI Express 2.0/DXX next-generation graphic cards with 6+2P(8P) PCI-E connectors. EMC ready! Full-scale electromagnetic filtering protects your system against radiation interferences (CE EMC EN61204 compliance). www.enermax.com forum.enermax.com...
  • Page 2 GPU(s) will hibernate and shift all GPU processes to CPU or chipset. This means they have such a wide dynamic load range as well. www.enermax.com forum.enermax.com...
  • Page 3 *1 Heavy-duty workstation with >16 FB-DIMM will neede 5A 5Vsb power in ACPI S3 mode. GALAXY EVO can perfectly support them and also >14 USB devices. *2 Max. CPU/GPU support may need additional modular cables. *3 Actual maximum support may vary by available connectors per model and by power consumption of connected components and is limited to DC output specifications. www.enermax.com forum.enermax.com...
  • Page 4 CERTIFICATIONS & STANDARDS © 2009 ENERMAX Technology Corporation. All rights reserved. Specifications are subject to change without prior notice. Actual products and accessories may differ from illustrations. Omissions and printing errors excepted. Content of delivery might differ in different countries or areas. Some trademarks may be claimed as the property of others.
