- Page 1 SPL-R Series ™ SPL-800R SPL-1000R SPL-1200R SPL-1500R U S E R ’ S M A N U A L D S P - C o n t r o l l e d H o m e T h e a t e r S u b w o o f e r...
- Page 2 R e s t o r i n g D e fa u l t s C a u t i o n w w w . v e l o d y n e . c o m SPL-R User’s Manual...
-
Page 3: Table Of Contents
Velodyne Products ........ -
Page 4: Congratulations
C o n g r a t u l a t i o n s Congratulations on your purchase of a Velodyne Small Plays Loud-Remote (SPL-R) subwoofer. This system represents the state-of-the-art in low frequency reproduction. Read and follow the instructions below to insure safe and proper system operation. -
Page 5: Installation
I n s ta l l a t i o n Your new Velodyne subwoofer provides for a number of installation options. Read all the installation information below in order to determine which installation option is best for your system. Remember to perform all installation procedures with system power turned off. -
Page 6: Rear Panel Connections
R e a r Pa n e l C o n n e c t i o n s Figure 1 shows the connections on the rear panel of the SPL-R. Following are brief descriptions of the connections described in Figure 1. More detail on these connections can be found in the next section. -
Page 7: Rear Panel Connections - Detailed Explanation
(8) IR Input Connect an IR repeater to this jack for use with universal remote systems. (9) 12v Trigger When this mini jack is connected, the unit remains in power-off mode until 12 volts is supplied across the two leads. Polarity is irrelevant. REAR PANEL CONNECTIONS - DETAILED EXPLANATION R e a r Pa n e l C o n n e c t i o n s - D e ta i l e d E x p l a n a t i o n... -
Page 8: Interconnect Cables
In these installations, you may want to bypass the crossover in either the processor or the Velodyne subwoofer. In some cases, you may want to use BOTH crossovers. To do this, you can use both your processor’s crossover and the one internal to the Velodyne sub. You should stagger the frequencies, (i.e., 120 Hz subwoofer, 80 Hz processor) for best results. -
Page 9: Usage
Caution! This subwoofer has electronics built into the cabinet. Do not place the cabinet next to sources of heat such as furnace registers, radiators, etc. Do not place the unit near sources of excessive moisture, such as evaporative coolers, humidifiers, etc. The power cord should be routed in such a way that it will not be walked on, pinched or compressed in any way that could result in damaging the insulation or wire. - Page 10 This button automatically EQs the subwoofer using a 6-band internal graphic equalizer. To use this feature, first plug in the supplied microphone into the Mic Input jack on the back panel of the subwoofer and place the mic in your preferred listening position. Then, by pressing EQ on the remote, the subwoofer emits 12 “sweep tones”...
- Page 11 P R E S E T S There are four presets, consisting of Movies, R&B - Rock, Jazz - Classical, and Games. As a preset is chosen, the light flashes the corresponding number of times. The presets provide the following characteristics for bass reproduction: Movies: Maximum output and impact for explosions and other action adventure movie content.
- Page 12 Each preset has its own characteristics with respect to subsonic filter, volume differential and a single equalizer (EQ) in order to optimize the listening mode for the preset. The following table shows the settings for the various presets: Preset Subsonic Volume Filter Frequency...
-
Page 13: Care Of Your Subwoofer
C a r e o f Yo u r S u b w o o f e r Do not use any harsh detergents or chemicals to clean the cabinet. Abrasives, detergents, or cleaning solutions will damage the finish on the cabinet. We recommend using a damp cloth to clean the front, back and sides. -
Page 14: Specifications
S p e c i f i c a t i o n s Specifications SPL-800R SPL-1000R SPL-1200R SPL-1500R Woofer: 8” forward firing 10” forward firing 12” forward firing 15” forward firing (6.5” piston diameter) (8” piston diameter) (9.7” piston diameter) (12.7”... - Page 15 VELODYNE ACOUSTICS, Inc. (“VELODYNE”) warrants all electronics for a period of three years, drivers for a period of five years, and full range speakers for a period of five years. All VELODYNE products have a warranty from the date of purchase against defects in materials and workmanship subject to the following conditions:...
-
Page 16: Velodyne Products
V e l o d y n e P r o d u c t s 110V 230V ® ® DD Series SPL™-R Series DD Series SMS™ -1 DD-10 SPL-800R DD-10 DD-12 SPL-1000R DD-12 SPL-800i DD-15 SPL-1200R DD-15 DD-18 SPL-1500R DD-18 SPL™-R Series Digital Drive 1812... - Page 17 Velodyne Acoustics, Inc. 345 Digital Drive Morgan Hill, CA 95037 408.465.2800 voice 408.779.9227 fax 408.779.9208 service fax www.velodyne.com Service E-mail: service@velodyne.com Product E-mail: help@velodyne.com Technical E-mail: techhelp@velodyne.com 63-SPLR Rev F Jan07 w w w . v e l o d y n e . c o m...
