Summarization of Contents
Congratulations!
Prior to Installation
Unpack carefully, use caution when lifting, save carton, and record serial number.
Product Features
Prepare for Installation
Read installation information to determine the best option for your system.
Installation
Inputs
Connect using speaker-level or line-level jacks, but not both simultaneously.
Volume control
Balances subwoofer output with main speakers for a similar output level.
Low-pass crossover - 40 to 120Hz
Adjusts the upper limit of the subwoofer's frequency response for smooth transition.
Phase adjustment - 0°/180°
Reverses subwoofer output phase to correct for mismatches and cancellations.
Troubleshooting and Service
Troubleshooting Steps
Check power, signal, controls, and protection circuit engagement before seeking service.
Conditions Requiring Service
Service needed for damaged cords, abnormal operation, water exposure, or physical damage.
