Air Filters and Front Panel Removal
Remove Air Filters
Steps for removing air filters, including unfastening hooks and pulling them downwards from the unit.
Remove Front Panel
Procedures for opening the front panel and releasing its shafts to detach it from the main unit.
Horizontal Blade Removal
Release Horizontal Blade Shafts
Instructions to release the center, left, and right shafts of the horizontal blade for removal.
Front Grille Removal
Remove Front Grille
Steps to remove 5 screws and unfasten 3 hooks on the top of the front grille to detach it.
Electrical Box Removal
Remove Service Cover and Fixtures
Steps to remove the service cover, wire fixture, and disconnect the connecting wire from the terminal board.
Disconnect Harnesses and Remove Box
Procedures for disconnecting connectors, releasing harnesses, and removing the electrical box from the bottom frame.
PCB Removal Procedures
Remove Display/Signal Receiver PCB
Steps for unfastening hooks to remove the signal receiver unit and display/signal receiver PCB.
Remove Intelligent Eye Sensor PCB
Steps to remove sealing material and unfasten hooks to remove the Intelligent Eye sensor PCB.
Remove Control PCB
Procedures for unfastening hooks to remove the control PCB from its mounting.
Remove Control PCB from Terminal Board
Steps to unfasten hooks, disconnect terminal connectors, and remove the control PCB.
Drain Pan, Swing Motors, and Vertical Blade Removal
Remove Drain Pan
Steps for removing the drain hose, piping, screws, and the drain pan assembly.
Remove Swing Motors
Procedures for removing swing motors for both horizontal and vertical blades.
Remove Vertical Blade ASSY
Instructions for removing the cover link and vertical blade assemblies from the unit.
Indoor Heat Exchanger Removal
Remove Auxiliary Piping and Screws
Steps to pull out auxiliary piping and remove screws before detaching the indoor heat exchanger.
Remove Indoor Heat Exchanger
Procedures for removing screws and hooks to detach the indoor heat exchanger from the unit.
Fan Rotor and Fan Motor Removal
Remove Fan Rotor and Side Plate
Steps to remove screws, side plate, and loosen the fan rotor screw.
Remove Fan Motor
Procedures for removing the fan rotor and the fan motor from its mounting.
