Alaris S2000w Series Setup Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

S2000/S2000w Series Scanners
ISIS Scanning Setup Guide
A-61894

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S2000w Series and is the answer not in the manual?

Questions and answers

Related Manuals for Alaris S2000w Series

Summary of Contents for Alaris S2000w Series

  • Page 1 S2000/S2000w Series Scanners ISIS Scanning Setup Guide A-61894...

  • Page 3: Table Of Contents

    Table Of Contents 1. Using the ISIS Driver __________________________________________ 5 About this Help system Configuring Image settings Configuring Scanner settings Preset Configurations dialog box 2. Image Settings _______________________________________________ 9 Main tab Layout tab Scan Area dialog box Image Processing tab Auto Color Detect tab Dropout tab Adjustments tab...

  • Page 5: Using The Isis Driver

    About this Help system This document provides help for setting up and using the Open Text Corporation ISIS® driver for the Alaris S2000/S2000w Series Scanners. ISIS (Image and Scanner Interface Specification) is an industry standard way of controlling an image acquisition device, such as a scanner or camera, and transferring the data it outputs into a computer system.

  • Page 6: Configuring Image Settings

    Configuring Image settings The main ISIS Driver window provides a set of several tabs for configuring images. You can select each of these tabs and make any choices necessary to meet your scanning needs. The Image Mode, Camera, Mode and Toggle Patch selections are available with all of the Image tabs (e.g., Main, Layout, Image Processing, etc.).

  • Page 7: Configuring Scanner Settings

    Help: displays on-line help about the options available on the selected window. Default: resets the values on all tabs to the default settings. See also: Layout tab Scan Area dialog box Image Processing tab Auto Color Detect tab Dropout tab Adjustments tab Background tab Image Edge Fill tab...

  • Page 8: Preset Configurations Dialog Box

    Preset Configurations dialog box This dialog box maintains a list of saved driver settings. You can Save, Delete or Import a preset by clicking one of the Preset Configuration icons; or you can select/modify a predefined preset that is shown in the Preset Name list box.

  • Page 9: Image Settings

    Image Settings Main tab The Main tab provides the following options: Dots per inch (dpi) or resolution — indicates the scanning resolution, which largely determines the quality of the scanned image. The greater the resolution, the better the reproduction. However, scanning at a higher resolution also increases scanning time and file size.
  • Page 10 Photo: the scanner will locate the photograph on the document and return an image that contains just the photograph. If the scanner finds more than one photograph on a document, one image is still returned which contains all photographs. Photo with ROI: is the same as Photo except you may select the document scan area that is used when finding photos.

  • Page 11: Layout Tab

    Layout tab The Layout tab provides the following options: Page Size - the default page size is set when a scanner is first selected. You can choose a different page size using the drop-down list. Page size should be set to the Scanner’s maximum when using the Automatic or Aggressive cropping option.

  • Page 12: Scan Area Dialog Box

    See also: Scan Area dialog box Scan Area dialog box The Scan Area dialog box allows you to define the amount of image data which is returned to the PC. Select the Image Mode (either Normal or Merged) based on the cropping option selected on the Main tab.

  • Page 13: Image Processing Tab

    Height: the height of the scanning area. Units — select whether you want the area to be defined in Pixels, Inches or Centimeters. Image Processing tab The Image Processing tab provides the following options: General Options Deskew — automatically straightens a document within ±0.3 degrees of the leading edge of the document.

  • Page 14: Auto Color Detect Tab

    Text with Photographs: when the documents you want to scan contain a mix of text and photos. Photographs: when the documents you want to scan are comprised mainly of photos. Media type — allows you to select the type of paper you are scanning, based upon the texture/weight.
  • Page 15 Off: this is the default. No color content will be detected. Low: documents requiring only a small amount of color to be saved as color or grayscale images. Used for capturing documents that are primarily black text with small logos, or contain small amounts of highlighted text or small colorful photos.

  • Page 16: Dropout Tab

    Dropout tab The Color Dropout options are only available when the Scan as selection is Black and White or Grayscale. The Dropout tab provides the following options: Color Dropout — used to eliminate a form's background so that only the entered data is included in the electronic image (e.g., remove the form’s lines and boxes).
  • Page 17 Brightness — changes the amount of white in the color or grayscale image. The values range from -50 to 50. Contrast — makes the images sharper or softer. The values range from - 50 to 50. Sharpen — increases the contrast of edges within the image. The values range from 0 to 3;...

  • Page 18: Background Tab

    Blue — changes the amount of blue in the color image. If you select Automatic, the scanner will analyze the documents to produce the best possible image. Automatic - advanced is for advanced users that want to further adjust this option.

  • Page 19: Image Edge Fill Tab

    Image Edge Fill tab This option fills the edges of the final electronic image by covering the area with the specified color. Image Edge Fill is performed after all other image processing options have been applied. Fill Color — allows you to select the color to fill the edges with. None White Black...

  • Page 20: Barcode Reading Tab

    Content: images will be considered blank based on the document content within the image. Select Black and White, Grayscale or Color to choose the maximum amount of content that the scanner will consider to be blank. Any image that has more content than this value will be considered non- blank and will be given to the scanning application.
  • Page 21 Search Area: select the area of the image to search. Search Area: select the area of the image to search. Entire Document Part of Document X: the distance from the left edge of the image Y: the distance from the top edge of the image. Width: of the area to search Height: of the area to search.

  • Page 23: Scanner Settings

    Scanner Settings Scanner tab The Scanner tab provides the following options: Document Feeder Paper Source Automatic: looks for paper in the ADF first. If there are no documents in the input elevator, the scanner will scan from the flatbed. This option is only available if a flatbed is attached.

  • Page 24: Transport Tab

    For S2000 series scanners you can configure the following power settings. For S2000w series scanners, configure power settings on the scanner touch screen or embedded web site. Power Off — allows you to set the amount of time, in minutes, the scanner has to be in power saver mode before it automatically turns off.

  • Page 25: Sleeved And Split Documents

    NOTES: Changing this value will affect the maximums for the following settings: Layout - Page Size; Multifeed - Length Detection. Not all combinations of settings for Image Mode and Dots per inch are supported at the larger lengths. To allow for greater flexibility with applications, the scanner will not generate an error until it sees a document whose length is not supported.
  • Page 26 Sleeved Document is - put pages that are fragile or difficult to feed in an accessory sleeve to simplify feeding; or fold a large page and put it in a sleeve; choose imaging instructions from list: Choices offered for Sleeved Document is are affected by the Camera(s) selected in Image Mode.

  • Page 27: Digital Stamp

    Digital Stamp The Stamping tab allows you to superimpose your own graphic and a small amount of text onto images. You may also put a rectangular border around the stamp. The defined stamp is connected to the settings shortcut, so you can have more than one digital stamp defined for your users.
  • Page 28 Off: the displayed image will not update until another Preview scan is performed. Units: selects the unit of measurement: Inches, Centimeters and Pixels. Some icons described above are available only when a Preview image is displayed. Stamping - Text tab On - enables a digital stamp that includes text.
  • Page 29 Define the text part of your digital stamp by choosing one or more elements. You can add the same element more than once, for instance if you want your text to have more than one Space in it - except that only one Message element is allowed per line.
  • Page 30 Example Shows the format of this line of digital stamp text, as defined so far. OK - saves your changes. Cancel - closes the window without saving any changes. Stamping - Graphic tab On - enables a graphic part of the digital stamp. Toolbar buttons Add: displays the operating system's File Open window so you can find a custom graphic to use.

  • Page 31: Multifeed Detection Tab

    Orientation - set the digital stamp at this angle. Border On - check, to put a rectangular line around the perimeter of your stamp. Color - use Select button to choose border color. Thickness - how heavy a line to use for the border. Opacity - 0% makes the digital stamp completely transparent;...

  • Page 32: Log Tab

    Stop Scanning - leave paper in path: scanning will stop immediately (i.e., making no attempt to clear the paper path) and control will return to the scanning application (i.e., ends the job). Image(s) of the multi- fed document will not be generated. Clear any documents from the paper path prior to restarting the scan session from the scanning application.

  • Page 33: Debug Tab

    You can view the Operator and Meter logs and save this information to a file by copying the information to the clipboard then pasting it into a document or you can Save all the logs. Save As: saves all the logs for viewing by support personnel. When selected, a save window will be displayed: Description: enter a brief description of problem/reason for saving the logs.

  • Page 35: Network Isis

    Network ISIS Network ISIS Overview When a scanner is connected to a network, ISIS driver networking allows any client computer on the network to operate the networked scanner in the same manner as a local scanner. After placing an original document to be scanned in the network scanner, an ISIS application can be used on a client computer where the ISIS driver is installed.
  • Page 36 Configured Network Scanners — displays a list of shared scanners on this server with connection information and share information. The Stop Sharing button will shop sharing the selected scanner. If there are no shared scanners, the Stop Sharing button is unavailable. Add —...
  • Page 38 All trademarks and trade names used are the property of their respective holders. The Kodak trademark and trade dress are used under license from Eastman Kodak Company. © 2018 Kodak Alaris Inc. TM/MC/MR: Alaris...
