INSTALLATION
1. Power Cord
2. VGA Cable
3. Composite Video Cable
4. USB Cable
5. VGA to Component/HDTV Adapter
6. S-Video Cable
7. Audio Cable Jack/Jack
8. DVI Cable (Optional Accessory)
9. 5V DC Output Jack for attached
Dongle Device (Optional)
INTERFACE CONNECTOR
Connecting to a Computer
1. Ensure the projector and your com-
puter are turned off.
2. Connect one end of the VGA cable
to the "VGA In" connector on the
projector; connect the other end
to the VGA connector on the com-
puter and tighten the screws.
3. Connect one end of the power cord
into the AC power socket on the
projector; connect the other end to
an electrical outlet.
Powering On the Projector
Quick Start
9
without DVI model
1. Remove the lens cap.
2. Turn on the projector first and then
3. Adjust the position, focus and zoom.
4. Run you presentation.
1. Press the power button twice.
2. Do not remote AC power cord from
USB
S-Video Output
DVI
RGB
2
6
8
5
DVD Player,
Settop Box,
3
HDTV receiver
7
with DVI model
Powering On the Projector
the computer.
Powering Off the Projector
outlet until the projector fan shut
down.
1
4
Video Output
