ZENEC ZE-NC2040 Brochure & Specs page 2

E>GO naviceiver – 100 % custom-fit
E>GO is an innovative concept from ZENEC, the leading multimedia
specialist. Exchange and Go – E>GO for short – stands for a new
gen-eration of naviceivers, whose construction and design is custom-
fit to the interior of various types of automobiles.
Navigation, entertainment, communication – the ZE-NC2040 navicei-
ver is a complex navigation and multimedia system with a large range of
features. ZENEC's new top-of-the-line model fits together visually with
all automobiles belonging to the VW Golf IV line – for example with the
VW Golf IV, VW Passat, VW Bora, VW Polo and VW Sharan.
Perfect integration
The design of the ZE-NC2040 is specifically tailored to match up with
the interior of VW Golf IV line vehicles including the button illumination
in red.
Ingeniously easy operation
All functions are comfortably operated using the touchscreen: From the
operation of the navigation or the iPod and the Parrot hands-free equip-
ment to additional components like a DVB-T tuner or rear view camera.
The red button illumination and the customized design of the front
panel makes the E>GO not only perfect for the respective look of the
car interior, but the E>GO is also effortlessly integrated into the existing
automotive electronics. The ZE-NC2040 is suited for installation into
the original center console of the above named automobiles without
further modifications and without any additional adapters: simply take
out the factory radio, put in the E>GO and drive off.
ZENEC E>GO – ingeniously easy, visually perfect.
iPod and iPhone ready
As a matter of course, the ZE-NC2040 is iPod and iPhone ready for
all models (compatibility list on www.zenec.com). The connection is
made with the ZE-NC-IPS interface cable (available separately). Com-
plete compatibility means that songs, videos, podcasts, etc. can be
played back and controlled via touchscreen.
First-class navigation
The integrated navigation system of the ZE-NC2040 is absolutely
upper class: maps covering 43 European countries, TMC/TMC Pro
receiver, tunnel mode, lane assistant, 3-D landscape/city map views
or the highway split screen display mode with real signpost ren-
dering (display of the highway signs on the map) – these features
underline the high standard with which the ZENEC E>GO navigates.
Pure infotainment
When it comes to the top-of-the-line naviceiver equipment, all wishes
have been fulfilled: The built-in CD/DVD drive plays all the current A/V
formats. The electrical and mechanical anti-shock system provides for
perfect image and sound fidelity during the ride. In addition to an RDS
tuner for the best radio reception, the ZE-NC2040 is also equipped
with an integrated digital power amplifier (4 x 50 watts) and a Dolby
digital decoder.
The E>GO has a USB port and a SD/SDHC card reader so music, mov-
ies, multimedia files or photos can be easily played back. The card slot
is easily accessible on the front and is useable for SD and SDHC cards
of up to 8 GB of memory.
Compatible automobiles
VW Passat 2001 – 03/2005 VW Bora Variant
VW Passat Variant 2001 – 08/2005 VW Polo 9N3
VW Golf IV 1997 – 2003 VW Sharan
VW Golf IV Variant 1999 – 05/2006 AUDI A4 B6
VW Bora 09/1998 – 01/2005 AUDI A6 C5
Please note: The ZE-NC2040 replaces the VW radio navigation systems "RNS MCD" and "RNS-MFD", the AUDI radio navigation system "Navigation Plus" and the SEAT radio "RNS 2DIN".
Restrictions: The ZE-NC2040 does not come with an multifunction display connection or steering wheel remote connection. The vehicle must be set up for a 2-DIN radio. The ZE-NC2040 is equipped with an
ISO cable harness, which means that vehicles fitted with a quad lock connection need an adapter.
Grade A image presentation
The 16.5 cm/6.5" touchscreen dis-
play is top quality: A non-reflecting
TFT LCD panel with LED backlight
delivers sharp, brilliant and high-con-
trast pictures – under bright daylight
conditions.
All of the functions can be comfort-
ably controlled using the touch sen-
sitive panel. A Dual-Main-GUI (gra-
phical user interface) with two main
planes and large display icons make
sure that the E>GO can be unerringly
operated during the ride.
Communication made easy
The ZE-NC2040 is equipped with an advanced CK5050+ Bluetooth
system from Parrot. This makes playing music from a mobile phone
and making phone calls in the car as simple as child's play.
1999 – 05/2006 SEAT Ibiza 6L 2002 – 2008
05/2005 – 06/2009 SEAT Leon 1M 1999 – 2005
1998 – 2008 SEAT Cordoba 6L 2002 – 2008
2000 – 02/2004 SEAT Toledo 1M 1999 – 2004
1997 – 02/2004 SEAT Alhambra 1996 – 2008
