Manual
Com-Server Highspeed
W&T
Release 2.10, October 2006
Type
58631, 58641,
58633, 58031,
58034, 58231,
58431, 58432,
58331, 58334
Com-Server Firmware 1.52 or higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 58034 and is the answer not in the manual?

Questions and answers

Related Manuals for W&T 58034

Summary of Contents for W&T 58034

  • Page 1 Manual Com-Server Highspeed Release 2.10, October 2006 Type 58631, 58641, 58633, 58031, 58034, 58231, 58431, 58432, W&T 58331, 58334 Com-Server Firmware 1.52 or higher...
  • Page 2 W&T © 10/2006 by Wiesemann und Theis GmbH Subject to error and alteration: Since it is posssible that we make mistakes, you mustn’t use any of our statements without verification. Please, inform us of any error or misunderstanding you come about, so we can identify and eliminate it as soon as possible.
  • Page 3 W&T Introduction The Com-Server models 58631, 58641, 58633, 58031, 58034, 58231, 58431, 58432 58331 and 58334 represent a uniform platform for linking serial interfaces such as RS232, RS422/485 to TCP/IP networks. In addition to all the standard applications implemented in...

  • Page 4: Table Of Contents

    Com-Server Highspeed 19“ Com-Server Highspeed OEM 58431 Com-Server Highspeed compact 58231 4 Supply voltage Com-Server Highspeed Industry and Isolated Com-Server Highspeed Industry 58631/UL Com-Server Highspeed Industry PoE Com-Server Highspeed Office Com-Server OEM and compact Com-Server Highpeed 19“ 5 Interfaces and displays...
  • Page 5 W&T Interface for the OEM-Com-Server 58431 Option: 20mA interface Interfaces for the OEM-Com-Server 58432 LED displays 6 Configuration access to the Com-Server Configuration menu structure Configuration via Telnet Configuration via Browser - Web Based Management 6.3.1 Activating WBM with the WuTility-Tool 7 The basis configuration of the Com-Server Saving your settings Menu: INFO System...
  • Page 6 W&T 10.2 The Com-Server as TCP-Client 10.2.1 TCP client mode with fixed destination system 10.2.2 TCP client mode with serial addressing 10.2.3 Optional settings 10.2.4 Deactivating TCP client mode 10.2.5 Application: Client/Server mode between Com-Server-Ports 11 Data transfer per UDP 11.1 The Com-Server as UDP peer 11.1.1 Setting the local UDP port number...
  • Page 7 W&T 16 IP Bus mode 16.1 Function of the IP Bus mode 16.2 Configuring the IP Bus mode 16.2.1 Activating the master 16.2.3 Deactivating IP Bus Mode 17 The Com-Server as SLIP router 17.1 Configuring the SLIP mode 18 Serial Socket Interface 18.1 Serial Socket Interface 19 Status and error messages...
  • Page 8 W&T...

  • Page 9: Quickstart

    W&T Quickstart Already experienced users of Com-Servers will find on the two following pages a flow chart with the essential steps for start-up as well as a complete overview of the configuration menu. Detailed information can be found then in the following sections. Subject to error and alteration...

  • Page 10: Flow Chart - Network Installation Using Wutility

    W&T Flow chart – Network installation using WuTility Network Com-Server Windows PC with TCP/IP Select site WuTility installed? Install WuTility with product CD Com-Server with PoE? Start WuTility Select Connect device in supply voltage inventory list Connect Button: network cable IP address Obtain IP- Enter IP address...

  • Page 11: Overview Of Configuration Menu

    W&T Overview of configuration menu IP-Address INFO System Cable Type MAC address Subnet Mask Gateway Standard Gateway SOFTW Date/REV Route 1 Destination HARDW Rev DNS Server Run Time Route 2 Netmask MTU (560-1460) Route 3 Gateway DHCP Client Route 4 BOOTP Client WBM Port SETUP System...

  • Page 12: Factory Default Settings

    W&T 1.3 Factory Default settings The list contains an overview of the most important settings. For many applications, such as the W&T COM Port Redirector, no additional configurations need to be made besides assigning the network base parameters. Detailed information on the respective parameters can be found in later sections of this manual.

  • Page 13: Assigning The Ip Address

    W&T Assigning the IP address The Com-Server is factory set to IP address 0.0.0.0. Before you can make the entry in the Com-Server, you need to specify an IP address that is valid for your network. You system administrator will provide you with this. If you have only a small network with no routing, use the IP address of your PC and simply change the last digit.

  • Page 14: Configuring Network Parameters With Wutility

    W&T Assigning the IP address Configuring network parameters with WuTility The Windows tool WuTility version 3.0 and higher allows not only inventorying of Com-Server and Web-IO installations, but also convenient assignment of the following network-side basic parameters: • IP address •...
  • Page 15 W&T Assigning the IP address local network for connected W&T network devices and creates an inventory list. This search process can be repeated manually as often as desired by clicking on the Scan button: Within the inventory list you can identify the desired Com-Ser- ver based on its MAC address.
  • Page 16 W&T Assigning the IP address In the following window you can activate the BOOTP client and the Web-Based-Management of the Com-Server. To prevent unintended address assignments or changes, we recommend deactivating the DHCP, BOOTP and RARP protocols if they are not expressly used in the respective network environment.
  • Page 17 W&T Assigning the IP address Changing network parameters is protected by the system password. To prevent improper access, we recommend assigning a system password for any Com-Servers in use. Additional information can be found in the section Configuration Accesses for the Com-Server. Subject to error and alteration...

  • Page 18: Assigning The Ip Using The Arp Command

    W&T Assigning the IP address Assigning the IP using the ARP command This method can only be used if the Com-Server does not already have an IP address, i.e. the entry is 0.0.0.0. To change an IP address, use one of the other methods described in this section or use the configuration menu over Telnet.
  • Page 19 W&T Assigning the IP address The Com-Server takes the IP address of the first network packet sent to it as its own and saves it in non-volatile memory. The Telnet connection will be established and the configuration menu is displayed in the Telnet window. All further settings are made here (see Basic configuration of the Com-Server).

  • Page 20: Serial Assigning Of Ip, Subnet Mask And Gateway

    W&T Assigning the IP address Serial assigning of IP, subnet mask and gateway After a Com-Server reset a time window of around 1-2 seconds is available, during which you can assign a new IP address, subnet mask and gateway address by entering at least 3 „x“.
  • Page 21 W&T Assigning the IP address 2.3.1 Assigning of subnet mask and gateway address Together with the IP address, the subnet mask and gateway address can also be assigned serially. The entry is separated by commas and follows the IP address. Entering as shown in the following example will assign IP address 172.17.231.99, subnet mask 255.255.255.0 and gateway 172.17.231.52 to the Com-Server...
  • Page 22 W&T Assigning the IP address This function can later be reactivated through the Telnet configuration under SETUP System r SETP TCP/IP r BOOTP Client. To prevent unintended address assignments or changes, we recommend deactivating the DHCP, BOOTP and RARP protocols if they are not expressly used in the respective network environment.
  • Page 23 W&T Assigning the IP address For additional information on activating Web Based Management, see section Configuration via Browser Web Based Management. Subject to error and alteration...

  • Page 24: Assigning The Ip Using Dhcp Protocol

    W&T Assigning the IP address Assigning the IP using DHCP protocol Many networks use DHCP (Dynamic Host Configuration Protocol) or its predecessor described in the following section for centralized and dynamic assignment of the network parameters. DHCP protocol is activated by the factory default settings, so that in network environments dynamic IP assignment is sufficient for connecting the Com-Server to the network.
  • Page 25 W&T Assigning the IP address Clicking on Continue then sends the new configuration data to the Com-Server. • Serial port As part of serial IP assignment, the following options for deactivating/activating DHCP and BOOTP can be selected directly following the address string: -0 r Deactivates DHCP and BOOTP -1 r Activates BOOTP/RARP -2 r Activates DHCP...
  • Page 26 W&T Assigning the IP address 2.4.3 Lease-Time The lease time determined and transmitted by the DHCP server specifies the Time-To-Live of the assigned IP address. After half the lease time has expired, the Com-Server attempts to extend the time for the assigned DHCP server and up update the address.
  • Page 27 W&T Assigning the IP address 2.4.4 Reserved IP addresses If the Com-Server is used as a TCP server or UDP peer, it provides services which other clients in the network can also make use of as needed. To open a connection, they of course need the current IP address for the Com-Server, so that in such situations it makes sense to reserve a particular IP address for the Com-Server on the DHCP server.

  • Page 28: Assigning The Ip Using Bootp Protocol

    W&T Assigning the IP address Assigning the IP using BOOTP protocol Many networks use BOOTP as predecessor of DHCP protocol for centralized and dynamic assignment of IP addresses. The factory default setting is for BOOTP turned off. You can activate it from SETUP System r SETUP TCP/IP r BOOTP Client.
  • Page 29 W&T Assigning the IP address each reset. To ensure accessibility of the Com-Server even should the BOOTP server go down, the previous IP address is retained should there be no reply. Subject to error and alteration...

  • Page 30: Assigning The Ip Using A Rarp Server

    W&T Assigning the IP address Assigning the IP using a RARP server UNIX environments especially use RARP protocol for centrally assigning IP addresses. TCP/IP devices that want to obtain an IP address send RARP requests with their Ethernet address as a broadcast over the network.

  • Page 31: Form Factors

    W&T Form factors Industry model Isolated model Office models 19“ models OEM models Compact model Subject to error and alteration...

  • Page 32: Com-Server Highspeed Industry

    W&T Form factors Com-Server Highspeed Industry Front view 58631, 58631/UL, 58641 Error Power Status Serial Port Network Bottom side 58631, 58631/UL, 58641 Screw terminal supply voltage: 12-24V AC/DC (for details see section Supply voltage)

  • Page 33: Com.server Highspeed Isolated 58633

    W&T Form factors Com.Server Highspeed Isolated 58633 Frontview 58633 Serial Port B Serial Port C Error Power Status Serial Port A Network Bottom Side 58633 Screwterminal Supply voltage 12-24V =/~ Subject to error and alteration...

  • Page 34: Com-Server Highspeed Office

    W&T Form factors Com-Server Highspeed Office Front view 58031 Status Power Error Port Serial Port A Com-Server W&T Highspeed Office 10/100 MBit w w w . w u t . d e #58031 Front view 58034 Status Power Error Port Serial Port D Serial Port C Serial Port B...

  • Page 35: Com-Server Highspeed 19

    W&T Form factors Com-Server Highspeed 19“ Port A Port B Port C Port D Power Reset W&T www.wut.de Com-Server #5833x 58331 / 8TE 58334 / 12TE Subject to error and alteration...

  • Page 36: Com-Server Highspeed Oem 58431

    W&T Form factors Com-Server Highspeed OEM 58431 95,8mm 92,13mm 20,38mm D=3,5mm D=3,5mm 17,2mm D=4mm D=3,5mm Optional serial module: RS232/422/485 RS232 RS422/485...

  • Page 37: Com-Server Highspeed Compact 58231

    W&T Form factors 3.6 Com-Server Highspeed compact 58231 Frontview Backview Com-Server #58231 Status Error Power Status LED = standby = error blink = connection flash = data Error LED = OK = check network = check ser. data format = check ser. handshake = self test / update W&T www.WuT.de...
  • Page 38 W&T Form factors...

  • Page 39: Supply Voltage

    W&T Supply voltage Industry and isolated model PoE - Power over Ethernet Office models 19“ models OEM models Compact model Subject to error and alteration...

  • Page 40: Com-Server Highspeed Industry And Isolated

    Com-Server Highspeed Industry and Isolated • Models: 58631, 58633 The supply voltage for models 58631 and 58633 can be brought in on the adjacent screw terminals on the underside of the housing. DC voltage of any polarity or AC voltage may be used.

  • Page 41: Com-Server Highspeed Industry 58631/Ul

    4.2 Com-Server Highspeed Industry 58631/UL • Models: 58631/UL The supply voltage for model 58631/UL is brought in through a screw terminal located on the bottom of the housing. DC voltage of any polarity may be used. The polarity reversal protection results in the following maximum and minimum values for the supply voltage: •...

  • Page 42: Com-Server Highspeed Industry Poe

    W&T Supply voltage Com-Server Highspeed Industry PoE • Models: 58641 The model 58641 Com-Server is designed for use in PoE (Po- wer-over-Ethernet) environments in accordance with IEEE802.3af. Power is provided by the network infrastructure using the RJ45 terminal. The Com-Server supports both phantom power using data pairs 1/2 and 3/6 as well as power feed using the unused wire pairs 4/5 and 7/8.

  • Page 43: Com-Server Highspeed Office

    W&T Supply voltage Com-Server Highspeed Office • Models: 58031, 58034 The office models 58031 and 58034 include an integrated wide-range power supply for an AC voltage of 100-250V/50- 60Hz. Mechanically the connection is made via a cold-device cable. The current draw of each model is indicated in the technical appendix.

  • Page 44: Com-Server Oem And Compact

    W&T Supply voltage Com-Server OEM and compact • Models: 58431, 58432, 58231 58231, 58431 The supply is brought in on a mains receptacle for hollow pin plugs located in the edge of the board. The feed voltage must be 5V ±5%. Pin jack 5,5mm Polarity: inner = GND...

  • Page 45: Com-Server Highpeed 19

    W&T Supply voltage Com-Server Highpeed 19“ • Models: 58331, 58334 The Com-Server Highspeed 19" models get their supply voltage through the 96-pin VG connector: Component side of board Alternat supply voltage also possible through the 6-pin terminal strip, RM 3,96 Jumper area Jumper a Jumper b...
  • Page 46 W&T Supply voltage Pin VG strip Com-Server Standard (all three jum- Jumper pers of row closed) Row 1 +12V VME-Bus J1 Row 2 n.c. +12V VME-Bus J2 Row 3 +12V Multibus II Row 4 +12V ECB Bus Row 5 +12V BUS7ISA For standard operation of the Com-Server only the 5V supply is needed.

  • Page 47: Interfaces And Displays

    W&T Interfaces and displays Ethernet interface Serial interfaces and options LED displays Subject to error and alteration...

  • Page 48: Ethernet Connection

    W&T Interfaces and displays Ethernet connection All Com-Server models incorporate an IEEE 802.3-compatible network interface on a shielded RJ45 connector. The pin assignments correspond to an MDI port, so that the connection to the hub or switch is accomplished using a 1:1 shielded patch cable.
  • Page 49 W&T Interfaces and displays • Both parties (switch and Com-Server) are operated in Auto- Negotiation mode. • Both parties are configured for the same (fixed) transmission speeds and duplex mode. Activating/deactivating Auto-Negotiation Use menu sequence Setup System r Link Speed to switch between Auto-Negotiation and fixed transmission speeds/ duplex mode.

  • Page 50: Rs232/422/485 Combi-Module

    W&T Interfaces and displays RS232/422/485 combi-module Com-Server models 58631, 58633, 58031, 58034, 58331, 58334 and 58231 come standard with an RS232/422/485 multi-port whose modes are described below. The ports on the Com-Server 58633 are also galvanically isolated from each other and with respect to the supply voltage with a dielectric strength of 1kV.

  • Page 51: Mode Selection

    W&T Interfaces and displays 5.2.2 Mode selection Switching between the modes is accomplished using the internal DIL switches located on the respective interface module. The following table shows an overview of all modes: Mode RS232 RS422, RS485 4-wire bus master RS485 4-wire automatic control RS485 2-wire...
  • Page 52 W&T Interfaces and displays Pin assignment and function RS232, DB9 Direction Signal Description Default Funktion (1) (IN) NC/DCD Data carrier 1-port models: Not connected detect 4-port models: Ignored Receive Data Data in Transmit Data Data out Data Terminal 12V for existing TCP Ready connection to a client or server Signal Ground...

  • Page 53: Rs422/485 Mode

    W&T Interfaces and displays 5.2.4 RS422/485 mode As opposed to RS232, an RS422 interface allows transmission distances of up to 1000 meters. The RS485 mode allows you to integrate corresponding 2- or 4-wire bus sytems into a TCP/IP network with the help of the Com-Server. Especially when using longer cable lengths in industrial environments, potential differences need to be taken into consideration.
  • Page 54 W&T Interfaces and displays Modes The DIL switches are used to set the following modes: • RS422, RS485 4-wire bus master Provides one data and handshake channel each in each direction. The RS422/485 drivers and receivers are always active in this mode. •...
  • Page 55 W&T Interfaces and displays Data In B Data In A Wiring examples RS422 connection with hardware handshake Data Out A RxD A (-) Data Out B RxD B (+) Data In A TxD A (-) Data In B TxD B (+) Handshake Out A CTS A (-) Handshake Out B...

  • Page 56: Interface For The Oem-Com-Server 58431

    W&T Interfaces and displays 5.3 Interface for the OEM-Com-Server 58431 The OEM model 58431 has a UART interface that operates at TTL levels, which is implemented on a 2mm square post header. As an option, interface modules for RS232, RS422/ 485 or the multi-port can be connected.
  • Page 57 W&T Interfaces and displays purposes. Applying a GND level for at least 100ms (using a button for example) forces a restart of the Com Server. Subject to error and alteration...

  • Page 58: Option: 20Ma Interface

    W&T Interfaces and displays 5.4 Option: 20mA interface All Com-Servers in the Highspeed series with the exception of model 58633 can be equipped optionally with 20mA interfaces instead of the RS232/422/485 combi-module. The interface can be used as an active or passive 20mA component.
  • Page 59 W&T Interfaces and displays Com-Server Tx and Rx loop active Data Out 20mA RxD + Data Out + RxD - Data In - Data Out GND Data In 20mA TxD + Data In + TxD - Data In - Data In GND Com-Server Tx and Rx loop passive Data Out 20mA RxD +...

  • Page 60: Interfaces For The Oem-Com-Server 58432

    W&T Interfaces and displays 5.5 Interfaces for the OEM-Com-Server 58432 The OEM model 58432 in credit card format has in addition to an RS232 interface with TTL levels an onboard RS485 interface. Both interfaces are located on the 10-pin connector X1 with the locking collar.
  • Page 61 W&T Interfaces and displays The serial TTL interface This interface can be configured as the TTL port of a UART. The solder jumpers must be set as follows: • LB5, LB6 = in • LB7, LB8, LB9 = out The RS485 interface with automatic control The following configuration of solder jumpers establishes a 2-wire RS485 bus connection on pins 7 and 8 of X4.
  • Page 62 W&T Interfaces and displays Basic diagram of the serial interfaces Vcc/5V (internal) Protective circuit RM2,54mm +5V/+24V DSR / A RTS / B GND 24V GND 5V Vcc/5V RS485 330 Ohm Transceiver 330 Ohm...

  • Page 63: Led Displays

    W&T Interfaces and displays 5.5 LED displays • Power LED Indicates supply voltage present. If the LED is not on, check for correct wiring of the power supply. • Status LED Flashes whenever there is activity on the serial port. Periodic flashing indicates that the port has a valid connection to another network station.
  • Page 64 W&T Interfaces and displays All LEDs on = Self-test error The self-test performed after each start or reset of the Com- Server could not be correctly finished. This error can occur when you have prematurely broken off a software update and the full operating sofstware could not be transferred.

  • Page 65: Configuration Access To The Com-Server

    W&T Configuration access to the Com-Server After completing the hardware installation and assigning the IP address, the remaining Com-Server configuration takes place over the network. Here either a Telnet client or, after it has been activated, an Internet browser can be used. Telnet configuration under Windows Configuration with the Internet browser Subject to error and alteration...

  • Page 66: Configuration Menu Structure

    W&T Configuration access to the Com-Server Configuration menu structure The setup of the Com-Server is treelike regardless of whether the configuration is used for a Telnet client or an Internet browser. An overview of all the levels can be found in the following illustration.
  • Page 67 W&T Configuration access to the Com-Server INFO System Cable Type IP-Address Subnet Mask MAC address Gateway Standard Gateway SOFTW Date/REV HARDW Rev DNS Server Route 1 Destination Route 2 Netmask Run Time MTU (560-1460) Route 3 Gateway DHCP Client Route 4 BOOTP Client WBM Port SETUP System...

  • Page 68: Configuration Via Telnet

    W&T Configuration access to the Com-Server Configuration via Telnet A Telnet client comes standard with nearly all operating systems that support TCP/IP protocol. Under Windows 9x/ NT/2000/XP this is normally found in the Windows system directory. The configuration menu for the Com-Server is reached through TCP port 1111.
  • Page 69 W&T Configuration access to the Com-Server *************************** * Com-Server Highspeed * COMSERVER-0A1B2C *************************** 1. INFO System 2. SETUP System 3. SETUP Port 0 (High-Speed Serial) 4. SETUP Port 1 (High-Speed Serial) 5. SETUP Port 2 (High-Speed Serial) 6. SETUP Port 3 (High-Speed Serial) 7.
  • Page 70 W&T Configuration access to the Com-Server The last configured value of a menu item appears in parentheses. If you make changes, the new value will appear at this point the next time the menu is opened. It only becomes If you exit the effective in the Com-Server itself however if you have saved it configuration menu by using SAVE Setup.

  • Page 71: Configuration Via Browser - Web Based Management

    W&T Configuration access to the Com-Server 6.3 Configuration via Browser - Web Based Management The Com-Server also allows configuration via HTTP protocol and a standard Internet browser. The menu structure of the WBM (Web Based Management) is compatible with the Telnet configuration.
  • Page 72 W&T Configuration access to the Com-Server and no handshake. During a reset of the Com-Server hold the x key down until after approx. 2 sec. the IPno.+<Enter>: prompt appears. Now directly following the IP address enter the extended address string +w[Portno.]. Portno. represents here the desired TCP port in decimal format.
  • Page 73 W&T Configuration access to the Com-Server 6.3.3 Activating WBM from the configuration menu If you want to activate WBM on an already operational Com-Ser- ver, you can do this via Telnet configuration. Start a Telnet session on port 1111 of the Com-Server. In the menu branch 2.
  • Page 74 W&T Configuration access to the Com-Server Navigation Since the WBM of the Com-Server is session-oriented, you must use backlinks and corresponding control buttons to navigate to the individual Web pages. Using the Back function in the browser can lead to problems in accepting the set parameters. You can make as many settings as desired during a configuration session.
  • Page 75 W&T Configuration access to the Com-Server The logout page then offers the following possibilities for ending the configuration session: Clicking on the Save button causes the Com-Server to save all the changes you made in its non-volatile memory and quits the configuration session. Clicking on the Abort button causes the Com-Server to reject all the settings you made and quits the configuration session.
  • Page 76 W&T Configuration access to the Com-Server Clicking on the Firmware Update button activates the mode in which the Com-Server expects a firmware update via TFTP protocol (see section Firmware Update of the Com-Server). Update mode can be exited only by complete transmission of a valid firmware or by interrupting the supply voltage.

  • Page 77: The Basis Configuration Of The Com-Server

    W&T The basis configuration of the Com-Server Here follows the explanation of all the configuration possibilities related to the Com-Server operating system and which are not directly related to the serial ports. The arrangement and function of the individual parameters within the menu structure are for the most part identical with Telnet and the Internet browser.

  • Page 78: Saving Your Settings

    W&T The base configuration of the Com-Server Saving your settings When configuring using either Telnet or Web Based Manage- ment, all the changes are first saved only temporarily in the Com-Server. To make sure the settings remain intact even after a reset or power failure, each configuration session must be ended with an explicit save procedure.

  • Page 79: Menu: Info System

    W&T The base configuration of the Com-Server 7.2 Menu: INFO System This menu allows you to call up device-specific parameters such as the version njmber and creation date of the firmware, MAC address of the unit, etc. n Cable type Shows the current Ethernet connection of the Com-Server (10BaseT or 100BaseT).

  • Page 80: Menu: Setup System

    W&T The base configuration of the Com-Server Menu: SETUP System This menu is for configuring all the parameters that pertain to the Com-Server operating system and are independent of the serial interface. 7.3.1 Menu: SETUP System r Setup TCP/IP n IP-Address (Default = 0.0.0.0) Enter here the IP address if you want to change it.
  • Page 81 W&T The base configuration of the Com-Server Changes to the system parameters IP-Address, Subnet Mask, Gateway and Route 1-4 cannot be activated right after saving. The Com-Server will use these values only after closing the current Telnet connection using q. n DNS Server (Default: 0.0.0.0) The entry contains the IP address of the DNS server (Domain Name System).
  • Page 82 W&T The base configuration of the Com-Server To prevent unintended address assignments or changes, we recommend deactivating the DHCP, BOOTP and RARP protocols if they are not expressly used in the respective network environment. n BOOTP Client (Default: 1 = ON) The factory setting is for BOOTP protocol deactivated (menu entry = 0).

  • Page 83: Menu: Setup System R Telnet Password

    W&T The base configuration of the Com-Server Example: A TCP client has opened a connection to TCP server port 8000 of the Com-Server and the network connection is interrupted. After the set keep-alive time plus 2s for two repetitions has elapsed, the Com-Server closes the connection and is again ready for any other clients.

  • Page 84: Menu: Setup System R System Password

    W&T The base configuration of the Com-Server 7.3.3 Menu: SETUP System r System Password The system password, which consists of any 31 (max.) characters, protects against any subsequent configuration and control access to the Com-Server. · 1111: Telnet configuration menu ·...

  • Page 85: Menu: Setup System R System Name

    W&T The base configuration of the Com-Server 7.3.4 Menu: SETUP System r System Name The freely configurable system name consisting of max. 31 characters is used to identify the Com-Server. This name is displayed as an opening message in the client for all Telnet sessions.

  • Page 86: Menu: Setup System R Factory Defaults

    W&T The base configuration of the Com-Server connection. Then it performs a software reset in order to activate the new configuration. Resetting the non-volatile memory causes loss of all the settings which deviate from the default values, including the IP address. 7.3.7 Menu: SETUP System r Reset Select this menu item to perform a software reset on the Com- Server.

  • Page 87: Menu

    W&T The base configuration of the Com-Server 7.4 Menu ... r TCP/IP Mode r System Options In this menu branch you can set specific system parameters. n Network Delay [10ms-Ticks] Default: 0000 This value specifies the minimum delay time of the Com- Server after serial data have arrived.
  • Page 88 W&T The base configuration of the Com-Server n Telnet Echo Default: active When opening a Telnet session, negotiation between the stations takes place on the network side to determine who will generate the echo of the characters sent by the client. Either the client application generates a local echo, or the Telnet server generates a remote echo by immediately returning all received data.

  • Page 89: Configuration Of The Serial Port

    W&T Configuration of the serial port Configuring the serial transmission parameters In addition to the usual settings for baud rate, data bits, parity and stop bits, the various handshake procedures and available special functions of the individual control signals are explained here. Subject to error and alteration...

  • Page 90: The Serial Parameters (Menu: Uart Setup)

    In the submenu Special Baud Divisor you can enter any desired divisor for generating the baud rate. This makes it possible to work even with non-standard baud rates. The baud rate and divisor are calculated using the following formulas: Models 58631, 58431 Divisor= 11,0592*10 Baudrate= 11,0592*10 16*Baudrate...

  • Page 91: The Handshake Modes

    W&T Configuration of the serial port Models 58031, 58034, 58633, 58231, 58331, 58334 Divisor= 7,3728*10 Baudrate= 7,3728*10 16*Baudrate 16*Divisor The currently configured baud rate is displayed when selecting the submenu SETUP Port x (serial) r UART Setup. By allowing any divisor, very high baud rates are possible. Please note in this connection that the upper limit for a bundled data stream is 230.4 kbps.
  • Page 92 W&T Configuration of the serial port n Software Handshake The software handshake is implemented using the two ASCII characters (11H)=XON and (13H)=XOFF. In the standard setting Software Handshake these two codes are considered by the Com-Server as control characters and are filtered out from the actual data flow in both directions.
  • Page 93 W&T Configuration of the serial port n Pin: RTS & Pin: DTR The following functions can be assigned to the outputs RTS and DTR: 1. Flow Control – If this function is turned on, the Com-Server handles the RS232 flow control through the corresponding output.
  • Page 94 W&T Configuration of the serial port 3. Accept only by HIGH – Connection establishment of a TCP client is only accepted if a HIGH level (+3...12V) is present on the corresponding input. Likewise the connection is rejected when there is a LOW level. 4.
  • Page 95 W&T Configuration of the serial port 2. Receive-Filter (Data direction r network) If this option is turned on, the Com-Server interprets the XON and XOFF characters sent by the serial terminal device as control bytes and does not insert them into the network data stream.

  • Page 96: Fifo Send/Rec

    W&T Configuration of the serial port 8.1.3 FIFO Send/Rec The submenu allows the FIFO memory of the serial receive module to turn on and off. Models 58031, 58034, 58231, 58331, 58334 and 58633 also make it possible to set various trigger thresholds.

  • Page 97: The Protocol Stack Of The Com-Server

    W&T The protocol stack of the Com-Server Services of the Com-Server Addressing in the TCP/IP network The serial ports as seen from by network Subject to error and alteration...

  • Page 98: Services Of The Com-Server

    W&T The protocol stack of the Com-Server Services of the Com-Server The actual data are exchanged between the application and the Com-Server port using TCP/IP or UDP/IP. Which protocol is selected and the type of connection (Client or Server) for data transmission depends on the application.

  • Page 99: Addressing In The Tcp/Ip Network

    W&T The protocol stack of the Com-Server 9.2 Addressing in the TCP/IP Network Addressing in the TCP/IP network is done in two steps. FIrst the network station itself is addressed with the IP address, then the services of this network station are addressed with TCP port numbers.

  • Page 100: The Protocol Stack Of The Com-Server

    W&T The protocol stack of the Com-Server The protocol stack of the Com-Server There are several possibilities for transporting serial interface data. The Com-Server port supports the standard protocols FTP and Telnet. It also allows you to transport the data on the so- cket interface level directly as TCP streams or UDP datagrams - inother words, without any additional higher-order protocol.
  • Page 101 W&T The protocol stack of the Com-Server sockets (streams) or UDP sockets (datagrams). The following comparison shows the essential features of both protocols at a glance. The Com-Server provides both of the protocols possible on the socket level for data transfer: Client/server process with TCP sockets (streams) or UDP sockets (datagrams).
  • Page 102 W&T The protocol stack of the Com-Server...

  • Page 103: Data Transfer Per Tcp/Ip Sockets

    W&T 10 Data transfer per TCP/IP sockets The most direct way to exchange data with a serial device connected to the Com-Server is via TCP sockets. This is especially useful in cases where communication needs to be integrated into your own programs. Comparable to traditional telephony, TCP connections always consist of an active, calling side (=Client) and a passive, call-answering side (=Server).

  • Page 104: The Com-Server As Tcp Server

    W&T Data transfer per TCP/IP sockets 10.1 The Com-Server as TCP server TCP is a connection-based protocol, i.e. during data transmission there is a fixed connection between client and server. TCP possesses all the mechanisms for opening and closing a connection and ensuring errorless data transfer over the network.

  • Page 105: Optional Settings

    W&T Data transfer per TCP/IP sockets It must be noted that only one TCP client at a time can be connected to the serial port of the Com-Server. If there is already a connection, any attempt from another client is rejected until this first connection has been properly closed or ended by means of a reset.
  • Page 106 W&T Data transfer per TCP/IP sockets Keep Alive Time If this function is activated, then if there is no data traffic the Com-Server checks during the set time interval to see whether the connected network application can be reached. If there is no reply, for example due to a break in the network infrastructure, the Com-Server resets the connection internally and thus enables a new connection to be opened.

  • Page 107: The Com-Server As Tcp-Client

    W&T Data transfer per TCP/IP sockets 10.2 The Com-Server as TCP-Client In contrast to the passive TCP server mode, in TCP client mode the Com-Server independent4ly opens connections to a TCP server located in the network. The destination IP address and destination port number needed for this can either be stored in the configuration or sent serially to the Com-Server before the actual user data.

  • Page 108: Tcp Client Mode With Fixed Destination System

    W&T Data transfer per TCP/IP sockets 10.2.1 TCP client mode with fixed destination system The submenu SETUP Port x r TCP/IP Mode r TCP Client is where the connection data for the desired TCP server are configured. n Server Port Port number that the application (TCP server process) addresses on the computer.
  • Page 109 W&T Data transfer per TCP/IP sockets Closing the TCP connection To close the connection the following methods from the Sub- menu ...TCP Client r Special Options are available. If connection control is configured using the handshake inputs CTS or DSR, the connection is also closed when this line drops.
  • Page 110 W&T Data transfer per TCP/IP sockets reset. To prevent unintended loss of data, make this value sufficiently large. Connection Timeout = 0 deactivates resetting of the connection after a timeout. 1 Tick: 1 second Format: decimal...

  • Page 111: Tcp Client Mode With Serial Addressing

    W&T Data transfer per TCP/IP sockets 10.2.2 TCP client mode with serial addressing In this mode the address data for the server are not permanently configured, but rather transmitted serially to the Com-Server as an ASCII string in front of the actual data. This makes it possible to open connections to changing TCP servers.

  • Page 112: Optional Settings

    W&T Data transfer per TCP/IP sockets Opening the TCP connection If serial addressing is used, the Com-Server waits to receive a valid address string. Any data arriving prior to receipt of a valid addressing are rejected. Closing the TCP connection As with using fixed destination parameters, the connection can be closed using the options Inactivity Timeout and Disconnect Char .
  • Page 113 W&T Data transfer per TCP/IP sockets n Response Mode Default: deactive In Response Mode the application is informed of the network-side connection status of the Com-Server in the serial terminal device by the output of special characters. This function is only available in TCP client mode. The following messages are output on the serial port: C (connected) The connection was successfully opened.

  • Page 114: Deactivating Tcp Client Mode

    W&T Data transfer per TCP/IP sockets 10.2.4 Deactivating TCP client mode Set the following parameters in the menu branch SETUP Port x r TCP/IP Mode r TCP Client to a value of 0 and save this change: ... r Server Port ...
  • Page 115 W&T Data transfer per TCP/IP sockets Serial addressing (Parameter Client: „C“+Addr) also makes chan- ging connections between multiple Com-Server ports possible. In this case the addressing must be generated by the serial devices. Example 1: A control program polls a measuring device; the measuring device is passive.
  • Page 116 W&T Data transfer per TCP/IP sockets Example 3: A control program polls multiple measuring devices; the measuring devices can (e.g. in case of error) independently send data to the control program. Intranet / Internet Configuration menu: r TCP/IP Mod r TCP-Client Com-Server A - Server Port: 8000 - Server IP: IP address Com-Server B...

  • Page 117: Data Transfer Per Udp

    W&T 11 Data transfer per UDP Instead of TCP, communication with the serially connected devices can also take place via UDP. This method offers several advantages over TCP when the data are secured already within a serial protocol in creating your own software.

  • Page 118: The Com-Server As Udp Peer

    W&T Data transfer per UDP 11.1 The Com-Server as UDP peer UDP is a connection-less and unsecured datagram service. During data transmission there is no fixed connection between the communicating network stations. Datagrams are addressed to the destination in the network without there being any reply referencing the success or failure of the sending.

  • Page 119: Setting The Local Udp Port Number

    W&T Data transfer per UDP 11.1.1 Setting the local UDP port number To send a UDP datagram to the Com-Server, the sender needs the IP address of the Com-Server as well as its UDP port number on which the data are received. Access to the serial port on the Com-Server per UDP takes place through the port specified in the menu Setup Port 0 r TCP/IP Mode r Local Port.

  • Page 120: Udp Clientmode With Fixed Destination System

    W&T Data transfer per UDP 11.1.2 UDP clientmode with fixed destination system In the Submenu SETUP Port x r TCP/IP Mode r UDP Client the address data of the desired UDP destination system are configured. All arriving serial data are sent in UDP datagrams to the configured destination system.

  • Page 121: Udp Client Mode With Serial Addressing

    W&T Data transfer per UDP 11.1.3 UDP client mode with serial addressing In this node the address data of the destination system are not permanently configured, but rather sent serially to the Com-Ser- ver as an ASCII string before the actual user data. This makes it possible to make connections to changing UDP servers.
  • Page 122 W&T Data transfer per UDP n Disconnect Char Default: 0 This parameter is only processed if the parameter Client: "C"+Addr is activated. If the Com-Server receives the character configured here at its serial port, it deletes the last serially received UDP server address. The character itself is not sent.

  • Page 123: Optional Settings

    W&T Data transfer per UDP 11.1.4 Optional settings The following optional settings in the Submenu ...UDP Client r Special Options allow you to activate and deactivate various special functions. These apply to fixed as well as serial addressing. n Dispatch Str. 1 & Dispatch Str. 2 Default: 0000H This mode allows compact sending of serial data to the network;...

  • Page 124: Deactivating Udp Mode

    W&T Data transfer per TCP/IP sockets n Special Options r Write "C"+Addr Default: deactive Set this switch to active (1) to output the sender address in ‚ASCII format before outputting the data for a UDP datagram to the serial port. The string always contains 22 characters. C IP address, Port_number (e.g.

  • Page 125: The Windows Com Port Redirector

    W&T 12 The Windows COM port redirector With the COM Port Redirector available for Windows 9x, NT, 2000 and XP, the virtual COM ports are installed in the respective system. These behave in a serial application exactly like normal local ports, but are actually located on Com-Servers located in the network.

  • Page 126: Virtual Com Ports

    W&T The Windows COM redirector 12.1 Virtual COM ports The latest version of the COM Port Redirector as well as addi- tional tools, application descriptions and FAQs can always be downloaded from our Web site. http://www.wut.de The simplest way to navigate from there is by using the menu tree on the left side of the page.
  • Page 127 W&T The Windows COM redirector Com-Server settings Startting with the factory default setting of the Com-Server only the 3 network-specific parameters IP Address, Subnet Mask and Gateway Address need to be configured for operating with the COM Port Redirector. It is not necessary to set the serial transmission parameters such as baud rate.
  • Page 128 W&T The Windows COM redirector...

  • Page 129: Box-To-Box Mode

    W&T 13 Box-to-Box mode In „Box to Box“ mode any two Com-Server serial ports can be logically linked to each other over the network. The two connected serial terminal devices are in constant online contact in this mode. Typical applications Configuration of Box-to-Box connections Subject to error and alteration...

  • Page 130: Box-To-Box Mode

    W&T Box-to-Box mode 13.1 Box-to-Box mode This mode is based on a permanent TCP connection between two serial ports on Com-Servers distributed in the network. One of these ports acts as the master, the other as slave, though is essentially makes no difference which device is acting as master or slave.

  • Page 131: Configuring Box-To-Box Mode

    W&T Box-to-Box mode 13.1.1 Configuring Box-to-Box mode Only the Master port is configured for „Box to Box“ mode; The Slave IP address and Slave port number are set only on the Master port! Settings in the Special Options submenu and parameterizing of the serial port can and must be done on both ports (see examples at the end of this section).

  • Page 132: Optional Settings

    W&T Box-to-Box mode 13.1.2 Optional settings n Sepecial Options r Dispatch Str. 1 & Dispatch Str. 2 Default: 0000H This mode allows compact sending of serial data to the network; the serial data stream is not broken down randomly, rather serial packets can be transferred over the network in their original context as a packet.
  • Page 133 W&T Box-to-Box mode 13.1.4 Sampleconfiguration for Box-to-Box mode Box-to-Box Master Box-to-Box Slave IP address: 172.16.231.5 IP address: 172.16.231.8 Port number of Port A: 8000 Port number of Port A: 8000 SETUP Port 0 SETUP Port 0 TCP/IP Mode TCP/IP Mode Box to Box Box to Box Slave Port...
  • Page 134 W&T Box-to-Box mode...

  • Page 135: Data Transfer Per Ftp

    W&T 14 Data transfer per FTP The FTP, which is based on TCP, is a standard protocol for file transmission. In the mode as FTP server an FTP client can send files to the Com-Server whose contents are sent to the serially connected device. In the other direction, serial data arriving at the Com-Server from the FTP client can be written to a file.

  • Page 136: The Com-Server As Ftp Server

    W&T Data transfer per FTP 14.1 The Com-Server as FTP server This mode should be used if the data to be sent exist as files and the action will always be pre-settings on the Com-Server are necessary for this mode. You can access the unit just like any other station in the network under its name or IP address.
  • Page 137 W&T Data transfer per FTP Example: GET 5 /user/cs_in (breaks the connection off after 5 seconds of no data traffic) For the exact syntax of your function invocations, please consult the user‘s manual for your FTP software. n ASCII Send in ASCII mode n IMAGE Send in binary mode n QUIT...

  • Page 138: The Com-Server As Ftp Client

    W&T Data transfer per FTP 14.2 The Com-Server as FTP client This mode enables access to files on any TCP/IP computer having an activated FTP server. The action must always be initiated by the serial terminal device. The address of the FTP server (Port number and IP address) must in any case be configured in the Com-Server.
  • Page 139 W&T Data transfer per FTP Once you have entered all the parameters in the Com-Server port menu, press the ENTER key several times to return to the main menu and save the entries with SAVE Setup. The message Saving... appears, then the FDP client mode is activated. The entry FTP-Client now appears in the SETUP Port x r Port State r Connection State menu.
  • Page 140 W&T Data transfer per FTP 14.2.2 The automatic FTP client mode This mode is recommended whenever you need to execute the same command over and over again. The FTP commands are configured in the Com-Server. The latter opens a connection to the FTP server when it receives data at the serial port.
  • Page 141 W&T Data transfer per FTP If a command sequence was already configured, it is shown when opening the menu. A maximum of 80 characters are available for all commands! Commands are case sensitive. Once you have entered all the parameters in the Com-Server port menu, press the ENTER key several times to return to the main menu and save the entries with SAVE Setup.
  • Page 142 W&T Data transfer per FTP n Protocol Char Default: 0 If the Com-Server receives the character defined here at the serial port, the connection to the FTP server is closed. The character itself is not sent. Default value is 0. Disconnect Char = 0 deactivates this mode.
  • Page 143 W&T Data transfer per FTP 14.2.3 FTP client with serial protocol This mode is recommended where constantly changing commands with different files need to be executed and where terminal entry is possible or there is a programmable serial device. FTP commands for the FTP client TYPE A or I Activation of ASCII or binary mode...
  • Page 144 W&T Data transfer per FTP occurrence of the protocol character in the data stream will be ignored. The only possibility for a disconnection in this case is by way of an inactivity timeout. Format: decimal Once you have entered all the parameters in the Com-Server port menu, press the ENTER key several times to return to the main menu and save the entries with SAVE Setup.

  • Page 145: Deactivating Ftp Client Mode

    W&T Data transfer per FTP Closing teh FTP connection As with fixed login parameters, the connection can be closed using the options Inactivity Timeout and Disconnect Char. De- tails can be found in section Automatic FTP-Client mode. 14.2.4 Deactivating FTP client mode Set the following parameters in the menu branch SETUP Port x r TCP/IP Mode r FTP Client to a value of 0 and save this change:...
  • Page 146 W&T Data transfer per FTP Example 2: User egon having the password happy wants to output the file /etc/hosts in ASCII format. The value „003“ (Ctrl C) is entered as Protocol Char. The protocol would look as follows: Com-Server Serial device egon<lf>happy<lf>TYPE A<lf>RETR /etc/hosts<lf><Ctrl C>...

  • Page 147: Data Transfer Per Telnet

    W&T 15 Data transfer per Telnet Telnet is a terminal emulation protocol. Data transmission is character- oriented. Telnet allows bi-directional character exchange between the TCP/ IP computer and the serial terminal device connected to the Com-Server. Com-Server as Telnet server Configuring the Com-Server as FTP client Subject to error and alteration...

  • Page 148: Com-Server As Telnet Server

    W&T Data transfer per Telnet 15.1 Com-Server as Telnet server No pre-settings are necessary on the Com-Server. You can access the device just like any other station in the netowrk under its name or IP address. The port numbers under which the Com-Server makes its FTP service available are fixed and cannot be configured: Default port numbers: •...

  • Page 149: The Com-Server As Telnet Client

    W&T Data transfer per Telnet 15.2 The Com-Server as Telnet client This mode is the simplest way to implement terminal emulation on a serial terminal device and thereby to effect direct communication with the TCP/IP station on which the Telnet server is active.
  • Page 150 W&T Data transfer per Telnet Opening the Telnet connection After saving the connection data the Com-Server waits to receive any serial character. This is the trigger for opening the connection. Closing the Telnet connection To close the Telnet connection, use the following methods available in the Submenu ...Telnet Client r Special Options.

  • Page 151: Optional Settings

    W&T Data transfer per Telnet 15.2.1 Optional settings n Serial 0D->0D00 Default: 0 If this switch is activated, an 00H is appended to the serially received character 0DH: in other words, 0DH 00H is sent over the network. This option may have to be activated for sending binary files.
  • Page 152 W&T Data transfer per Telnet...
  • Page 153 W&T 16 IP Bus mode Several serial Com-Server ports can be logically linked together over the network in the form of a Master-Slave bus. The connected serial terminal devices are in constant online contact in this mode. Any additional data traffic or other network protocols have no effect on the connection.

  • Page 154: Function Of The Ip Bus Mode

    W&T IP Bus mode 16.1 Function of the IP Bus mode The following sketch shows the Master-Slave principle of IP-Bus mode. The Com-Server configured as a master sends all received serial data via broadcast into the network. All Com- Servers configured as slaves receive these data and pass them on to the connected serial devices.

  • Page 155: Configuring The Ip Bus Mode

    W&T IP Bus mode 16.2 Configuring the IP Bus mode You may not configure the IP Bus mode in the same Telnet session in which the IP address, the subnet mask or the gateway address for the Com-Server was already changed. After you make such serttings you must first close the Telnet connection using „q“...

  • Page 156: Deactivating Ip Bus Mode

    W&T IP Bus mode 16.2.3 Deactivating IP Bus Mode Set the respective IP address in the SETUP Port x r TCP/IP Mode r IP Bus Mode menu to zero (0.0.0.0), or use the menu SETUP Port x r Port State r Clear Port Mode. The Connection State in the Submenu SETUP Port x r Port State must then be named FREE.

  • Page 157: The Com-Server As Slip Router

    W&T 17 The Com-Server as SLIP router SLIP router mode enables serial devices with their own TCP/IP stack to be incorporated into an Ethernet. When the Com-Servers are used in pairs, remote Ethernet segments can also be integrated into the main network in this mode using a serial standard cable.

  • Page 158: Configuring The Slip Mode

    W&T SLIP router mode 17.1 Configuring the SLIP mode In this mode the Com-Servers functions as a router. All network packets whose destination address is within the configured subnet are routed over the serial interface using SLIP. All arriving serial SLIP packets are passed along to the local Ethernet network.
  • Page 159 W&T SLIP router mode The following sketch shows the various ways of processing the IP packets depending on the SLIP-Net Routing parameter. 192.1.1.12 172.16.231.2 172.16.231.1 Ethernet Com Server RS232 172.16.231.3 Packet frame: Ethernet IP datagram SLIP IP datagram ..r SLIP Router r Net Address = 192.1.1.0 / r SLIP-Net Routing = 1 ping 172.16.231.1 ping 192.1.1.12 ..r SLIP Router r Net Address = 192.1.1.12 / r SLIP-Net Routing = 0...
  • Page 160 W&T SLIP router mode 17.1.2 Application example Connecting two IP networks over serial cable In SLIP router mode paired use of two Com-Servers allows two IP/Ethernet networks to be connected over a serial RS232/422 cable. The prerequisite is that the two networks must belong to different IP networks.
  • Page 161 W&T SLIP router mode 17.1.3 Configuring the Com-Server via SLIP It is possible to open a UDP connection for configuring some Com-Server parameters through the serial connection between the Com-Server and the connected SIP computer. The SLIP packets must be directed to the IP address 10.0.0.1 and UDP port 1111.
  • Page 162 W&T SLIP router mode Packet types (byte TYPE) The following three packet types are used for sending configuration data: • TYPE = 1: Writing parameters in the Com-Server This packet is sent by the SLIP computer to the Com-Server. The Com-Server carries out the configuration and deletes the packet.

  • Page 163: Serial Socket Interface

    W&T 18 Serial Socket Interface The Serial Socket Interface enables defined communication between Com- Servers and the device connnected to their serial port. Analogous to the TCP/IP socket interface in Windows or UNIX systems, it provides the end user with an external TCP/IP stack on the serial port while supporting up to eight logical client and/or server sockets.

  • Page 164: Serial Socket Interface

    W&T Serial Socket Interface 18.1 Serial Socket Interface The Serial Socket Interface enables defined communication between Com-Servers and the device connnected to their serial port. Analogous to the TCP/IP socket interface in Windows or UNIX systems, it provides the end user with an external TCP/IP stack on the serial port while supporting up to eight logical client and/or server sockets.

  • Page 165: Status And Error Messages

    W&T 19 Status and error messages Status messages of the menu Port State Resetting a fixed mode: Clear Port Mode Subject to error and alteration...

  • Page 166: Menu Setup Port X R Port State

    W&T Status and error messages 19.1 Menu Setup Port x r Port State In this menu you will find information about the configured TCP/IP mode of the Com-Server port, the status of the network connection and a listing of error which occured. In addition, Clear Port Mode can be used to clear a fixed set mode.
  • Page 167 W&T Status and error messages n Error State This list shows the errors which occured on the port. If more than five errors have occured since the Com-Server was last reset or since the last time the error table was cleared, the oldest entry is always overwritten.
  • Page 168 W&T Status and error messages „Parity Error“ A character received on the serial port has an incorrect or missing parity bit. Please check that the transmission parameters for the Com Server and the corresponding serial terminal device are the same. Parity errors can also be caused by use of excessively long cable.

  • Page 169: Expanded Services Of The Com-Server

    W&T 20 Expanded services of the Com-Server In the preceding sections we explained all the standard processes that are implemented in the Com-Server. These client/server processes cover the majority of the application possibilities for the Com-Server. Implementati- on of more complex scenarios often requires however that the software be individually adapted.

  • Page 170: The Control Port

    W&T Expanded services of the Com-Server 20.1 The control port The TCP client and TCP server processes for sending data to the serial port of the Com-Server do not allow influencing the serial port itself. But some applications make it necessary that the status and configuration of the port be known and capable of being changed at all times.
  • Page 171 W&T Expanded services of the Com-Server message PASSWD? followed by a null byte (0x00) to the client and closes the TCP connection. If no system password is configured you can, as described below, begin with the exchange of info structures as soon as the TCP connection has been established.
  • Page 172 W&T Expanded services of the Com-Server The info structure has a fixed length of 30 bytes and is comprised of the following individual structures: #pragma pack(1) //packs the structure components into 1-byte limits typedef struct _rem_box_cntrl char zero_1; COM_ERROR _ce; COM_STAT _cs;...
  • Page 173 W&T Expanded services of the Com-Server } COM_ERROR; Structure COM_STAT The COM_STAT structure has a length of three WORDS (16-bit integer) and contains the status of the handshake lines as well as the number of bytes which are in the send and receive buffers of the serial port.
  • Page 174 When creating the break signal, a distinction between the various Com-Server models needs to be made as follows: n 58631, 58431 With these models, break mode is first set using set_break. Then with each following serial character to the data connection the Com-Server sends a baud rate- dependent BREAK signal (approx.
  • Page 175 // 0 = 8 / 8 // 1 = 16 / 16 // 2 = 32 / 56 // 3 = 56 / 60 // models 58631 and 58431 have a fix FIFO // trigger so they ignore these bits char bits; //000x.xxxx...
  • Page 176 W&T Expanded services of the Com-Server struct _commands unsigned char save_command :4; //Save COM-Configuation //0 = no save //1 = save without EEPROM Update //2 = save with EEPROM Update unsigned char clear_error :1; //1 = clear error in display/lamps unsigned char set_fact_def :1;...
  • Page 177 W&T Expanded services of the Com-Server 2) To work with the configuration, the value save_command in the structure has to be set. "save_command = 2" causes the Com-Server to save this configuration in non-volatile memory and to use it again after a restart. A 1 does not overwrite the non-volatile memory, i.e.

  • Page 178: Reset Com-Server-Port

    W&T Expanded services of the Com-Server 20.2 Reset Com-Server-Port For special applications this port makes it possible to carry out a forced reset of the Com-Server port: The parameters for the current connection are deleted, and the current connection partner (host) is notified by means of a TCP/IP RST. TCP port numbers: •...
  • Page 179 W&T Expanded services of the Com-Server If no system password is configured, then as the example shows the Com-Server immediately closes the TCP connection as soon as it has been established and performs a port reset. When invoking this service, the contents of the serial in- and output buffer are lost.

  • Page 180: Software Reset Of The Com-Server

    W&T Expanded services of the Com-Server 20.3 Software reset of the Com-Server Socket 8888 has been implemented in case the Com-Server ever needs to be completely reset. If a connection is opened on this port, the Com-Server immediately closes it again and then performs a software reset.

  • Page 181: Uploading/Downloading Configuration Data

    W&T Expanded services of the Com-Server 20.4 Uploading/downloading configuration data (Port numbers 8003/read, 8004/write) These services allow you to read out the configuration data for the Com-Server stored in the non-volatile memory and send it to another Com-Server. Especially when installing a large number of Com-Servers having the same settings this methjod eliminates having to open a Telnet configuration connection for each individual unit.
  • Page 182 W&T Expanded services of the Com-Server Writing configuration data on port 8004 Uploading to a Com-Server is analogous to reading out the configuration data. After opening a TCP connection to Port 8004 of the Com-Server, the latter expects the 1024 bytes for a new configuration.

  • Page 183: Inventory Taking Per Udp/8513

    W&T Expanded services of the Com-Server 20.5 Inventory taking per UDP/8513 Larger installations often require that an inventory be taken of all the Com-Servers currently in the network. This can be done using UDP Port 8513. After receiving a network packet directed to this port, the Com-Server replies to the respective sender with an info packet.
  • Page 184 W&T Expanded services of the Com-Server #pragma pack(1) typedef struct _BOX_VERSION // ( 10 byte ) unsigned int version; // 0x10: 1.0 (Version of this structure) unsigned int sw_rev; // z.B. 1.24 (0x1501) unsigned int hw_rev; // C2_EURO = 2.0 (0x0002) // C3_PC104 = 3.0 (0x0003) // C4_MINI...
  • Page 185 W&T Expanded services of the Com-Server typedef struct _WT_INTERN3 // ** all parameters in Hostorder / Low Byte First ** BOX_VERSION // Port = UDP_BOX_INFO_8513 BOX_DESCRIPT bd; PORT_DESCRIPT pd[ACT_PROCESS]; } WT_INTERN3; #pragma pack() All variables of types Integer and Long are mapped in host order, i.e.

  • Page 186: Snmp Management

    W&T Expanded services of the Com-Server 20.6 SNMP management Many networks are managed through a central network management system via SNMP protocol. A full description of the Management Information Base (MIB) of the Com Server would exceed the limits of this Manual. Documentation including the ASN.1 file is available for downloading at our Web site.

  • Page 187: Firmware Update Of The Com-Server

    W&T 21 Firmware update of the Com-Server Since the operating software is under constant develpoment, this device also allows you to perform a firmware update. The available upload variations are described here. Where do I get the current firmware? Network firmware update unter Windows Network firmware update under UNIX Subject to error and alteration...

  • Page 188: Where Do I Get The Current Firmware

    W&T Firmware update of the Com-Server 21.1 Where do I get the current firmware? The most current firmware including update tools and a revision list is published on our Web site at the following address: http://www.wut.de From there it is easiest to navigate using the Search function located on the left side.

  • Page 189: Network Firmware Update Under Windows

    W&T Firmware update of the Com-Server 21.2 Network firmware update under Windows Required is a PC running Windows 9x/NT/2000/XP with a network connection and activated TCP/IP stack. For the update process you need two files which, as already mentioned, are available for download from our Web site at http://www.wut.de.

  • Page 190: Network Firmware Update Under Unix

    W&T Firmware update of the Com-Server 21.3 Network firmware update under UNIX Required is a computer with a network connection and a TCP/IP stack that provides Telnet and TFTP network protocols. When updating with TFTP protocol the firmware is split into 6 files that are send to the Com-Server one after the other.
  • Page 191 W&T Firmware update of the Com-Server Example: SCO UNIX Enter the following commands after the corresponding prompt: # tftp tftp> connect [ip_number|host_name] tftp> binary tftp> put Cxr1_1.4_1 [remote filename] (remote filename = any letter) Now wait until the green Status LED comes on again. Then use the put command to send the remaining files, and close the TFTP connection.
  • Page 192 W&T Firmware update of the Com-Server...

  • Page 193: Appendix

    W&T Appendix TCP/IP activation under Windows Overview of the port numbers Example: Serial assignment of the IP address under Windows Web applications HTTP,SMTP, POP3 ... Technical Data Subject to error and alteration...

  • Page 194: Tcp/Ip Under Windows 9X

    W&T Appendix TCP/IP under Windows 9x To activate TCP/IP you need a computer having a network card and Windows 9x. TCP/IP is bundled with Windows 9x, so it only needs to be configured for the local network. • O b t a i n a v a l i d I P a d d r e s s f r o m y o u r n e t w o r k administrator.

  • Page 195: Tcp/Ip Under Windows Nt

    W&T Appendix TCP/IP under Windows NT To activate TCP/IP you need a computer having a network card and Windows NT. TCP/IP is bundled with Windows 9x, so it only needs to be configured for the local network. • O b t a i n a v a l i d I P a d d r e s s f r o m y o u r n e t w o r k administrator.

  • Page 196: Used Ports And Network Security

    W&T Appendix Used ports and network security The port numbers factory set in the Com-Server: Password Port number Application protection? Configurable? 6000, 23 (TCP) Telnet server port A 6100 (TCP) Telnet server port B 6200 (TCP) Telnet server port C 6300 (TCP) Telnet server port D 7000, 21 (TCP)
  • Page 197 W&T Appendix Each port number may be used for just one service in the Com-Server. If differing numbers are used for changeable ports, be sure that these are not assigned in duplicate. The Com-Server and network security Network security has rightly taken on added significance in recent times.
  • Page 198 W&T Appendix VPN tunnel (Virtual Private Network) should be taken. This is however a general issue for network security for which each customer must find the appropriate solutions. Ports with special functions In addition to access over Telnet or Web Based Management, there are a variety of functions which can be activated over various TCP or UDP ports.
  • Page 199 W&T Appendix the TCP ports 8003 and 8004 used for this are protected by the system password. • Com-Server Reset and Port Reset (see section on Reset Com-Server-Port and Reset the Com- Servers) The TCP ports 8888, 9084, 9184, 9284 and 9384 allow for resetting of fixed modes of a port and for fully r e s e t t i n g t h e C o m - S e r v e r .

  • Page 200: Serial Assignment Of The Ip Address Under Windows

    W&T Appendix Serial assignment of the IP address under Windows Serial assigning of the IP address and even the subnet mask and gateway address can be done using the free mini-termi- nal program „Easyterm“, which has been optimized especially for this task. Alternately of course you can use any other ter- minal program such as that included with Windows or Hyper- terminal as described here.
  • Page 201 W&T Appendix Now turn the Com-Server on and off to reset it and while it is starting up hold down the „x“ key (lower case, no Caps Lock!). After about 2-3 seconds the prompt IP no.:+<ENTER>: will appear in the terminal window. Now enter the IP address you want to assign in the usual dot notation (e.g.
  • Page 202 W&T Appendix Hyperterminal To serially assign the IP address you can also use Hyper- terminal, which is bundled with Windows. Start this procedure under Start r Programs r Accessories r Hyper- terminal. 1.) In the first window you assign a name for the connection you wish to build.
  • Page 203 W&T Appendix 3.) The transmission parameters are 9600 baud, 8 data bits, no parity, no protocol: 4. After you have confirmed the settings with OK, you will find yourself in the actual terminal window. All keyboard entries are output thorugh the selected COM port. Now turn the Com-Server on and off to reset it and while it is starting up hold down the „x“...

  • Page 204: Web Application Http, Smtp, Pop3

    W&T Appendix Web application HTTP, SMTP, POP3 ... TCP/IP protocol is the basis for all applications used inthe Internet. As in the case for example of HTTP, SMTP or POP3 these are often relatively simply constructed, non-time critical ASCII protocols which are sent within the TCP data range.
  • Page 205 W&T Appendix RS232 control line (see Configuring the RS232 parameters (Menu: UART Setup)) or using a timeout (see TCP Client mode (Menu: TCP Client)). For additional information and examples for integrating your own serial devices into the Web using the Com-Server, see our Web site at http://www.wut.de.

  • Page 206: Wutility - Inventory And Management Tool

    W&T Appendix WuTility - Inventory and management tool In Windows environments the WuTility Tool can also be used for inventory and management of Com-Server installations. Pressing a button lists all the Com-Servers located in the local network together with their key data. Following are the most interesting functions which can be run directly from the list: Assigning the IP address, even if the currently set address does not fit in the local network...

  • Page 207: Hardware Reset To Factory Defaults

    W&T Appendix Hardware reset to factory defaults In addition to resetting the Com-Server to its factory defaults using the Telnet configuration (Port 1111), this can also be done via hardware. For this purpose all models have two adjacent jumpers on the board. For normal operation these jumpers must be out.

  • Page 208: Technical Data

    W&T Appendix Technical Data Com-Server Highspeed Industry 58631 Supply voltage ..DC 12V - 48V (+/-10%) ... AC 9Vrms - 30Vrms (+/-10%) AC adapter 18V/300mA included in scope of delivery Supply voltage UL version ..DC 12V - 24V (+/-10%)
  • Page 209 W&T Appendix Com-Server Highspeed Isolated 58633 Supply voltage ..DC 12V - 48V (+/-10%) ... AC 9Vrms - 30Vrms (+/-10%) Current draw typ. 130mA @24V Permissible ambient temperatur ..storage -40 ... +70°C ... operating, non-cascaded 0 ... +60°C ...
  • Page 210 W&T Appendix Com-Server Highspeed PoE 58641 Supply voltage ... Power over Ethernet 37 - 57V from PSE External supply..DC 12V - 48V (+/-10%) ... AC 9Vrms - 30Vrms (+/-10%) Current draw typ. 130mA @24V PoE Class 1 (0,44 - 3,84W) Permissible ambient temperatur ...
  • Page 211 W&T Appendix Com-Server Highspeed Office 58031, 58034 Supply voltage 100-250V /50-60Hz with cold-device cable Current draw approx. 3,5W Permissible ambient temperature ..storage -20 ... +60°C ... operating 0 ... +50°C Permissible relative humidity 0 - 95% (not condensing) Network 10/100BaseT, RJ45 for STP cables Galvanic isolation...
  • Page 212 W&T Appendix Com-Server Highspeed 19“ 58331, 58334 Supply voltage DC 5V +/-5% Current draw ... 58331 typ. 320mA @5V 58334 typ. 360mA @5V Permissible ambient temperature ..Lagerung -40 ... +70°C ... Betrieb 0 ... +60°C Permissible ambient humidity 0 - 95% (not condensing) Network 10/100BaseT, RJ45 for STP cables...
  • Page 213 W&T Appendix Com-Server Highspeed OEM 58431 Supply voltage DC 5V +/-5% Current draw typ. 250mA, max. 325mA @5V Permissible ambient temperature ..storage -40 ... +70°C ... operating 0 ... +60°C Permissible relative humudity 0 - 95% (not condensing) Network 10/100BaseT, RJ45 for STP cables Galvanic isolation...
  • Page 214 W&T Appendix Com-Server Highspeed Compact 58231 Supply voltage ... DC 5V +/-5% Current draw typ. 270mA, max. 345mA @5V Permissible ambient temperatur ..storage -40 ... +70°C ... operating 0 ... +50°C Permissible relative humidity 0 - 95% (not condensing) Network 10/100BaseT, RJ45 for STP cables Galvanic isolation...

  • Page 215: Declaration Of Conformity

    W&T Appendix Declaration of conformity Subject to error and alteration...

  • Page 216: Index

    W&T Index Index Factory Default 12 Factory Defaults 86 Symbole factory defaults 207 2-wire bus 54 FIFO 96 20mA interface 58 Firmware update 85 4-wire bus 54 firmware update 189 fixed routes 80 flashing patterns Flow Control 93 APPE 140 Flush Buffer 88 ASCII 137 Framing Error...
  • Page 217 W&T Index Network Delay 87 TCP Client 108 No halt on XOFF/RTS/DTR 167 Technical Data NO Handshake 92 Telnet Echo 88 Telnet Password Terminating TYPE A 140 Overrun Error TYPE I 140 parity 90, 175 UDP 100 Parity Error 168 UDP port number 119 parity error 63 Password...

Table of Contents

Save PDF
