Manual
Web-IO Analog-In
W&T
Type
Model
Release
10/100BaseT, 12-24V
57641, 57642, 57643
1.4, Jan 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 57641 and is the answer not in the manual?

Questions and answers

Related Manuals for W&T 57641

Summary of Contents for W&T 57641

  • Page 1 Manual Web-IO Analog-In Type 10/100BaseT, 12-24V Model 57641, 57642, 57643 W&T Release 1.4, Jan 2008...
  • Page 2 W&T © 01/2008 by Wiesemann & Theis GmbH Microsoft, MS-DOS, Windows, Winsock and Visual Basic are registered trademarks of the Microsoft Corporation Subject to errors and modifications: Since we can make mistakes, none of our statements should be taken without verification. Please inform us of any mistakes or misunderstandings you notice so that we can become aware of them and remedy them as quickly as possible.

  • Page 3: Introduction

    W&T Introduction The W&T Web-IO Analog-In models incorporate all the functions in one box for capturing, storing and displaying your analog measurements (0...20mA or 0...10V). A variety of alarm functions is also available which can be custom implemented in your own applications or in existing systems. This manual contains all the information you need for installing, configuring and operating the Web-IO Analog-In module.

  • Page 4: Table Of Contents

    W&T Table of Contents Introduction .................... 3 1 Quick Start-up ..................6 1.1 Connecting the supply voltage ........6 1.2 Connecting the measurement lines ........6 1.3 Assigning the IP address using „WuTility“ ......8 1.4 IP assignment using DHCP protocol ........ 10 1.4.1 Activating/deactivating DHCP ........
  • Page 5 W&T 3.14 ASCII command strings via UDP ........56 3.15 UP-/Download ............. 57 4 Individual querying of measured values ....... 59 4.1 Querying via TCP/IP ............59 4.2 Querying via UDP ............59 4.3 Querying via SNMP ............60 5 Java Applets - Auto-updating in the browser ....62 5.1 Working with the Java applet ..........

  • Page 6: Quick Start-Up

    W&T 1 Quick Start-up It takes only a few steps to start up the Web-IO Analog-IN module and make it visible in your network. 1.1 Connecting the supply voltage Connect 12-24V AC/DC to the terminal provided using the plug-in power supply included. Polarity is uncritical. 1.2 Connecting the measurement lines Error I+ GND...
  • Page 7 : Current input 0..20mA U+ : Voltage input 0..10V GND : Ground Please note when wiring the inputs that they use the same GND internally. 1.2.2 Pin configuration 57641 Web-IO Analog-In 0..20mA / 0..10V 1.2.3 Pin configuration 57642 Web-IO Analog-In 2x 0..20mA 1.2.4 Pin configuration...

  • Page 8: Assigning The Ip Address Using „Wutility

    W&T 1.3 Assigning the IP address using „WuTility“ Once the hardware has been connected to the supply voltage as described above, you must assign the IP address needed for operation in a TCP/IP network. You can obtain the correct value for this parameter from your system administrator.
  • Page 9 W&T Click on the „IP address“ symbol: In the resulting window enter the desired network parameters for the device and confirm by clicking on „Continue“. The BOOTP client of the Web-IO Analog-In can be activated in the following window. Clicking on the Continue button assigns the network parameters to the Web-IO Analog-In.

  • Page 10: Ip Assignment Using Dhcp Protocol

    W&T 1.4 IP assignment using DHCP protocol Many networks use DHCY (Dynamic Host Configuration Protocol) or its predecessor BOOTP described in the following section for centralized, dynamic assignment of network parameters. By default DHCP protocol is activated, so that in network environments with dynamic IP assignment you only need to connect the Web-IO Analog-In to the network.

  • Page 11: System Name

    W&T In the following dialog window deactivate the options BOOTP and DHCP. Click on Next to send the new configuration data to the Web-IO Analog-In. • Web Based Management In Config r Device r Basic Settings r Network you can alternately activate or deactivate both the protocols.

  • Page 12: Lease Time

    W&T 1.4.3 Lease time The lease time determined and sent by the DHCP server specifies how long the IP address will remain in use. After half the lease time has expired the Web-IO Analog-In attempts to extend the time for the assigning DHCP server and to update the address.

  • Page 13: Reserved Ip Addresses

    W&T 1.4.4 Reserved IP addresses The Web-IO Analog-In provides services which can make use of other clients in the network as needed. To open a connection they of course need the current IP address of the Web-IO Ana- log-In, so that in these applications it makes sense to reserve a particular IP address for the Web-IO Analog-In on the DHCP server.

  • Page 14: Assigning The Basic Network Parameters

    W&T 1.5 Assigning the basic network parameters In the configuration tree at left click on „Config“. You are now prompted to enter a password. The factory default setting is for no password, so that you can simply click on the Login button without entering a password.
  • Page 15 W&T The device now automatically displays the necessary menu points for this profile. Click on „Network“ in the configuration menu.
  • Page 16 W&T On the following page enter all the necessary network parameters and when you are finished click on the „Logout“ button. Then clicking on the „Save“ button saves the settings in the device and closes your configuration session. After the network parameters have been changed the device automatically restarts itself.

  • Page 17: Graph Display Of The Measurements

    W&T 2 Graph Display of the Measurements 2.1 Basic functions The device provides a table of the current values and a graph of the stored values. By using the control buttons at the bottom of the page you can do the following. Scroll the graph to right or left by the size of the display interval, to within one unit.
  • Page 18 W&T Zooms back to the previous zoom level. A c t i v a t e s a u t o m a t i c r e f r e s h i n g o f the graph. Refreshes the display Opens the configuration menu beneath the graph...

  • Page 19: Config Menu

    W&T Design and positioning of the graph is configurable. 2.2 Config menu...
  • Page 20 W&T The following functions are available from the configuration menu beneath the graph: Start: Here you specify the starting time for the X-axis. End: Here you specify the ending time for the X-axis. Polling Rate: Enter here the desired refresh rate for the graph. The device provides a new value no sooner than after 4 seconds.

  • Page 21: Table

    W&T 2.3 Table This function is used to show the currently represented values in table format. As soon as not all stored values can be displayed, the following values are shown in the table for each sensor: Max: The maximum value in the displayed interval Min: The minimum value in the displayed interval Ø: The average value of the displayed interval...

  • Page 22: Additional Basic Settings

    W&T 3 Additional basic settings 3.1 Configuring the port and device names 3.1.1 Text Enter your personal descriptions in the field provided and then click on „Send“.
  • Page 23 First enter a name and a descrptive text for the port and select the measuring range to calibrate the input circuit to your measuring location (for models 57641, 57642 only: measuring range 0..20mA or 4..20mA). To deactivate the port, select „Disconnect“.

  • Page 24: Local Time Setting

    W&T 3.2 Local time setting 3.2.1 Time zone Here you define the time zone in which the device is located. The settings refer to UTC (Coordinated Universal Time ). Then click on „Send“.
  • Page 25 W&T 3.2.2 Summer time If you want your unit to automatically switch to daylight savings time, first enter the offset to UTC. The standard value (for Germany etc.) is two hours. Activate this function by selecting „Apply Summertime“ and buffer store the settings („Send“). Start/Stop Define when daylight savings time begins and ends.
  • Page 26 W&T 3.2.3 Device Clock If you choose not to use a timeserver, this allows you to set the clock manually. Then click on „Logout“ and save your settings.

  • Page 27: Automatic Time Setting Using A Networjk Time Service

    W&T 3.3 Automatic time setting using a network time service 3.3.1 Time Server If you want to adjust the time using a time server, enter here the necessary information. The preset addresses are just an example and do not necessarily have to be used.

  • Page 28: Configuring The Data Logger

    W&T If you enter a name as the address, be sure that you first have configured the Gateway and DNS server so that the device can resolve the addresses. Click on the „Logout“ buitton and save your settings. 3.4 Configuring the data logger 3.4.1 Select Make the following settings: Timebase: Defines at what time interval the measured data are...
  • Page 29 W&T Attention: If you change Timebase Timebase Timebase Timebase Timebase or Select Sen- Select Sen- Select Sen- Select Sen- Select Sen- sor the memory will be erased completely. 3.4.2 Clear Clicking on the „Clear memory“ button deletes the entire contents of the data logger.

  • Page 30: Configuring The Graphics Display

    W&T 3.5 Configuring the graphics display 3.5.1 Basic Settings...
  • Page 31 W&T Enable: Auto scroll enable: After opening the graphical representation, the measured values are automatically refreshed. The control buttons are not available when using the Auto Scroll function. Show table: Shows the current values in table format as well. Show graph: Activates graph representation of the measured values.

  • Page 32: Select Sensor

    W&T Frame Color: Enter here the desired color for the border of the graph, or select a color from the color selector below: Background Color: Select here the color for the background of the graph. This color is also used as a background for the table.
  • Page 33 W&T Graphics Selection: You can set the following parameters for each sensor: Activate/deactivate Sensor X: (Checkbox selected/deselected) Sensor Color: Enter the desired sensor color, or use the color selector to choose. Show extreme values: If a zoom level is selected in the graph in which a display point represents a measuring interval and not an individual measuring point, this function is used to display the maximum and minimum measured in this interval.

  • Page 34: Scale Config

    W&T 3.5.3 Scale Config Scale: The graph can display four different scales. Each individual scale can be assigned the following parameters: unit: The unit used for this scale. min: The lowest displayed value on this scale max: The highest displayed value on this scale auto scale: The lower and upper values for this scale are selected automatically based on the measured values, so that an optimal, dynamic display is achieved.

  • Page 35: Calibration

    W&T 3.6 Calibration You can calibrate the port with the help of single-point, two- point reference measurements and corresponding offset value entries. In single-poing compensation the entered value is added to the measured value, whereas in two-point compensation a straight line is calculated for compensating the entire measuring range.
  • Page 36 W&T Config: If you want the measured value to correspond to a certain physical quantity (e.g. 10mA corresponds to 50hPa), you can configure the display value for 0% to 100% of the measuring range including the associated unit. This configuration is used for all outputs.

  • Page 37: Browser Access

    W&T 3.7 Browser access 3.7.1 HTTP Startup: Here you specify which HTML page should be displayed when the device starts up.

  • Page 38: E-Mail Alarms

    W&T HTTP Port: You can use this port to access the device. The default setting is the standard HTTP Port 80. If you would like to use a different port, it may have to be explicitly indicated when the page is opened: http://webio:<PortNr>...
  • Page 39 W&T The e-mail function allows you to forward an information or alarm mail to one or more e-mail or SMS recipients. Name: Enter here the name that should appear as the sender. ReplyAddr: This is the reply address with which the device identifies itself.
  • Page 40 W&T mail.provider.de:476 Authentication: If the mail server requires authentication, set here the corresponding procedure for user identification. SMTP authentication off: No authentication ESMTP: A user name and password are required for logging in to the mail server. SMTP after POP3: For an SMTP access it is necessary to first make access using POP3 so that the user can be identified.
  • Page 41 W&T 3.8.2 Alarm X Here you configure the desired alarm conditions.
  • Page 42 W&T Trigger: Here you define the trigger for the alarm e-mail. Multiple selections are allowed. To send a message wihtout an alarm condition, check only the „Timer“ box. Min./Max.: Specifies the lower and upper limit. The range within these limits is considered „valid“. Hysteresis: You can also specify a hysteresis value based on which the alarm status is reset.
  • Page 43 W&T Delay Time: Triggering of the alarm is delayed by this time (in minutes) for momentary limit violations. Interval: Enter here the send interval (in minutes) at which a message should be sent assuming the alarm function is enabled. If you want to send just a single message, enter here an „E“. Timer: This timer interval is based on the CRON service such as is used in Linux/Unix systems.
  • Page 44 W&T 3.8.3 Alarm X -> Mail The actual content of the e-mail is selected under this menu item. E-Mail-Addr: Enter here the e-mail address of the recipient. To send the e-mail to multiple recipients, separate the addresses from each other with a semicolon. Subject &...
  • Page 45 W&T W&T tag value Function comma spelling dot spelling (##.####) (##,####) Measurand 1: Displays the <M1> <m1> value for channel 1. Measurand 2: Displays the <M2> <m2> value for channel 2. W&T tag date + time Displays the actual time and <Z>...

  • Page 46: Snmp Incl. Alarm Sending Via Trap

    W&T 3.9 SNMP incl. alarm sending via Trap Sending alarm messages as an SNMP trap. 3.9.1 Basic Settings -> SNMP Here you define the basic settings needed for SNMP operation. Community String: Read: Use this string to read the configuration in your SNMP manager. Community String: Read-Write: Use this string to both read and write the configuration in your SNMP manager.
  • Page 47 W&T Cold Start: When power is disconnected/fails. Warm Start: At device reset. SNMP Enable: To use the SHMP functionality, check this box. 3.9.2 Alarm X -> SNMP The actual contents of the SNMP trap is specified under this menu item.
  • Page 48 W&T Manager IP: Contains the IP address of your SNMP manager. The SNMP messages from the W&T unit are sent to this address. Trap Text: Specifies the text of the trap. In this text field the following tags will be also accepted. The device exchanges these tags with the actual values.

  • Page 49: Sending Alarms Via Tcp (Client Mode)

    W&T 3.10 Sending alarms via TCP (Client Mode) Send alarm messages as a TCP packet. 3.10.1 Alarm X -> TCP: IP Addr: The IP address where you want the message sent. Port: The recipient must have a TCP server service on this port which can accept incoming connections.

  • Page 50: Sending Alarms Via Ftp (Client Mode)

    W&T 3.11 Sending alarms via FTP (Client Mode) Write the measured values to an FTP server.
  • Page 51 W&T 3.11.1 Basic Settings -> FTP Here you will find the basic settings needed for FTP operation. FTP Server IP: Enter here the IP address or the host name of the FTP server yhou want to send the data to. FTP Control Port: This is the port needed for the connection.
  • Page 52 W&T 3.11.2 Alarm X -> FTP FTP Local Data Port: This is the local data port on the Web- Thermo-Hygrograph. Values between 1 and 65536 are permitted. Entering „AUTO“ causes the device to select the port dynamically. File Name: Enter here the path to the file you want the device to access.
  • Page 53 W&T W&T tag value Function comma spelling dot spelling (##.####) (##,####) Measurand 1: Displays the <M1> <m1> value for channel 1. Measurand 2: Displays the <M2> <m2> value for channel 2. W&T tag date + time Displays the actual time and <Z>...

  • Page 54: Sending Alarms Via Syslog

    W&T 3.12 Sending alarms via Syslog IP Addr: This is the IP address you want the message sent to. Port: On the receiver end there must be a Syslog server service on this port which can accept incoming connections (Standard: 514).

  • Page 55: Ascii Command Strings Via Tcp Port 80

    W&T 3.13 ASCII command strings via TCP Port 80 3.13.1 HTTP When queried by an HTTP Get command, the device can also send a header with IP address and name of the device along with the measured value. To enable this, check the corresponding box. If this function is deactivated, only the measured value is sent.

  • Page 56: Ascii Command Strings Via Udp

    W&T 3.14 ASCII command strings via UDP In addition to TCP/IP commands the device can also reply to UDP datagrams. For this the port which the device is supposed to „listen“ to must be set. The default setting is 42279. The enable function turns UDP on.

  • Page 57: Up-/Download

    W&T 3.15 UP-/Download In the Download area yo can download the XML configuration as well as the three user pages (home.htm, user.htm, log.htm) for further processing. With XML download you can read out the Web-IO Analog-In settings, make any changes and save them to the device using XML Upload.
  • Page 58 W&T The individual options and parameters correspond to the configuration items in the browser menu. Please note, especially when carrying out mass updates orconfigurations, the IP address stored in the XML file isalways sent also, and that it must first be set accordingly.

  • Page 59: Individual Querying Of Measured Values

    W&T 4 Individual querying of measured values 4.1 Querying via TCP/IP It is possible to use a socket connection for manually querying the current measurements in CSV format (comma separated data). This function as well is used for querying the single data without the Web interface.

  • Page 60: Querying Via Snmp

    <IP-Address> 1.3.6.1.4.1.5040.1.2.10.1.3.1.1.2 = Measured value 1 as octet string. <IP-Adresse> 1.3.6.1.4.1.5040.1.2.10.1.4.1.1.2 = Measured value 2 als Integer-Wert in tausendstel, ohne Kommatrennung. The IDs for the different device types are: #57641: 1.3.6.1.4.1.5040.1.2.10... #57642: 1.3.6.1.4.1.5040.1.2.11... #57643: 1.3.6.1.4.1.5040.1.2.12... Use the configured SNMP-Read or Read/Write-Community for the query.
  • Page 61 W&T Entering the administrator password in the variable wtWebGraphAnalogIn57641SessCntrlPassword opens a session. By reading out the variable wtWebGraphAnalogIn57641SessCntrlConfigMode you can check whether the session was successfully opened. 1 = Session opened, device in configuration mode. 0 = Opening of the session failed. Check whether the password was incorrectly entered if a password has been assigned.

  • Page 62: Java Applets - Auto-Updating In The Browser

    W&T 5 Java Applets - Auto-updating in the browser Visualizing states int he browser based on pure HTTP or HTMP allows only a snapshot. What is displayed is the status at the time the Web page was opened. The only way to see a state change is to reload the complete Web page.
  • Page 63 W&T width="0" declaration in Pixel height="0" declaration in Pixel Since the applet does not contain a visual component, width and height should always be 0. mayscript This option allows the Java applet to use JavaScript code in the HTML document. In addition, several other Web-IO-specific parameters can be set, each of which is inserted in its own <param>...

  • Page 64: Using The Applet With Javascript

    W&T Here is an example: <applet name="Analog" archive="A.jar" code="A.class" codebase="http://192.168.0.5" width="0" height="0" mayscript> <param name="device" value="0"> <param name="showerrors" value="off"> <param name="sensorpolling" value="on"> <param name="pollingrate" value="500"> </applet> Both the parameters and the values are case-sensitive. 5.2 Using the applet with JavaScript To be able to work with the applet, a corresponding JavaScript function must be declared in the header of the Web page.
  • Page 65 W&T Please note that the function name is case-sensitive. The following source text shows a short example for dynamic display of Port 0. <html> <head> <script language="JavaScript" type="text/javascript"> <!-- function sensorChanged( iDevice, iSensor, iVal ) if (iSensor == 0 && iDevice == 0) { document.getElementById( 'port' + iSensor ).firstChild.data = iVal;...
  • Page 66 W&T A more detailed example for use of the Java applet can be found on the Web page app.htm, which can be opened in the Web-IO. Open: http://<ip-adresse>/app.htm...

  • Page 67: Data Logger

    W&T 6 Data Logger The Web-IO Analog-In stores all them measured values in a fixed ring memory, so that they are still intact even after a power loss or after pressing the Reset button. The measuring data in the data logger are obtained through the user page of the device (Home ->...

  • Page 68: Appendix

    W&T 7 Appendix 7.1 Alternate IP address assignment 7.1.1 Using DHCP-/BOOTP protocol Many networks use DHCP (Dynamic Host Configuration Protocol) or BOOTP for centralized and dynamic assigning of the IP addresses. It makes no difference to the Web-IO devices which of the two protocols is used in any given case, since DHCP is simply a downward compatible extension of BOOTP.
  • Page 69 W&T Please consult your system administrator when starting up the device in DHCP/BOOTP networks. If the address is assigned using DHCP, you must also indicate that a reserved IP address is required. To integrate this into the respective address database, the administrator needs the Ethernet address of the device, which can be found on the housing sticker.
  • Page 70 W&T arp -s <IP-Adresse> <MAC-Adresse> e.g. under Windows: arp -s 172.0.0.10 00-C0-3D-00-12-FF e.g. under SCO UNIX: arp -s 172.0.0.10 00:C0:3D:00:12:FF Then ping the device again (in our example ping 172.0.0.10). The IP aeddress is now stored in the non-volatile memory. This method can only be used if no other IP address has already been assigned to the device, i.e.

  • Page 71: Example For Creating Your Own Web

    W&T 7.2 Example for creating your own Web pages You can freely configure the standard display pages of the device (user.htm, home.htm, log.htm). Special control elements can be inserted into the page using tags. In the following you will find an example for creating the page „user.htm“. Create an HTML page which must begin with the expression <user.htm>...
  • Page 72 W&T <w&t_tag=bc1> describes a backgrouind color (BGColor) that varies with the alarm state of the first port. If there is a limit violation, this color is red. Otherwise the tag does not describe an explicit color. This tag is used for example to show limit violations in red in the log table. <w&t_tag=bc2>...
  • Page 73 W&T Example for setting a background color in a table: <tr> <td colspan="3" align="center"> <table border="2"> <tr> <th><w&t_tags=sensor1></th> </tr> <tr> <td <w&t_tags=bct>><w&t_tags=m1> mA</td> </tr> </table></td> </tr> The measured value is highlighted in red when there is a limit violation. To specify the output format for the data, insert the following line into your document: <form action="log.htm"...
  • Page 74 W&T Example for user.htm: <user.htm> <html> <head> <title>Untitled Document</title> <meta http-equiv="Content-Type" content="text/html; charset=iso-8859-1"> </head> <body bgcolor="#FFFFFF" text="#000000"> <p>Web-IO Analog-In</p> <p>Time: <w&t_tags=time></p> <p><w&t_tags=sensor1>: <w&t_tags=m1></p> <p>&nbsp;</p> <form action="log.htm" method="POST"> <p>Output data logger:</p> <p><w&t_tags=steps></p> <p><w&t_tags=ok_button></p> </form> <form action="logger.csv" method="POST"> <p>Output CSV:</p> <p><w&t_tags=steps></p> <p><w&t_tags=ok_button></p> </form>...
  • Page 75 W&T This page is displayed by the Web-IO Analog-In in the Web browser as follows:...
  • Page 76 W&T Example for log.htm: <log.htm> <html> <head> <title>Untitled Document</title> <meta http-equiv="Content-Type" content="text/html; charset=iso-8859-1"> </head> <body bgcolor="#FFFFFF" text="#000000"> <form action="log.htm" method="POST"> <w&t_tags=previous_button> </form> <w&t_tags=logtable> <form action="log.htm" method="POST"> <w&t_tags=next_button> </form> </body> </html>...
  • Page 77 W&T This page is displayed by the Web-IO Analog-In in the Web browser as follows:...

  • Page 78: Firmware Update

    W&T 7.3 Firmware update The operating software for the Web-IO Analog-In is being constantly enhanced. The following section describes how to upload the firmware when new versions become available. . Where do I obtain the current firmware? . Firmware update over the network under Windows 7.3.1 Where do I obtain the current firmware? The most up to date firmware version including the available update tools and a revision history are published on our Web...
  • Page 79 W&T No special preparation of the device is needed for the firmware update. The WuTility used for the update recognizes all WuT devices located in its network and is for the most part self-explanatory. If you do have questions or if anything is unclear, please refer to the accompanying documentation or try our online help.

  • Page 80: Led Indicators

    W&T 7.3.3 LED indicators ■ Power-LED: Indicates the presence of supply voltage. If the LED is not on, please check for proper connection of the power supply. ■ Status-LED: Flashes whenever there is network activity. The Web-IO Analog-In is not receiving a link pulse from a hub or switch.
  • Page 81 W&T Auxiliary-LEDs (internal) ■ on error http://xxx.xxx.xxx.xxx/diag -LED: Indicates internal configuration errors. For diagnostic information open page http://xxx.xxx.xxx.xxx/diag in the device. ■ system error: Serious hardware error. Try restarting the device by interrupting turning power off and on. If the problem persists, return the unit for service.

  • Page 82: Technical Data

    W&T 7.4 Technical Data Prod. No.: 57641, 57642, 57643 Current input: 0..20mA, 100Ohm (57641, 57642) Voltage input: 0..10V, 1MOhm (57641, 57643) Network: 10/100BaseT autosensing Power supply: 12-24V AC / DC via terminal screw Measurement unit Resolution: Current input: 2µA, Voltage input: 1,20mV Measuring error: max.

  • Page 83: Declaration Of Conformity

    W&T 7.5 Declaration of Conformity...
