Summarization of Contents
Safety instructions
Hazard levels
Defines DANGER, WARNING, and NOTICE terms indicating hazard severity for safe operation.
Safety symbols
Explains standard safety symbols like warning, prohibition, and compulsory action for user safety.
Safety during operation and maintenance
Outlines safety precautions for operating and maintaining the machine, including safety zones.
Safety devices and functions of the base machine
Lists safety devices and functions that trigger alarms and stop the machine, and protect it from damage.
Periodic inspection of safety devices
Details periodic inspection of safety devices like light beams, E-stops, service doors, hydraulic/pneumatic systems, and warning labels.
Technical information, E5/E6/E8
Notes on technical information
Provides explanations and clarifications for various technical specifications and parameters listed in the manual.
Operating description of turret punch press
Misuse of the machine
Details prohibited uses and modifications of the machine to ensure safe operation and prevent damage.
Main structure of the machine E5
Machine axes
Describes the linear and rotating axes of the machine, including options for specific functions like tapping and upforming.
Coordinate table
Explains the function and control of the coordinate table for sheet movement in X and Y directions.
Turret
Details the 20-station turret, its protection, tool holders, and service door access.
Clamps
Describes the pneumatic central locking system of the clamps and their programmable positioning.
Brush tables
Explains the function of brush tables in damping vibration and noise, and their interaction with sheet support rollers.
Punching mechanism, E machines
Details the servomotor-driven punching mechanism, stroke adjustment, and forming capabilities.
Control centre
Describes the components housed in the control centre, including NC control, servo amplifiers, and computer.
Auto-index system
Explains the auto-index system for automatic tool rotation in the working position according to NC control.
Standard tool system Thick Turret
Introduces the standard Thick Turret (AM) system, its tool holders, and details clamp protection areas and dimensions.
Control desk (Siemens)
Identifies and describes the components of the Siemens control desk, including touch screen, buttons, and keyboard.
Control panel (Siemens)
Details the Siemens control panel functions, including mode selection, machine function keys, and axis selection.
Remote control panel
Explains the functions of the remote control panel, including emergency stop, safety light beams reactivation, and cycle start.
Using the machine
Starting the machine and emergency stop
Provides step-by-step instructions for starting the machine and the procedure for emergency stops.
Production order run
Guides the user through selecting and starting a production order, including tool checks and mode selection.
Production run control
Explains how to control production runs, including interrupting, restarting, stopping, and continuing programs.
Production run after emergency stop
Details the procedure after an emergency stop, including identifying the reason, making remedies, and restarting.
Shutting down the machine in a normal situation
Outlines the correct steps for safely shutting down the machine during normal operations.
Turret rotation
Describes how to manually rotate the turret, including operational conditions and safety notes.
Mounting a tool on the turret
Details the process of mounting and removing tools, including die installation, necessary tools, and safety precautions.
Operating modes
Explains operating modes (JOG, MDA, AUTO), JOG mode use, MDA/AUTO modes, feed rate control, and program control buttons/keys for machine operation.
Preventive maintenance
E5 maintenance points
Illustrates and lists key maintenance points on the E5 machine for routine checks.
E5/E6/E8 weekly maintenance
Details the weekly maintenance tasks required for E5, E6, and E8 models, covering cleaning and checks.
E5/E6/E8 monthly maintenance
Outlines the monthly maintenance procedures for E5, E6, and E8 models, including lubrication and component checks.
Compact Express, monthly maintenance / LD, monthly maintenance
Lists monthly maintenance tasks for Compact Express and LD models, focusing on checks of pneumatic systems and rollers.
Recommended lubricants
Provides a comprehensive list of recommended oils, greases, and fluids for various machine components.
SU3/SU6C/SU9 sorting unit (option)
Technical data SU3/SU6C/SU9
Presents technical specifications for SU3, SU6C, and SU9 sorting units, including sorting addresses and pallet sizes.
Control panel
Describes the SU sorting unit's control panel, including components, manual mode operation, safety circuit reset, and automatic mode activation.
Sorting unit addresses
Specifies the sorting addresses for SU3, SU6C, and SU9 units used in automatic mode with NC programs.
