Instructions - Parts
Communications
Gateway Module
For use with Graco Control Architecture based systems to provide fieldbus
communications capabilities.
Important Safety Instructions
Read all warnings and instructions in the system
operation manual. Save these instructions.
4003764
Conforms to
UL Std. 508
Certified to CAN/CSA Std.
C22.2 No. 14
312864B
TI11985A
Advertisement
Table of Contents
Related Manuals for Graco CGMPN0
Summary of Contents for Graco CGMPN0
- Page 1 Instructions - Parts Communications Gateway Module 312864B For use with Graco Control Architecture based systems to provide fieldbus communications capabilities. Important Safety Instructions Read all warnings and instructions in the system operation manual. Save these instructions. TI11985A 4003764 Conforms to UL Std.
-
Page 2: Table Of Contents
Technical Data ......11 Graco Standard Warranty ....12 Graco Information . -
Page 3: Component Identification
TI11985A Fieldbus Connectors Table (C) DeviceNet PROFINET PROFIBUS EtherNet/IP TI11814A TI11815A TI11816A . 1: Key: Communications Gateway Module Base Fieldbus Connector Module Connection Screws Access Cover Module Status LEDs Fieldbus Status LEDs (see descriptions on page 6) CAN Connectors 312864B... -
Page 4: Overview
Installation Data Exchange The CGM is available for use with all Graco Control Data is available by block transfer, cyclic transfer, Architecture based systems that have compatible change of state triggered, and explicit access to individ- design. -
Page 5: Setup
This may take up to 10 seconds. TI12319A NOTE: The rotary switch (S) has no function for the CGM. 5. Remove token (T). Store in a safe place. 6. Replace access cover (E). 312864B... - Page 6 Station Name not set Set Station Name via system monitor Red (4 flashes) Major Internal Error Cycle system power; replace module Link/Activity (Link) State Description No Link, no communication present Green Link established, no communication present Green, flashing Link established, communication present 312864B...
- Page 7 Controlled by a Scanner in Run state Flashing Green Not configured, or Scanner in Idle state Major fault (EXCEPTION-state, FATAL error etc.) Flashing Red Recoverable fault(s) LINK/Activity (Link) State Description No link, no activity Green Link established Flashing Green Activity 312864B...
- Page 8 Unrecoverable Fault(s) Flashing Red (1 Hz) Recoverable Fault(s) Alternating Red/Green Self test DeviceNet Connector (DC) Signal Description Negative bus supply voltage CAN_L CAN low bus line SHEILD Cable shield CAN_H CAN high bus line Positive bus supply voltage 312864B...
- Page 9 Request to send GND Bus Ground (isolated) +5V Bus Output +5V termination power (isolated) A Line Negative RxD/TxD, RS485 level Housing Cable Shield Internally connected to the Anybus protective earth via cable shield filters according to the PROFIBS standard. 312864B...
-
Page 10: Troubleshooting
Verify that you are using the correct token for your system type and rein- Incorrect data map for fieldbus type stall token. If installation fails, order No data map loaded new token. The red LED (F) will flash a code, pause, then repeat. 312864B... -
Page 11: Parts
15V762 MODULE, Gateway, PROFINET; CGMPN0 only 289697 Base 114135 SCREW, mounting, module connec- tion 277674 COVER, access Technical Data Category Data Power requirements 12-30 VDC @ 0.2 A Weight 12.8 oz. Dimensions 4.3 in. x 3.8 in. x 3.8 in. 312864B... -
