Summarization of Contents
PREPARING THE DEVICE
UNPACKING
Steps for opening the box and checking contents.
INSTALLATION OF BATTERIES
Guide on how to properly insert AA batteries for power.
MicroSD, USB AND HDMI PORTS
Location and use of data and power ports.
FIRMWARE UPDATE
Instructions for updating the device firmware for optimal performance.
ON/OFF
Procedure for powering the device on and off.
USING KEYPAD
Explanation of how to use the device's keypad for navigation and functions.
FOCUSING
Steps for adjusting diopter and objective lens for clear focus.
MOUNTING YOUR SCOPE
Instructions on how to securely attach the scope to a firearm.
COMPASS CALIBRATION
Process for calibrating the internal compass for accurate readings.
INTERFACE
HOMESCREEN
Overview of the main display elements: scales, status bar, and widgets.
SHORTCUT CAROUSEL
Accessing quick shortcuts for various device features and functions.
USING SYSTEM SETTINGS
Navigating the System Settings menu for configuration and adjustments.
FUNCTIONS
PHOTO MODES
Explains different modes for capturing still images (Single, Burst, Time Lapse).
RECOIL ACTIVATED VIDEO
How to automatically record video triggered by weapon recoil.
RANGEFINDER
Using the smart rangefinder to determine target distance.
DISTANCE ENTRY
Manually inputting or adjusting target distance for calculations.
ENVIRONMENT
Inputting environmental data for enhanced ballistic accuracy.
HOW TO PERFORM A NUC
Procedure to improve thermal image quality by compensating for sensor variations.
PIXEL CORRECTION PROCEDURE
Guide to correct unresponsive pixels in the field of view.
ZEROING
ZERO RETICLE
Step-by-step process to align the reticle with the point of impact.
SYSTEM SETTINGS
THERMAL
Adjustments for thermal image properties like contrast and sensitivity.
PHOTO/VIDEO
Settings for photo modes, burst count, time lapse, and microphone.
DISPLAY
Configuration options for screen brightness and display widgets.
PROFILES/ZERO
Managing shooting profiles, zeroing data, and device settings.
SETTINGS
Device-wide settings including units, date/time, connectivity, and firmware.
SERVICING
CLEANING EYEPIECE
Instructions for cleaning the eyepiece and micro display.
WARNINGS AND CAUTIONS
MOBILE APPLICATIONS
Using the ATN Obsidian app to control the device and manage data.
