ULTIMATE SPEED KH 3017 Operation And Safety Notes

H YDrAULIC CAr JACK
7
6
A
KH 3017
H YDrAULIC CAr JACK H IDrAVLIČNA DVIgALKA
Operation and Safety Notes zA AVTOMOBILE
N avodila za upravljanje in varnostna opozorila
H IDrAULIČNA D IzALICA zA VOzILA
U pute za posluživanje i za Vašu sigurnost
4 C
Hydraulic car jack KH 3017
1
2
Introduction
Q
These operating instructions form a part of this product. Make
yourself familiar with all the operating instructions and safe-
ty advice for the product before use. Use the product only as
3 described and for the indicated purpose. If you pass the product on to
anyone else, please ensure that you also pass on all the documentation
with it.
Q Proper use
Intended use:
The hydraulic car jack is designed for lifting and lowering cars. It is for-
bidden to lift people with this appliance.
5 4
restrictions on use:
Other uses of or changes to the hydraulic car jack, as mentioned before,
B
are not as intended and could lead to risks such as injuries and damage.
The manufacturer does not assume any liability for damage arising
from improper use.
The product is only intended for private and not for commercial use.
The following is / are forbidden:
- Operation under diffi cult conditions
- Operation that is subject to special provisions
- The handling of loads whose properties could lead to dangerous
situations
- Dangers that arise during dismantling
8 - Direct contact with food
- Operation on ocean-going vessels
GB
Technical information
If the required force exceeds 400 N, these forces must be diminished Q
by enlisting additional people.
Model: KH 3017
Note: Close the lowering valve after every use! Capacity: 3000 kg
Note: Always store the hydraulic car jack in a vertical position! This Minimum lifting height: Approx. 19.5 cm
prevents oil from leaking out. Maximum lifting height: Approx. 38 cm
Do not spill any oil. Operating force: 400 N
Tested in accordance with: EN1494:2000+A1
Q Description of parts
1 Saddle
2 Extension screw (for saddle)
Safety notes
3 Lever socket
4 Safety valve
5 Release valve
WArNINg!
6 Tube section with locating slot DANgEr! Follow the instructions below
7 Tube section with pin to avoid the threat of loss of life, injury, or damage to
8 Pumping lever the product etc.
J
A lways use axle stands and wheel chocks in addition to your hy-
Q Included items
draulic vehicle jack. Never work under a raised vehicle unless you
have taken additional safety precautions. This is intended to prevent
1 Hydraulic car jack the vehicle from rolling away, sliding off or overturning the jack.
J
2 Tube sections with locating slot U se the product on a solid, level surface only. Using the product
1 Tube section with locating pin on an unstable or uneven surface – such as a gravel surface –
1 Operating instructions may lead to the load slipping.
J
E nsure that you never exceed the allowable (rated) load capacity.
J
T he person operating the jack must observe the jack and the load
during all movements.
J
N ever work under the raised load if it has not been made secure
by suitable means.
GB
Using the jack
J D o not allow the hydraulic vehicle jack to be used by uninstructed Q
or inexperienced persons.
raising the vehicle
J B efore using the hydraulic vehicle jack take precautions to prevent Q
the vehicle from rolling away. Put the handbrake on, place the vehicle
in gear (with automatic gearboxes set to "P") and chock the wheels. Follow these steps:
J E ven with precautions in place always remain alert and make a j P lace one of the tube sections with a locating slot
visual check that the saddle is fi rmly seated against the vehicle release valve
1
jacking point. closes the release valve.
J j
C heck that no person or object is under the vehicle before you N ow assemble the three-part pumping lever
lower it. section
J j
L ower the vehicle slowly. P lace the hydraulic vehicle jack under one of the lifting positions as
J
C heck that all parts have been assembled and fi tted properly and shown in the owner's manual supplied by the vehicle manufacturer.
j
are undamaged. S crew out the extension screw
J
B efore each use check that the hydraulic vehicle jack is working dle comes into contact with the underside of the vehicle.
j
properly. Check the screws and valves of the hydraulic vehicle jack I nsert the pump piston lever
for correct seating and look out for hydraulic oil leaks in particular. Insert the notch of the pipe part into the anti-twist device of the lever
J
N ever use the hydraulic vehicle jack for moving or loading a vehicle. holder fi xture
Never use it to lift a whole vehicle completely off the ground. Now raise the car until the chassis stands can be placed beneath
J
Make sure that no-one – especially a child – is in the the car.
j
vehicle and that everyone is kept at an adequate distance A llow the vehicle to come down on to the axle stands by slowly
away from the vehicle when the hydraulic vehicle jack is opening the release valve
in use.
J
N ever change the setting of the safety valve 4 .
J Q Lowering the vehicle
M ake sure that no petrol, battery acid or any other dangerous
substance can fl ow out of the vehicle when the vehicle is being lifted.
object is under the vehicle before you lower it.
Follow these steps:
j
F irst raise the vehicle slightly in order to be able to remove the
axle stands.
GB GB
on to the
6
and turn it in the direction (see Fig. A). This
5
8 . Turn each tube
6 7 in the direction to fi x it in place.
2 in the direction until the sad-
8 into the lever holder fi xture 3 .
3 .
5 by turning it in the direction.
WArNINg! DANgEr TO LIFE! Check that no person or
