- Page 2 Trademarks All brand and product names are trademarks or registered trademarks of their respective companies. Note The information in this manual is subject to change without notice.
-
Page 3: Table Of Contents
Table of Contents Getting Started ................1 1.1 Understanding Hardware Components ..........1 Front Components ................1 Back Components ................2 Top Components ................2 Bottom Components ................3 1.2 Performing the Initial Start Up ............3 1.3 Charging the Battery via the USB Cable..........3 1.4 Using Your Device in a Vehicle ............ - Page 4 Limited warranty ................14 4.1 WARRANTOR ................. 14 4.2 WHAT THIS WARRANTY COVERS ..........14 4.3 WHAT THIS WARRANTY DOES NOT COVER ....... 14 4.4 HOW TO MAKE A WARRANTY CLAIM ........... 15 4.5 YOUR LEGAL RIGHTS ..............15 4.6 LIMITATION OF LIABILITY .............. 16...
-
Page 5: Getting Started
Getting Started 1.1 Understanding Hardware Components NOTE: Depending upon the specific model purchased, the colour of your device may not exactly match the device shown in this manual. Front Components Ref Component Description Touchscreen Displays the output of your device. Tap with the top of your finger on the screen to select menu commands or to enter information. -
Page 6: Back Components
Back Components Component Description Speaker Plays music, sounds and voice. SD Slot Accepts SD (Secure Digital) memory cards. Top Components Component Description Power Switch Turns on and off the device. -
Page 7: Bottom Components
Bottom Components Component Description Car Kit Connector Connects your device to the optional Car Kit. Reset Button Restarts your device (soft reset). Mini-USB Connects to the charger or USB cable. Connector 1.2 Performing the Initial Start Up 1. Make sure that power is supplied to your device. (See the next section.) 2. -
Page 8: Using Your Device In A Vehicle
The charge indicator glows amber when charging is in progress. Do not disconnect your device until the battery is fully charged, when the charge indicator turns green. This will take a couple of hours. CAUTION: For optimal performance of the lithium battery, take note of the following: •... -
Page 9: Connecting The Car Charger
Connecting the Car Charger The car charger supplies power to your device when you are using the device in the car. CAUTION: To protect your device against sudden surges in electrical power, connect the car charger only after the car engine has been started. 1. -
Page 10: Operating Basics
1.5 Operating Basics Turning On and Off Shift the power switch to “on” or “off” to turn your device on or off. When you switch off the device, it actually enters into a standby state and stops operating. Once you turn on the device again, it resumes. 1.6 Inserting an SD Card Your device has an SD slot where you can insert a Secure Digital or... -
Page 11: Troubleshooting And Maintenance
Troubleshooting and Maintenance Troubleshooting and Maintenance 2.1 Resetting Your System Occasionally, you may need to reset your device. For example, you should reset your system when it stops responding; or appears to be “frozen” or “locked up.” Insert a small pin, such as a straightened paperclip, into the reset button at the bottom of your device. -
Page 12: Screen Problems
Screen Problems The screen responds slowly Make sure that your device is not running out of energy. If the problem persists, reset your system. The screen freezes Reset your system. The screen is difficult to read Make sure that the backlight of the display is on. Move to a well lit location. - Page 13 Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time. Do not place anything on top of your device or drop objects on your device. Do not drop your device or expose it to severe shock. Do not subject your device to sudden and severe temperature changes.
-
Page 14: Regulatory Information
Regulatory Information NOTE: Marking labels located on the exterior of your device indicate the regulations that your model complies with. Please check the marking labels on your device and refer to the corresponding statements in this chapter. Some notices apply to specific models only. 3.1 Regulations Statements European Notice Products with the CE marking comply with Radio &... -
Page 15: Fcc Compliance
Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive EN 301 489-17 V1.2.1 2002-08: Electromagnetic compatibility and Radio spectrum Matters (ERM);ElectroMagnetic Compatibility (EMC) standard for radio equipment; Part 17: Specific conditions for 2,4 GHz wideband transmission systems,5 GHz high performance RLAN equipment and 5,8 GHz Broadband Data Transmitting Systems EN 55013: 2001+A1: 2003: Sound and television broadcast receivers and associated equipment —... -
Page 16: Safety Precautions
CANADIAN ICES-003 COMPLIANCE This Class B digital apparatus complies with Canadian ICES-003. NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in electronic equipment at home. -
Page 17: About Charging
About Charging Use only the charger supplied with your device. The use of another type will result in malfunction and/or danger. This product is intended to be supplied by a LISTED Power Unit marked with “LPS”, “Limited Power Source” and output rated + 5 V dc / 1.2 A”. -
Page 18: Limited Warranty
Non-U.S. and non-Canadian purchases: If you have made your purchase outside the United States and Canada, this Limited Warranty is granted by and this Limitation of Liability is stipulated for the benefit of ROUTE 66 Geographic Information Systems B.V., Leidekkerstraat 4A, NL-2984 AV Ridderkerk (The Netherlands). -
Page 19: How To Make A Warranty Claim
Hardware. 4.4 HOW TO MAKE A WARRANTY CLAIM 3) In order to make a claim of a Defect, you must contact ROUTE 66 by email during the Warranty Period via www.66.com to explain the Defect and to obtain an RMA number (Return Materials Authorization) if necessary. -
Page 20: Limitation Of Liability
8) This Limited Warranty cannot be transferred to any other person. 4.6 LIMITATION OF LIABILITY 9) Neither ROUTE 66 nor its suppliers shall be liable to you or to any third party for any damages either direct, indirect, incidental, consequential or...
