Sony Handycam HDR-GW77 Service Manual

HDR-GW55VE/GW77/GW77E/
SERVICE MANUAL
Ver. 1.1 2012.06
Revised-1
Replace the previously issued
SERVICE MANUAL 9-834-666-31
with this Manual.
Photo: HDR-GW77V/White
SERVICE NOTE (Check the following note before the service.)
– ENGLISH –
1-1. WATER-PROOF, DUST-PROOF, AND SHOCK-PROOF
1-2. SERVICING FLOW
1-3. WATER-PROOF INSPECTION TOOL
1-4. AIR-LEAK TEST
1-5. PERIODIC MAINTENANCE
1-6. PRECAUTION ON REPLACING THE VC-657 BOARD
1-7. ADDITION OF DESTINATION DATA FILE
1-8. PRECAUTION ON REPLACING THE CM-128 BOARD
1-9. PRECAUTION ON REPLACING THE LENS
1-10. SELF-DIAGNOSIS FUNCTION
1-11. METHOD OF COPING WITH SHIFT LENS ERROR
1-12. GPS RECEIVING CHECK (GW55VE/GW77V/GW77VE)
1-13. PRECAUTION ON REPLACING THE VC-657 BOARD (GW55VE/GW77V/GW77VE)
1-14. PRECAUTION ON REPLACING THE CABINET (BOTTOM)
1-15. PRECAUTION ON REPLACING THE CABINET (G)
‒ JAPANESE ‒
1-1. 防水/防塵・耐衝撃
1-2. 修理フロー
1-3. 防水検査冶具
1-4. エアリークテスト
1-5. 定期メンテナンス
1-6. VC-657基板交換時の注意
1-7. Destination Data ファイルの追加について
1-8. CM-128基板交換時の注意
1-9. レンズ交換時の注意
1-10. 自己診断機能
1-11. シフトレンズエラーの対処方法
1-12. GPS 受信確認 (GW55VE/GW77V/GW77VE)
1-13. VC-657基板交換時の注意 (GW55VE/GW77V/GW77VE)
1-14. キャビネット交換時の注意 (底）
1-15. キャビネット交換時の注意 (G）
The components identified by mark Les composants identifiés par une
0 or dotted line with mark 0 are marque 0 sont critiques pour la
critical for safety. sécurité.
Replace only with part number Ne les remplacer que par une
specified. pièce portant le numéro spécifié.
HDR-GW55VE/GW77/GW77E/GW77V/GW77VE_L2
9-834-666-32
GW77V/GW77VE
2
LEVEL
US Model
Canadian Model
AEP Model
UK Model
North European Model
E Model
Hong Kong Model
Korea Model
Japanese Model
Tourist Model
Digital HD Video Camera Recorder
Sony Corporation
Revision History
Ver. Date History
1.0 2012.05 Official Release
1.1 2012.06 Revised-1 • Correction of ACCESSORIES.
(A1 12-156) Page 2-8,
983466632.pdf
Contents
—
2-9
Published by Sony Techno Create Corporation
S.M. Rev.
issued
—
Yes
2012F08-1
© 2012.06
