Ss-Ct5/TS5/WS5/WT5
SERVICE MANUAL
Ver 1.1 2004.01
• SS-CT5/TS5/WS5/WT5 are the
speaker section in DAV-FC7 and
DAV-SC5.
• SS-WT5 is conposed of SS-CT5, SS-
TS5 and SS-WS5.
Sony Corporation
9-961-035-02
2004A16-1
Home Audio Company
© 2004.01
Published by Sony Engineering Corporation
SS-CT5
SPECIFICATIONS
Speakers
Front/Surround
Speaker system
Bass reflex
Speaker unit
70 mm (2
cone type
Rated impedance
4 ohms
128 × 216 × 114 mm
Dimensions (approx.)
(5
/
8
/
1
8
5
(w/h/d, with the stand)
Mass (approx.)
0.53 kg (1 lb 3 oz)
Centre
Speaker system
Bass reflex
Speaker unit
70 mm (2
cone type
Rated impedance
4 ohms
190 × 122 × 89 mm
Dimensions (approx.)
(7
/
4
/
1
2
7
(w/h/d, with the stand)
Mass (approx.)
0.56 kg (1 lb 4 oz)
Subwoofer
Speaker system
Bass reflex
Speaker unit
160 mm (6
cone type
Rated impedance
4 ohms
190 × 384 × 357 mm
Dimensions (approx.)
(7
/
15
1
2
inches) (w/h/d)
Mass (approx.)
7.67 kg (16 lb 15 oz)
Canadian Model
Australian Model
/
inches) dia.
7
8
4
/
inches)
8
1
2
/
inches) dia.
7
8
3
/
inches)
8
5
8
/
inches) dia.
3
8
/
14
/
1
1
8
8
SPEAKER SYSYTEM
