Front suspensión manual Toyota 1984 4*4

1 comments:
Mr. Anderson
May 14, 2025

The front suspension manual for a 1984 Toyota Hilux Surf 4WD includes information on the Independent Front Suspension (IFS) system with torsion bar springs. Key components include:

1. Upper and Lower Control Arms – Support wheel movement and hold the steering knuckle.
2. Torsion Bar – Acts as the spring, attached between the lower control arm and the vehicle frame.
3. Shock Absorbers – Mounted near the control arms to dampen suspension movement.
4. Steering Knuckle – Connects the control arms to the wheel hub and supports the front axle.
5. CV Joints and Axles – Allow power to be transmitted to the front wheels while steering and moving.

Adjustment procedures include:

- Torsion Bar Adjustment – Used to change ride height and preload.
- Wheel Alignment – Requires setting camber, caster, and toe.

Maintenance tips include checking for worn bushings, leaking shocks, and damaged CV boots. Torque specifications and testing procedures are listed in the service manual.
