SPLIT-TYPE AIR CONDITIONERS
OUTDOOR UNIT
SERVICE MANUAL
Models
MUH-GA50VB -
MUH-GA50VB -
MUH-GA60VB -
MUH-GA80VB -
NOTE:
This service manual describes technical data of outdoor units.
RoHS compliant products have <G> mark on the spec name plate.
For servicing of RoHS compliant products, refer to the RoHS Parts List.
E1
E2
E1
E1
CONTENTS
10. TROUBLESHOOTING······································25
MUH-GA50VB
11. DISASSEMBLY INSTRUCTIONS·····················36
12. PARTS LIST······················································40
13. RoHS PARTS LIST···········································46
Revision:C
• The fan guard for MUH-GA60VB-
MUH-GA80VB-
Please void OB368 REVISED EDITION-B.
HFC
utilized
R410A
Indoor unit service manual
MSH-GA•VB Series (OB367)
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················5
3. SPECIFICATION·················································6
4. NOISE CRITERIA CURVES ·······························8
5. OUTLINES AND DIMENSIONS ·························9
6. WIRING DIAGRAM ··········································10
7. REFRIGERANT SYSTEM DIAGRAM ··············12
8. PERFORMANCE CURVES ······························15
9. SERVICE FUNCTIONS ····································25
E1
has been changed.
E1
No. OB368
REVISED EDITION-C
and
