Dickinson Marine
www.dickinsonmarine.com
info@dickinsonmarine.com
CARIBBEAN / MEDITERRANEAN
Propane Galley Range
INSTALLATION – USE AND CARE MANUAL
This manual MUST be read carefully
DICKINSON RESERVES THE RIGHT TO CHANGE PRODUCTS OR DOCUMENTS AT ANY TIME
Doug & Don
Form#7.2-23 Issue#1
Sept. 14, 2011
QUALITY INSPECTED BY -
Advertisement
Related Manuals for Dickinson Mediterranean
Summary of Contents for Dickinson Mediterranean
- Page 1 CARIBBEAN / MEDITERRANEAN Propane Galley Range INSTALLATION – USE AND CARE MANUAL This manual MUST be read carefully DICKINSON RESERVES THE RIGHT TO CHANGE PRODUCTS OR DOCUMENTS AT ANY TIME Doug & Don Form#7.2-23 Issue#1 Sept. 14, 2011 QUALITY INSPECTED BY -...
-
Page 2: Table Of Contents
CONTENTS Warnings and Disclosures pg - 3 Stove Dimensions pg - 6 Product Features pg - 7 Burners and Valves pg - 09 Fuel Supply Instructions pg - 10 Fuel Locker Diagram pg - 11 Fuel System Testing pg - 12 Gimbaled Instructions pg - 13 Gimbaled Diagram... - Page 3 WARNING! THIS IS A LOW PRESSURE PROPANE GAS APPLIANCE. YOU MUST HAVE A SEPARATE 11” W/C (30 mbar)LOW PRESSURE REGULATOR INSTALLED CORRECTLY OR OPERATION WILL RESULT IN A DANGEROUS FIRE AND WILL DAMAGE YOUR UNIT. **PLEASE READ YOUR INSTRUCTION MANUAL BEFORE USE OF THIS APPLIANCE**...
- Page 4 • Shut off main supply tank, and call the fire department if the boat has filled with gas. IMPORTANT Safety is everyone’s responsibility. Your Dickinson product is designed and constructed to give you many years of safe use. The operation will be further enhanced if proper care and judgment are exercised in the use and maintenance of the appliance.
- Page 5 USE ONLY approved materials, hose, regulators and fittings to install. • 10ft Hose – ULC Type I CGA St 8.1 – Dickinson Prt# 19-100-10 20ft Hose – ULC Type I CGA St 8.1 – Dickinson Prt# 19-100-20 Propane Low Pressure Regulator UL/C.G.A – Dickinson Prt# 19-151 DO NOT store or use gasoline or other flammable vapors and liquids in the •...
- Page 6 Never leave the appliance unattended when in use. Do not use oversized pots or pans. See section on ‘burners’. Do not use abrasive or caustic cleaners or detergents on this appliance. Keep appliance area clear and free from combustible material. MEDITERRANEAN & CARIBBEAN DIMENSIONS...
-
Page 7: Product Features
* Tie Down Bar – This is the 1/8 aluminum piece that is appox. 10” long *see pic below. The tie down bar is to be fastened in your stoves cut out so that the bottom panel housing the battery boxes will slide into it thus preventing your stove from tilting forward as the boat lists. - Page 8 FLAME CLEARANCE AND POT SIZES Space is always at a premium on a boat and the Dickinson Propane Stoves give you the most versatility and the most powerful burners available in a marine cooktop format. For your safety and for good maintenance of the appliance, use the appropriate size pots for the right and left burners.
- Page 9 It is recommended that this appliance have a dedicated gas line and have a low-pressure regulator installed. (11” WC)(30mbar) (Dickinson Part No 19-151) Connect the gas line to the 3/8" flare connector of the cook top with copper or an approved hose. During...
- Page 10 BLOW OUT FUEL LINE PRIOR TO ATTACHING TO THE PROPANE SUPPLY AND THE APPLIANCE OR TAPE OVER THE FITTING WHEN INSTALLING THE FUEL LINE SO NO DEBRIS WILL ENTER. LPG System Installation **In some cases the solenoid valve is installed on the low pressure side of the system (i.e. after the LPG regulator) See solenoid manufactures’...
-
Page 11: Fuel System Testing
USE ONLY approved materials, hose, regulators and fittings to install. • 10ft Hose – ULC Type I CGA St 8.1 – Dickinson Prt# 19-100-10 20ft Hose – ULC Type I CGA St 8.1 – Dickinson Prt# 19-100-20 Propane Low Pressure Regulator UL/C.G.A – Dickinson Prt# 19-151 DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any •... - Page 12 Before installing your range, fill out the Warranty Registration Form that is printed on the last page of this manual and send it back to Dickinson Marine, within 10 days of purchase. Keep your model and serial numbers handy, as they will be required when ordering parts, or requesting assistance.
- Page 13 Locate the companion pieces to the gimbals and install the appliance. For safety, Dickinson gimbaled appliances are designed with a sliding bolt type lock. The sliding bolt should lock into an adjacent cabinet or bulkhead to prevent the appliance from swinging in rough weather.
- Page 14 Cut-Out Dimension Diagram Optional Gimbaled Installation The Gimbal kit is an option we offer, that allows your stove to swing freely, which keeps it level when you’re on a keel. (i.e sailboat) Note: The stove can be locked into place, and should be if you aren’t using the stove, and/or are expecting really rough weather.
- Page 15 Cut-Out Dimension Diagram Optional Built-In Look ( Trim Kit ) Bracket Installation See Kit Instructions Caribbean 2 Burner Model # 26-000 Mediterranean 3 Burner Model # 26-001...
- Page 16 OPERATING YOUR PROPANE STOVE It is recommended that every time the LPG tank valve is opened for use, the operator close the valve and watch that the gauge needle remains constant. If leaks occur, correct them. If leaks cannot be corrected, do not operate appliance. Always test light a top burner after operating the tank valve to dispose of air in the supply line.
- Page 17 15. You must shut off both the solenoid and the manual gas cylinder valves whenever your vessel is unattended or if there is an emergency. Dickinson recommends that you also shut the cylinder valves off whenever your propane stove is not in use.
-
Page 18: Oven Cooking
Oven Cooking Considerations – Aluminum Foil Do not cover an entire rack with foil or place foil directly under cookware. To catch spillovers, place a piece of foil a little larger than the pan, on the rack below the pan. DO NOT PLACE FOIL ON THE OVEN BOTTOM. - Page 19 PROLONGED LAY UP The Dickinson Propane Stove has been designed to have a long life, with every day use. However, if you leave your boat unattended for a long period of time, particularly in high heat and humid conditions, or long winter conditions, the high temperature lubricant in the gas control valves may settle, resulting in difficulty in turning the control valves and possibly seizure of the valve.
-
Page 20: Part Replacements
Install a new battery if necessary. If none of the spark plugs will spark after the battery is checked or replaced you may need to order a replacement spark ignition box from Dickinson. Check to see whether there is 3/32” (2mm) gap between the spark plug head (which should be clean) and the burner rim, and that all the wires are securely connected to the spark ignition box located midway down the backside of the stove. -
Page 21: Limited Warranty
If any part of your new product fails because of a manufacturing defect within the warranty period dickinson offers to replace said parts free of charge, provided, however, that such parts have not been improperly repaired, altered or tampered with or subjected to misuse, abuse or exposed to corrosive conditions. This warranty, however, is limited by certain exclusions, time limits and exceptions as listed below. -
Page 22: Warranty Form
Return to: SINCE 1932 SINCE 1932 SINCE 1932 SINCE 1932 #101-17728 66 Ave, Surrey, B.C. Canada V3S 7X1 WARRANTY FORM I have read and understand the Limited Warranty and the Instruction Manual and agree to the terms and conditions (please print) Date……………………………………………………………………………...
