RH-64
Service Manual 1600/1110 Level 1&2
PAGE 1 (
20)
Confidential
RH-70
SERVICE MANUAL
Service Level 1&2
Transceiver characteristics:
•
Band: Dual-band phone for GSM 900/1800MHz or
850/1900MHz (depends on Sales Area)
•
Display: High resolution color display with up to
65,536 colors (128 x 128 Pixels)
Inverted black and white display (Nokia 1110 Only)
•
Vibra Alert: Onboard Vibra motor
•
Connector: Easy Flash connector
Transceiver with BL-5c 900mAh Li-Ion battery pack
Talk time
Up to 5h
Environmental characteristics:
•
Lead-free soldered
Copyright © 2005 NOKIA Corporation. All rights reserved.
Approved 1.0
DJk/MGR
23.06.2005
Standby
Note
Depends on
Up to 18days
network
parameters
Advertisement
Table of Contents
Related Manuals for Nokia RH-70
Summarization of Contents
1. Introduction
Warnings and Cautions
Important safety warnings and cautions for handling the device and performing service.
3. Pathfinder for Workshop Staff
Nokia Online Resources and E-learning
Accessing online training and multimedia content for service technicians.
7. Service Tools
FLS-4S Flash Dongle and ACF-8 Power Supply
Dongle and flash device for POS use, including driver and user guide.
Internal Battery BL-5c
900mAh Li-Ion battery providing lightweight power for the phone.
Travel Charger ACP-12
Small and lightweight charger for fast phone battery charging.
Headset HS-7
Handsfree headset with remote control for answering calls.
XCS-1 Service Cable
Service cable to connect FLS-4S to SF-10.
SF-10 POS Flash Adapter
POS Flash Adapter for software updating, provides voltage and connections.
8. SW-Update
Flash Concept - Point of Sales
Procedure for software updates using Easy Flash or POS Flash Concepts.
9. Disassembly Instructions
Tools and Initial Preparation
Required tools and protecting the display before disassembly.
A-Cover and Keymat Removal
Unlocking and removing the A-Cover and Keymat for Nokia 1600/1110.
Screw Removal and LCD Shielding
Removing six screws and the LCD shielding assembly.
Acoustic Channel and LCD Module
Removing acoustic channel, protecting LCD, and removing LCD module.
Light Guide, Engine Module, and Antenna
Removing light guide, engine module, antenna IHF Assy, and easy flash connector.
Microphone Removal
Procedure for removing the microphone using a slotted screwdriver.
