Soft Values (Bytes 518-557)
Soft Values define the assignments for the 10 "Soft Row" parameters as follows:
Byte#
1,2
3,4
5,6
7,8
9,10
11,12
13,14
15,16
17,18
19,20
21,22
23,24
25,26
27,28
29,30
31,32
33,34
35,36
37,38
39,40
The effect/controller type is one of the following:
0 Pitch
1 Chorus
2 EQ
3 Mod
4 Reverb
5 Delay
6 Knob
7 LFO 1
8 LFO 2
9 Arpeggiator
10 ADR 1
11 ADR 2
12 Randomizer
13 AB Controller
14 Sample and Hold
15 Envelope 1 Generator
16 Envelope 2 Generator
0xFF unassigned
The parameter index is the parameter number for the defined effect or controller number that you want
to place in the Soft Values Edit. This number is an index into the parameters for the effect or controller
NOT the Parameter Type number. The Mix parameter for all effects, for instance, is parameter number
0. Level is ALWAYS parameter number 1. These indeces directly map to the last number of the control
address for each parameter.
Tempo (Bytes 558-561, "Rate" Parameter Type 0x010C)
Tempo is an unsigned word (16-bit value) that specifies the current system tempo in beats per minute
(BPM) when the program is loaded. Note that, internally, the system measures tempo down to the sample
level but it averages to the nearest BPM when the program is stored. The tempo range supported by the
system is 41-400 BPM.
Descriptions
effect/controller type #1
parameter index #1
effect/controller type #2
parameter index #2
effect/controller type #3
parameter index #3
effect/controller type #4
parameter index #4
effect/controller type #5
parameter index #5
effect/controller type #6
parameter index #6
effect/controller type #7
parameter index #7
effect/controller type #8
parameter index #8
effect/controller type #9
parameter index #9
effect/controller type #10
parameter index #10
MPX 1 MIDI Implementation Details
# Bytes Parameter Type#
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
1 0x0138
1 0x0139
35
