MPX 1 User Guide

Tremolo (M) and Tremolo (S)

In Tremolo (M), the left and right
inputs are mixed together, then a
local sinewave generator modu-
lates the volume.
In Tremolo (S) the left input is
modulated by a local sinewave gen-
erator before going to the left out-
put. The right input is modulated by
sin, cos, -sin, or -cos, depending
on the Phase parameter.
These are the smallest mono
and stereo effects with interpolated
output level controls. You can use
them (with the tremolo turned off)
to add smooth output level control
to a stereo effect that doesn't have
output level interpolation.
Vintage Trem Dyna Tremolo

Overdrive

Overdrive is a simple gain ef-
fect that produces non-linear dis-
tortion as the Drive control is
turned up. This effect is useful for
such things as simulating the
sound of distorted radios and tele-
visions, or adding some "edge" to
other effects, etc. While not in-
tended to be used as a full-blown
guitar amp simulator, combina-
tions of Overdrive and EQ or
Comb effects can produce some
very useful tone effects.
Car Radio Rock Organ
7-20
Tremolo (M)
Mix* 0-100%
Level* Off, -89 to +6dB
Rate 0-50Hz
1:24-24:1 cycles/beat
(Rate Units)
PW 0-100%
Depth* 0-100%
Phase 0°-270°
Mix 0-100%
Level* Off, -89 to +6dB
Drive 0-100
* = Interpolated; ( ) = Option of preceding parameter
Tremolo (S)
Dry/Wet ratio
Amount of effect in the processed signal
Tremolo rate or period ratio
Selects frequency or cycles/beat
Tremolo pulse width
Tremolo depth
In Tremolo (S), controls the phase difference between the
right and left tremolo
Dry/Wet ratio
Amount of effect in the processed signal
Distortion control
