- Page 1 ATA User Manual Please insert your installation CD now and then follow the on screen instructions iiNet ATA Telephone Adapter Setting up for ADSL and VoIP. For model F1PG200ENau F1PG200ENau...
-
Page 2: Table Of Contents
Table of Contents 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Product Overview . -
Page 3: Introduction
Introduction Thank you for purchasing the Phone Adapter . This User Manual provides instructions for installing and configuring the Phone Adapter . In minutes, you will be able to place phone calls to any location in the world using your standard phone equipment and your broadband Internet connection . -
Page 4: Product Overview
Product Overview Key Features Voice over Internet Phone Dialing This exciting, new technology allows you to place calls over your existing broadband Internet connection with the same quality and functionality as your standard telephone service . ® Compatible with both PCs and Mac Computers The Phone Adapter supports a variety of networking environments including Mac OS... - Page 5 Product Overview Built-In Dynamic Host Configuration Protocol (DHCP) Client Built-In Dynamic Host Configuration Protocol (DHCP) client on-board makes for the easiest possible connection to your router . The DHCP server in your router will assign IP addresses to your Phone Adapter automatically so there is no need for a complicated networking setup .
-
Page 6: Knowing Your Phone Adapter
Knowing your Phone Adapter Package Contents • Phone Adapter • RJ45 Ethernet Networking Cable • RJ Phone Cord • Power Supply • User Manual • Quick Installation Guide • Features Overview System Requirements • Broadband Internet service, such as cable or DSL •... -
Page 7: Product Specifications
Knowing your Phone Adapter Product Specifications Standards IEEE 802 .3u 0/00Base-Tx Fast Ethernet (WAN) Protocols Supported SIP, CSMA/CD, TCP/IP, UDP, DHCP (client) Voice Compression G .7, G .729 Management Browser-Based User Interface Ports 0/00Base-Tx auto-sensing RJ45 port, WAN 2 FXS voice ports (Line and 2) LEDs Network: Connection to router Voice: Line , Line 2... - Page 8 Knowing your Phone Adapter [a] Line 2 [b] Line 1 Connection to Router DC Power [c] Connection to Router Line 2 Line 1 5V/2.4A [d] Reset Reset [e] Power (a/b) Phone Ports These ports are for connection to your telephone handset . Use the RJ cable that was provided with the Phone Adapter to connect the telephone to these ports .
- Page 9 Knowing your Phone Adapter (e) Power Jack Connect the included 5VDC, 2 .4A power supply to this jack . LEDs When you apply power to the Phone Adapter or restart it, a short period of time elapses while the Phone Adapter starts up (about 30 seconds) .
-
Page 10: Connecting And Configuring Your Phone Adapter
Connecting and Configuring your Phone Adapter Router Requirements Your cable or DSL router must be equipped with an RJ45 Ethernet port . Many routers have both an RJ45 Ethernet port and a USB connection . If you have a router with both Ethernet and USB, and you are using the USB connection at this time, you will be instructed to use the RJ45 Ethernet port during the installation procedure . -
Page 11: Connecting Your Phone Adapter
Connecting and Configuring your Phone Adapter Connecting your Phone Adapter to a Gateway/Router Installing the Phone Adapter as a client to a router that already exists. Identify an available LAN port on your existing router or home gateway . Using the Ethernet cable that is included with your Phone Adapter, take one end of the cable and connect it to the available LAN port on your Router . -
Page 12: Troubleshooting
Troubleshooting Problem: • Phone Adapter is not working . • LEDs do not come on . Solution: If the LED indicators are not ON, the problem may be that the Phone Adapter is not connected properly . Verify that the Phone Adapter is plugged into a power source . Check to see that the cables are connected to the correct ports and that they are secure . - Page 13 Troubleshooting Problem: • The Phone Adapter cannot connect to the router . • The “connected” light does not come on . Solution: If your Phone Adapter appears to be powered but the “connected” light is not green, the problem may be that your router and Phone Adapter are not connected properly .
- Page 14 Troubleshooting Technical Support You can find technical support information at http://www .iinet .net .au or contact iiNet customer support on 3 22 58 .
-
Page 15: Information
FCC Statement DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin Corporation, of 50 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that the product, FPG200ENau to which this declaration relates, complies with Part 5 of the FCC Rules . - Page 16 • ETS 300 826 General EMC requirements for radio equipment . To determine the type of transmitter, check the identification label on your Belkin product . Products with the CE marking comply with the EMC Directive (89/336/EEC) and the Low Voltage Directive (72/23/EEC) issued by the Commission of the European Community .
- Page 17 Belkin Corporation Limited 2-Year Product Warranty Belkin Corporation warrants this product against defects in materials and workmanship for 2 years . If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it...
- Page 18 ATA Hardware Setup For Advanced trouble shooting, technical support and VoIP setup please call our dedicated Belkin ATA support hotline on: 1300 552 002 Open Monday - Friday 8am - 8pm EST VoIP Account Support/Settings If you have any questions that relate to your...
