Aironet 1000 series User Manual

Wireless access points for token ring
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
User's Guide
2000 and 1000 series
Wireless Access Points for
Token Ring
Products supported:
AP2000-T and AP1000-T
DOC-710-003849 Rev. A0
Aironet Wireless Communications, Inc. • 367 Ghent Road, Suite 300
P.O. Box 5292 • Fairlawn, Ohio 44334-0292

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000 series and is the answer not in the manual?

Questions and answers

Related Manuals for Aironet 1000 series

Summary of Contents for Aironet 1000 series

  • Page 1 User’s Guide 2000 and 1000 series Wireless Access Points for Token Ring Products supported: AP2000-T and AP1000-T DOC-710-003849 Rev. A0 Aironet Wireless Communications, Inc. • 367 Ghent Road, Suite 300 P.O. Box 5292 • Fairlawn, Ohio 44334-0292...
  • Page 2 Aironet. Information in this document is subject to change without notice. Aironet makes no representation or warranties with respect to the contents of this manual and specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose.

  • Page 3: Manufacturers Federal Communication Commission Declaration Of Conformity Statement

    User Warning The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency. Any changes or modification to said product not expressly approved by Aironet could void the user’s authority to operate this device.
  • Page 4 Department of Communications - Canada Canadian Compliance Statement This Class A Digital apparatus meets all the requirements of the Canadian Interference - Causing Equipment Regulations. Cet appareil numerique de la classe A respecte les exigences du Reglement sur le material broilleur du Canada. This device complies with RSS-210 of Industry of Canada.

  • Page 5: Declaration Of Conformity

    EN 55022 (A) EN 55011 (A) EN 50082-1 EN 60950 Manufacturer: Aironet Wireless Communications, Inc. 367 Ghent Road, Suite 300 Fairlawn Ohio, 44333 The undersigned hereby declares that the equipment specified above conforms to the directives and standards cited herein.

  • Page 6: Safety Information

    (RF) electromagnetic energy emitted by FCC regulated equip- ment. Aironet subscribes to the same safety standard for the use of its products. Proper operation of this radio according to the instructions in this manual will result in user exposure substantially below the FCC recommended limits.

  • Page 7: Table Of Contents

    Installing the Hardware ............4 Configuring the Access Point..........7 Console Port..............7 Telnet Session..............7 System Identifier (SID) ...........8 Bitrate/Frequency (2000 Series/2.4 GHz Models)..8 Channel (1000 Series/900MHz Models) ......9 Root Mode..............9 Verifying Registration .............9 Where to Go from Here ............10 Technical Support ............10 Shipping Address ............10...

  • Page 9: Before You Start

    The purpose of this User’s Guide is to allow you to install and configure your Access Point, so that an end node or another Access Point (acting as a Repeater) will be able to register to it. For detailed installation and configuration procedures, see the AP1000-T/AP2000-T Technical Reference Manual .

  • Page 10: Understanding The Radio Network

    Radio Node - A PC, notebook computer, etc. containing a Wireless LAN ISA, MCA card or PCMCIA Adapter. End Node - A Radio Node that is at the end of the RF Network Tree. Understanding the Radio Network Advanced Radio Local Area Network (ARLAN) is designed like an upside-down tree, with a Root Unit at the top and repeaters and Radio nodes branching down and out from the Root as shown in the figure below.
  • Page 11 Optional long range antennas are shown below; a range of 6 miles can be achieved with the 900MHz Yagi and 4 Miles with the 2.4GHz Yagi.

  • Page 12: Installing The Hardware

    Installing the Hardware With the unit powered off, attach the RP-TNC antenna to the antenna connector. Do not over-tighten when connecting, finger-tight is sufficient. Once connected, make sure the antenna is positioned vertically to achieve an omni-directional pattern. Attach the console port cable to the EIA-232-E port and the other end of the cable to the serial port on a terminal or a PC running a terminal emulation program.
  • Page 13 If using STP cabling: The Access Point supports STP (Shielded Twisted Pair) cabling. Once you have connected the Token Ring Cabling, you will have to go to the Configuration-Tokenring-Speed to set the ring speed, and Configuration-Tokenring-Active-On to allow the Access Point to enter the ring.
  • Page 14 Insert the small plug on the end of the AC/DC Power Pack Cord into the 12-18VDC port, then plug the AC/DC power pack into an electrical outlet. Power-on the Aironet Wireless Access Point by pushing the ON button. When power is initially applied to the Access Point, all three Indicators will flash yellow, red and then green, in sequence, to test the functionality of the Indicators.

  • Page 15: Configuring The Access Point

    Configuring the Access Point To configure the Access Point so that it will communicate with end nodes or Repeaters, you must first use the Console Port to set the following parameters - SID, Frequency or Datarate, Root Mode. If you choose to set an IP address, remote access to the unit is possible via Telnet or HTML browser.

  • Page 16: System Identifier (Sid)

    HEX number not exceeding 6 digits, or select random if you want the Access Point to pick the SID. Bitrate/Frequency (2000 Series/2.4 GHz Models) The bit rate and frequency must match those of other nodes on the RF network. The default bit rate is the highest available, and the default frequency is the center frequency.

  • Page 17: Channel (1000 Series/900Mhz Models)

    Channel (1000 Series/900MHz Models) The channel must match that of other nodes on the RF network. The default channel is the center frequency with the highest data rate. Since each channel is matched to a bit rate, changing the channel will also change the bit rate. Type Channel and then type the applicable channel from the choices shown.

  • Page 18: Where To Go From Here

    Please ask your Aironet representative for the AP1000-T/AP2000-T Technical Reference Manual . In the Technical Reference Manual, you can learn more details about your Aironet unit and ARLAN software. Use the instructions in this reference to view statistics and perform system diagnostics.
