USER'S MANUAL
Thank you very much for purchasing this product.
To ensure correct and safe usage with a full understanding of this product's performance, please be
sure to read through this manual completely and store it in a safe location.
Unauthorized copying or transferral, in whole or in part, of this manual is prohibited.
The contents of this operation manual and the specifications of this product are subject to change
without notice.
The operation manual and the product have been prepared and tested as much as possible. If you
find any misprint or error, please inform us.
Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which may
occur through use of this product, regardless of any failure to perform on the part of this product.
Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which may
occur with respect to any article made using this product.
Advertisement
Table of Contents
Related Manuals for Stika SV-12
Summarization of Contents
Read This First
Machine Functions
Overview of the cutting machine's capabilities and software integration.
To Ensure Safe Use
Essential safety guidelines, warnings, and precautions for operating the cutting machine.
Included Items
List and identification of all components provided with the cutting machine.
Important Notes on Handling and Use
Machine Handling and Movement
Key considerations for handling the precision device, including moving the machine safely.
Chapter 1: Setup Preparation
Part Names
Identification of the major components and parts of the STIKA cutting machine.
Installation Steps
Step-by-step instructions for site selection, removing packing materials, and connecting cables.
Chapter 2: Installing Software
Software Overview
Description of the software provided on the CD-ROM, including drivers and cutting applications.
Windows Software Installation
Detailed guide for installing drivers and software on Windows operating systems.
Macintosh Software Installation
Detailed guide for installing drivers and software on Macintosh operating systems.
Chapter 3: Performing Cutting
Before Cutting Preparation
Information on usable material types, sizes, and conditions to check before cutting.
Cutting Process
Detailed steps for loading material, creating cutting data, and executing the cutting job.
Applying Cut Material
Instructions on how to affix the cut material to a surface using application tape.
Chapter 4: Mastering the STIKA
Optimizing Cutting Quality
Methods to check and improve cutting precision by adjusting blade extension and material settings.
Correcting Material Angle
Procedure to adjust material alignment using the sheet adjustment lever for accurate cuts.
Creating Cutting Data
Guide to creating text and importing image files for cutting, and editing contour data.
Applying Large Materials
Techniques for applying large cut materials, focusing on preventing slippage and air bubbles.
Chapter 5: Maintenance
Routine Maintenance
Steps for cleaning the blade tip, blade holder, and the main unit to maintain performance.
Replacing Consumables
Instructions for replacing the blade and blade protector when they are worn or damaged.
Chapter 6: Appendix
Troubleshooting Guide
Solutions for common problems, errors, and installation issues with the STIKA machine and software.
Shaft Lubrication
Procedure for lubricating the cutting carriage guide shaft to ensure smooth operation and prevent noise.
Cutting Range Specifications
Technical details on the cutting width and length capabilities for different STIKA models.
Product Specifications
Comprehensive technical data including dimensions, weight, power, and environmental operating conditions.
