Main cpu ver. 0150 and edsp ver. 11.53

Advertisement

Quick Links

11/30/09
This procedure is used to update Main CPU Ver.
flash programming for the FT-2000/D Transceivers.
*If you already have software Ver. 11.53 it is not necessary to update the FT-2000/D EDSP again.
We recommend installing the Flash Programming Software on a PC computer with Windows 2000,
XP or Vista Operating System; and use the CT-119 programming cable or 8-pin mini-DIN PGM-SW
(P0091526) and serial cable RS-232C, DB9F to DB9F straight cable.
NOTE: There are many USB adapters available; however some may not function with this software.
We recommend using the latest USB adapter driver software when available.
The update software is available from our website at http://www.yaesu.com. The CT-119
programming cable is available from your authorized Vertex Standard dealer. You may also order
by email to Vertex Standard parts department, yaesuparts@vxstdusa.com.
If the CT-119 programming cable or is not available you will need a RS-232C, DB9F to DB9F
straight cable and 8pin mini-DIN PGM-SW (P0091526). If the DIN PGM-SW is not available you
will need to operate the internal program switch S3004. Please follow the instructions in
ADDENDUM: Page 7 and 9.
1. Down load the FT-2000 data file [FT-2000_PEP2000_11-30-09.zip] from the following website:
http://www.yaesu.com/indexVS.cfm?cmd=DisplayProducts&ProdCatID=102&encProdID=66EA
91711DFB68C03DED4AD35153E12C&DivisionID=65&isArchived=0
2. Save the FT-2000 data file [FT-2000_PEP2000_11-30-09.zip] to the desktop on your computer.
3. Unzip and Extract the contents of [FT-2000_PEP2000_11-30-09.zip] to the desktop of your
computer.
4. You will find the PEP2000_EDSP3 and PEP2000_MAIN folders on your desktop.
The programmers and software are now stored on your computer on the desktop. The files designated
in the last step above are ready to update your FT-2000/D Transceiver.
* The PEP_2000 MAIN folder includes the new software writer FWS003 V2.01. We recommend not using
the earlier version software and writer.
* The PEP_2000 EDSP folder includes a new software writer EDSP V3.01; it no longer requires the four
DLL files that were needed by V1.03. We recommend you use the V3.01 writer and remove V1.03 and the
four DLL files from you PC.
The software updates will work with all versions (AF, AS, EU, NA, OC, SA or all Countries) of the FT-2000 and FT-
2000D.
PEP2000
Install the data file to PC
0150
and EDSP Ver.
11.53
the

Advertisement

loading
Need help?

Need help?

Do you have a question about the FT-2000D - UPDATE V0150 AND V11.53 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yaesu FT-2000D - UPDATE V0150 AND V11.53

  • Page 1 NOTE: There are many USB adapters available; however some may not function with this software. We recommend using the latest USB adapter driver software when available. The update software is available from our website at http://www.yaesu.com. The CT-119 programming cable is available from your authorized Vertex Standard dealer. You may also order by email to Vertex Standard parts department, yaesuparts@vxstdusa.com.
  • Page 2 Ver. 0150 MAIN CPU implements improvements (also includes all previous updates): • The FH-2 [ ] keys are made to increment the frequency at 100kHz up or down. <- -> • CW carrier is corrected to change LSB ⇔ USB when the indication is changed on VFO B. •...
  • Page 3 Turn off the main power switch located on the back of the FT-2000 (or turn off the power supply for FT-2000D and wait a minute, until the capacitors discharge) and remove the AC power cord. Connect the CT-119 Cable’s DB9F connector to the serial port COM1 in the back of your computer.
  • Page 4 (12) Turn the radio off. The main CPU updating process is now complete. Follow the instructions below to update the EDSP. 8-pin mini-DIN PGM-SW 1. Turn the main REAR power switch OFF. 2. Connect a RS-232C straight cable to the CAT connector. EDSP 3.
  • Page 5 5. On your computer desk top open PEP2000_EDSP folder and find the EDSP-301 icon as shown below. Double-click the EDSP-301 icon, displayed on the Program Screen. 6. Click the Update button. You will see AH025_V1153 out file displayed. If you do not see AH025_V1153 (as in the screen below), then open the “Look in:”...
  • Page 6 Software version 11.53 1.50 We hope this new software will increase your enjoyment of your FT-2000/D. Thank you for choosing Yaesu radios. If you have any problems or questions please contact Vertex Standard, Amateur Tech Support. amateurtech@vxstdusa.com Best regards, Mikio Maruya, WA6F Executive Vice President Engineering &...
  • Page 7 ADDENDUM If the CT-119 programming cable or 8-pin mini-DIN PGM-SW (P0091526) is not available you will need a serial cable RS-232C, DB9F to DB9F straight cable. Please follow these instructions. *Don't forget to write down (or save to a CF Card) any personal menu settings you have changed from the default before you start.
  • Page 8 Now go to the desktop open PEP2000_MAIN folder and find the FSW003 icon as shown below. Double-click the FSW003 icon, displayed on the Program Screen. NOTE: I f you receive a “communications error” message on your screen, click on the Configure box and choose a different COM port from the drop down menu.
  • Page 9 Figure A left Remove the rear foot (near the CAT connector) expose the program switch access hole. Switch S3004 is visible through the hole. Move the switch to the on (rear) position. (Top of picture) This is just a screw hole for reference...
