ESP32-Cam
Table of contents
Specifications
8 MB
520KB SRAM + 4M PSRAM
Bluetooth 4.2 BR/EDR and BLE standards
802.11 b/g/n
UART, SPI, I2C, PWM
Max. 4GB
9
Default 115200 bps
JPEG (OV2640 support only), BMP,
GRAYSCALE
2412~2484 MHz
Onboard PCB antenna, gain 2dBi
802.11b: 17±2 dBm (@11Mbps)
802.11g: 14±2 dBm (@54Mbps)
802.11n: 13±2 dBm (@MCS7)
CCK, 1 Mbps: -90 dBm
CCK, 11 Mbps: -85 dBm
1
Advertisement
Related Manuals for Aideepen ESP32-Cam
Summary of Contents for Aideepen ESP32-Cam
- Page 1 ESP32-Cam Table of contents Specifications ....................................1 Pinout .........................................2 Instructions ....................................... 2 Specifications SPI Flash 8 MB 520KB SRAM + 4M PSRAM Bluetooth Bluetooth 4.2 BR/EDR and BLE standards Wi-Fi 802.11 b/g/n Support interface UART, SPI, I2C, PWM Support TF card Max.
- Page 2 6 Mbps (½ BPSK): -88 dBm 54 Mbps(¾ 6-QAM): -70 dBm MCS7(65 Mbps, 72.2 Mbps): -67 dBm Power Supply Range 5V / 3,3V Operating Temperature -20°C ~ 85°C Pinout Instructions In order to be able to program the ESP32 cam in the Arduino IDE you must Install support for the ESP32 platform.
- Page 3 Copy the following link: https://dl.espressif.com/dl/package_esp32_index.json...
- Page 4 Open the Arduino IDE again and go to: A new window will open, type esp32 in the search box and install the board named esp32 from Espressif Systems, as shown below: Now you can select 【AI-Thinker ESP32-CAM】...
- Page 5 In order to make the computer recognize ESP32 CAM, please make sure your computer has the CH340X driver installed before use.
