Solid brick wall, load-bearing wall, fired hollow brick wall, wood board wall
thickened insulation wall!
gypsum board walls and thin plywood walls...! .
1.For solid brick walls,
load-bearing walls, and fired
hollow brick walls, we are
equipped with 8mm wall fittings
2. If it is a wooden wall (the
thickness of the board needs to
be at least 15 mm), please use
spare screws.
Installation wall requirements
It is not recommended to install
15mm
AG-480R-1
