OfficeMate 91964 Assembly Instructions

A.
Figure
Steel rail shipped as folded in figure
TO FIT IN DRAWERS, SNAP BOTH RAILS:
a. Place the rail on a flat surface with an
indented snap line at the edge.
b. Hold rail down with one hand, and
clamp pliers on desired snap line.
c. Bend the pliers downward to snap off
any unwanted pieces.
1.
Slide rail into notch at
top end of unit.
Hanging Folder Frame Assembly Instructions
Stock # 91964, 91965, 91999
B.
Figure
A.
Before adjusting the length, measure the depth of the drawer inside.
2.
Tighten screw with screwdriver
or coin to secure rail.
To unfold, straighten out both ends as seen in figure
3.
Slide assembled rail into the remaining
end unit and tighten screw to secure.
Officemate, LLC | Edison, NJ 08837
B.
4.
Repeat steps three and
four for opposite side.
6/25/2024
