Naomi Home Venus Adjustable Drafting Stool
PART LIST
1 - Caster x 5
Star Chair Base x 1
2 -
3 - Gas Lift x 1
4 - Chair tray x 1
5 - Chair Seat x 1
6 - Chair Back Bar x1
7 - Chair Back x1
8 - Round Footrest x1
Hardware
A - Screw x 4
B - Screw x 2
C - Hand Wheel x 1
D - Back Support x 1
USE AND MAINTENANCE
1
E - Straight Pipe x 1
F - Allen Wrench x 1
3
3.Insert B Screw × 2 into the D into the 6 into the 5
and hand tighten.
5
5. Insert 5 into 3.
If you need help or have damaged or missing parts, contact customer service at
Use on level surfaces only
Because this product needs assembly, it is prone to working itself
loose from time to time depending on the use. Please take the time to
check that all connections are still tight and working properly
Only clean using a damp cloth and mild detergent, do not use bleach
or abrasive cleaners.
4
Assembly Instructions
1 Select 3 Gas Lift ×1, 2 Star Chair Base×1 and
.
1 Caster ×5,E Straight Pipe x 1 and 8
. Insert 3 into 8 into E into 2 and hand
Footrest x1
tighten. Insert 1 × 5 into the 2 and make sure the
Casters slide smoothly.
2
2.Insert A Screw × 4 into the hole of
the 4 into the 5.
4.Insert C Hand Wheel × 1
into the hole of the 4 into
the 5.Insert 7 into the 6.
Congratulations! Setup
of your new Naomi
Home Venus Adjustable
Drafting Stool is
Completed !
