IAG Performance IAG-BDY-F3038 Manual

I-line mud flap front and rear set for 2021+ ford bronco
Hide thumbs

Advertisement

Quick Links

Download this manual
IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC
Step 1/37
IAG-BDY-F3038 - IAG I-Line Mud Flap Front
and Rear Set for 2021+ Ford Bronco
Part# IAG-BDY-F3038
Congratulations on the purchase of your IAG I-Line Mud Flap Front and Rear Set, and
thank you for choosing IAG Performance. These instructions are intended for users
with basic mechanical skills. Professional installation is not required. The average
installation time is 45 minutes.
Video Instructions can be found here:
https://www.youtube.com/watch?v=is0sr7FebeM
IAG Performance
1/19

Advertisement

loading
Need help?

Need help?

Do you have a question about the IAG-BDY-F3038 and is the answer not in the manual?

Questions and answers

Related Manuals for IAG Performance IAG-BDY-F3038

Summary of Contents for IAG Performance IAG-BDY-F3038

  • Page 1 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 1/37 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco Part# IAG-BDY-F3038 Congratulations on the purchase of your IAG I-Line Mud Flap Front and Rear Set, and thank you for choosing IAG Performance.
  • Page 2 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 2/37 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco Part# IAG-BDY-F3038...
  • Page 3 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 4/37 Numbered annotations (13) Front Left Mudflap x 1 Front Right Mudflap Front Left Mounting Bracket x 1...
  • Page 4 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 6/37 Numbered annotations (1) Remove the four factory push pins using a Phillips head screwdriver. Step 7/37 Numbered annotations (1) Locate two of the included snap nuts.
  • Page 5 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 8/37 Numbered annotations (1) Slide the two snap nuts over the two upper holes where you removed the push pins.
  • Page 6 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 10/37 Numbered annotations (1) Install two of the included bolts and two washers to secure the bracket to the previously installed snap nuts using an M5 allen key.
  • Page 7 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 12/37 Numbered annotations (1) Locate the front left mud flap. Install included push pin through mudflap in inner most hole.
  • Page 8 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 14/37 Numbered annotations (1) Tighten both bolts with M5 allen key. Step 15/37 Numbered annotations (1) Reinstall fender flare by turning 5 factory clips until firmly engaged.
  • Page 9 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 16/37 Numbered annotations (1) Remove driver's side rear fender flare by turning 5 factory clips. Step 17/37...
  • Page 10 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 18/37 Numbered annotations (1) Remove factory push pin with Phillips head screw driver. Step 19/37 Numbered annotations (1) Remove factory bolt using 10MM socket or wrench.
  • Page 11 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 20/37 Numbered annotations (1) Locate included snap nut. Step 21/37 Numbered annotations (1) Pull fender liner out slightly. Slide snap nut over lower factory mounting hole.
  • Page 12 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 22/37 Numbered annotations (1) Locate the driver's side rear upper bracket. Install included bolt and washer through lower mounting hole into previously installed snap nut by hand.
  • Page 13 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 24/37 Numbered annotations (1) Tighten upper mounting bolt with 10MM socket or wrench. Step 25/37 Numbered annotations (1) Tighten lower mounting bolt with M5 allen key.
  • Page 14 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 26/37 Numbered annotations (1) Locate the rear driver's side lower mounting bracket and mounting bracket extension. Step 27/37...
  • Page 15 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 28/37 Numbered annotations (1) Remove two factory tow hook bolts using 18MM socket. Remove tow hook from vehicle.
  • Page 16 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 30/37 Numbered annotations (1) Place factory tow hook over bracket. Install both factory bolts through tow hook and bracket by hand.
  • Page 17 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 32/37 Numbered annotations (1) Clean rear bumper. Apply included anti-shock pad onto rear bumper after peeling backing paper off.
  • Page 18 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 34/37 Numbered annotations (1) Slide mud flap between lower mounting bracket and rear bumper. Step 35/37 Numbered annotations (1) Install included bolt and washer in upper mounting hole.
  • Page 19 IAG-BDY-F3038 - IAG I-Line Mud Flap Front and Rear Set for 2021+ Ford Bronco rev. | 46814 v1 [Published] 2022-11-11 19:04 UTC Step 36/37 Numbered annotations (1) Install two included bolts and washers through the lower mounting holes. Bolts should be installed from the rear of vehicle, through mudflap and into mounting bracket.

This manual is also suitable for:

Iag-bdy-f3037
