- Page 3 Step 1:Put Part C and Part F together and put the Part A in the middle Step 2:Use Nut③ and Srew② to connect two Part C(or Part F),and of them,then use Screw① to tighten them. tighten them.Then put one Part J on the bottom side of two attached Please note:Part C is not the same length as Part F! Part C(or Part F).Use Screw①...
- Page 4 Step 5:Insert Part G1 to the connection part of the two attached Part F. Then Insert Part G2(the shorter piece) to the connection part of the two attached Part C.Next insert Part E to Part L. Insert Part M to Part L.Please note:The Part E which is attched to G2 Step 6:Put the canopy fabric (Part P&Q) on the frame,extend it fully.
