Summary of Contents for ABCCANOPY CT03
- Page 1 ASSEMBLY AND OPERATING INSTRUCTIONS...
-
Page 2: Table Of Contents
About The Product Installation Ⅰ Ⅱ 1-1 Product Information 2-1 Before Assembly 1-2 Parts List 2-2 Safety Tips 2-3 Setting Up 2-4 Taking Down 2-5 Installation Instructions For Wheels 2-6 Instructions For The Awning Ⅲ Appendix 3-1 User's Manual 3-2 After-sales Service 3-3 Disclaimer 3-4 Custom Canopy 3-5 More Products... -
Page 3: Product Information
10ft （8ft） 10ft（8ft） 10ft（8ft） 10ft（8ft） Product Information 10ft （8ft） Product Name POP UP CANOPY 10ft（8ft） 15ft（12ft） 15ft（12ft） Color White Top Material Polyester Bracket Material Alloy Steel Specifications 10 ft x 10 ft / 8 ft x 8 ft 10ft 10 ft x 15 ft / 8 ft x 12 ft （8ft）... - Page 4 CT03 CT04 CT05 P3-1 Door wall P3-2 Side wall...
- Page 5 CT06 P3-1 Door wall P3-2 Side wall CT07 P3-1 Door wall P3-6 Church window CT08 P3-1 Door wall P3-2 Side wall P3-3 Awning...
- Page 6 CT10 P3-1 Door wall P3-2 Side wall CT11 P3-1 Door wall P3-2 Side wall CT30 CT34 P3-4 Mesh door P3-4 Mesh door P3-5 Mesh wall P3-5 Mesh wall...
-
Page 7: Parts List
PARTS LIST FRAME PART NUMBER Dome cap Joint bolt / nut / washer & bolt cap Lower peak pole bracket Peak pole outer Foot pad 2 Way outer leg bracket Outer leg w/ velcro Peak pole inner Inner leg 2 Way outer leg slider bracket Inner leg height adjuster 3 Way outer leg bracket Joint bolt / nut / washer... -
Page 8: Before Assembly
BEFORE ASSEMBLY 2 PERSON 10-20 MIN ASSEMBLY HAMMER SAFETY TIPS 1. Please read this manual thoroughly and carefully before assembling and using the item, follow all instructions and keep the manual for future reference. 2. Proper use of the item includes observing the safety instructions in this manual and the information on the proper use of the item outdoors and for private purposes. -
Page 9: Setting Up
SETTING UP Step 1 Remove frame from box and stand upright in the center of the desired setup location. Gently pull the outer legs until the frame is partially expanded. Step 2 Attach the canopy top to each frame corner with velcro straps. Place the Dome cap (Part A) into the pocket and pull the drawstring tight. - Page 10 SETTING UP Step 3 Lift the frame into position by expanding the truss bars until frame is fully expanded. Lift the slide bracket to the highest position. Attach the velcro straps on the truss bar. Tips: Please note that the red peak tensioner is used to adjust the issue of the top becoming loose after prolonged use. When hearing crack, it means it comes the top.New products do not require adjustment.
- Page 11 SETTING UP Step 5 Attach the side walls with velcro straps and zippers according to your own requests. Tips: This step is required for products with side walls. Step 6 Use sandbags,ropes and stakes for fixation. Tips:Filled the sandbags with sand, rock, gravel, snow, dirt or other contents.Use hammer to anchor the stakes if necessary.
-
Page 12: Taking Down
TAKING DOWN Step 1 Remove stakes,ropes and sand bags securing the canopy to the ground. Step 2 Carefully Unzipped the zippers and take down velcro straps on each side to remove the side walls. Tips: when taking this step, please don't put too much strengh to avoid tearing. - Page 13 TAKING DOWN Step 3 Position the legs to its lowest position by adjusting the slider bracket. Carefully pick down the velcro straps on the truss bar. Tips: When removing the top, the Velcro straps must be removed first! Failure to remove the velcro straps will cause the top and frame to wear out! Step 4 Slightly lift the frame and push slowly until about ½...
- Page 14 TAKING DOWN Step 5 Push the frame into fully closed. Step 6 Store the frame back in the roller bag.
-
Page 15: Installation Instructions For Wheels
SETTING UP INSTALLATION INSTRUCTIONS FOR WHEELS Step 1：Big wheel x2 Step 2：Attach the screw and Step 3：Turn the locking screw nut to the wheel, retaining out counterclockwise. Screw*2 Screw nut*2 2MM gap. NO GAP! Step 4：Tighten the nut Step 5：It is done. counterclockwise until it is no longer loose... -
Page 16: Instructions For The Awning
INSTRUCTIONS FOR THE AWNING (ONLY FOR CT08) Step 1：Connect the awning Step 2：Insert and pass the Step 3：Install the support pole pole together. awning fabric. on the tent frame. PART LIST Step 4：Finish the set up and enjoy canopy shade. -
Page 17: User's Manual
USER’S MANUAL It is recommended that you use the ropes and stakes to secure the canopy. This product is not intended to withstand periods of extreme/high wind or storm. Check the connection of the frame regularly to ensure that it is firm and stable. If the frame structures have water stains, please clean up with a soft cloth in time to prevent rust. -
Page 18: After-Sales Service
AFTER-SALES SERVICE About returns and refunds Items shipped from Amazon.com, including Amazon Warehouse, can be returned within 30 days of delivery. You can visit the Amazon’s Customer Service homepage to get help: https://www.amazon.com/returns Items shipped from our shop, also can be returned within 30 days of delivery. If the reason for return is a result of an error or a damage on product, we will provide a pre - paid shipping label. -
Page 19: Custom Canopy
CUSTOM CANOPY The Pop Up Canopies can be customized to fit your needs. Add a custom top , walls or banner to make a bold statement. We offer digital dye sublimation and silk screened printing and up to 100% full print coverage in vivid images and precision clarity without compromise. - Page 20 CUSTOM WORKS Pop Up Canopies Table Cover Teardrop Flag Side Walls...
-
Page 21: More Products
MORE PRODUCTS TA55 TB51 SK01 TD42... - Page 22 MORE PRODUCTS AJ01 CT07 AJ18 PD01...
- Page 23 MORE PRODUCTS UB02 UB03 UB04 UB09...
- Page 24 INSTANT CANOPY...
