JAKCOM R5 Manual

Smart ring
Hide thumbs Also See for R5:

Advertisement

Table of Contents

JAKCOM R5 Smart Ring
Please scan this below QR code
to watch the Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R5 and is the answer not in the manual?

Questions and answers

Related Manuals for JAKCOM R5

Summary of Contents for JAKCOM R5

  • Page 1 JAKCOM R5 Smart Ring Please scan this below QR code to watch the Instructions...

  • Page 2: Product Introduction

    Product introduction JAKCOM R5 is a multifunctional smart ring that can replace 6 proximity cards simultaneously, Interact with mobile phones to realize special functions of "Social Sharing", "Wireless USB Flash Disk", "Smart Home Trigger" and so on. Built-in 2 health energy stones to improve human EMFs, and has scratch-resistant, waterproof, dustproof hardware characteristics.

  • Page 3: Specification Parameters

    Specification Parameters Carrier Frequency 13.56MHZ 、125KHZ RF Distance 1~3cm IC Module Chip CUID x 2 Carrier Frequency of IC 13.56MHZ Module IC Module Feature Equivalent to two M1 (Mifare1) IC cards, with card number and encrypted sector repeatedly modifiable. ID Module Chip T5577 x 2 Carrier Frequency of ID 125KHZ...
  • Page 4 NFC Module Chip Ntag216 x 2 Carrier Frequency of NFC 13.56MHZ Module NFC Module Features Equivalent to two NFC smart cards which can interact with smart phones NFC Phones Applicable All Android phones with NFC function, as well as iPhone launched after September 2018, such as iPhone XR, XS, 11, 12, 13 and 14...
  • Page 5 Structure and Sensing Range A. The area engraved with "I" is No.1 IC card B. The area engraved with "II" is No.1 NFC card C. The area engraved with "III" is No.2 IC card D. The area engraved with "IIII" is No.2 NFC card...
  • Page 6 E. The white side area is No.1 ID card F. The black side area is No.2 ID card G. Health energy stone 1 H. Health energy stone 2 Reading method of IC and ID module The reading method of any IC or ID module is the same as an ordinary card, Close to the card reader according to the sensing range shown in the figure above.
  • Page 7 Sketch Map Use No. 1 IC card Use No. 2 IC card...
  • Page 8 Use No. 1 ID card Use No. 2 ID card Tip: The antenna of each module shall be close to the card reader, The closer the distance, the more sensitive the reader will be.
  • Page 9 If you want to replicate the original card directly into the ring, please use the "JAKCOM CDS Replicator". Scan the following QR code to view "JAKCOM CDS Replicator". The default passwords of ID modules are :...
  • Page 10 Settings of NFC module function 1. Open the Facebook APP; 2. Search "JAKCOM.com" and follow this Page;...
  • Page 11 3. Enter the JAKCOM.com Page; 4. Click the "Sign Up" button; https://nfc.jakcom.com lf you can't use Facebook You can also scan the QR code above to set it up.
  • Page 12 设备中心 5. Click the "Add Device" button; Add a device Select device 6. Input the activation code of back of the box; 设备中心 Add a device Select device Please enter the activation code Cancel Back of the box The activation code of No.1 NFC module: ***** The activation code of No.2 NFC module: *****...
  • Page 13 7. Click your device name in the list to enter function setting; 设备中心 Add a device Select device JAKCOM_R5_01 JAKCOM_R5_02 Different function services can be respectively set for these two NFC modules; After a new function is set for corresponding module, the old functions will be automatically closed.
  • Page 14 NFC function description Social Sharing: Quickly share your social account information to other phones; Personal Functions: Quickly start each personal functions by Ring’s NFC module; Wireless Disk: Quickly share your files to other phones.
  • Page 15 Startup of NFC module function 1. Before use, please enable the NFC function of the phone. If the phone is not equipped with the NFC function, it cannot be used; Sketch Map 13.20 13.20 More connections General Android iPhone Some versions of the iPhone doesn't have this switch, Enabled by default.
  • Page 16 2. Use the well set NFC module to touch the NFC sensing area of the phone, according to the sensing position shown above (B and D on Page 4); Example SAMSUNG iPhone Back iPhone Front HUAWEI iPhone's front can sense also a) The NFC sensing area is different for different brands of mobile phone.
  • Page 17 Sketch Map No.1 NFC card No.2 NFC card...
  • Page 18 3. After successful sensing, if it is prompted to select the app to open, please select the "web browser". 13.20 13.20 WEBSITE NFC TAG Browser Open "ins.JAKCOM.com" in Safari Facebook Always Once Android iPhone Third-party NFC application Any NFC module of the ring can be regarded as a standard NFC tag, and used in any third-party NFC application, such as "Pon Pon Tile of MIJIA", "...
  • Page 19 The default data can be reset in the following method; 1. Use an Android phone which has NFC function to download and install "NFC RESET" through the following link; http://www.jakcom.com/app/nfc/nfc_reset.apk For iPhone, please search "NFC-RESET" in the app store NFC RESET...

  • Page 20: Contact Details

    3. Move the NFC module of the ring which is to be reset, close to the NFC sensing area of the phone, and the reset can be finished within a few seconds. Contact details Website: http://www.JAKCOM.com Email: service@JAKCOM.com Service Phone: +86 400 806 7311...
