PayLessHere WS-6250 Assembly Instructions

6-TIER HEAVY-DUTY SHELVING
PACKAGE CONTENTS Attention:Please install it with 2 people !
A B
x 6 Shelf
x 48 +2 extra
F
G
x 4 x 4
Feet Leveler Pole Cap
(for stationary option) (used if making two 3-tier shelving units)
HARDWARE CONTENTS
x 2
x 2
AA
BB
Washer
Anchor
WS-6250
http://www.paylesshere.com
Warning:
Maximum weight capacity per shelf
is 1000lbs when equally distributed on
feet levelers.
Maximum entire unit weight capacity
is 600lbs when equally distributed on
casters.
Failure to follow these instructions may
result in serious injury or death of
yourself and people around you．
Some of the part are heavy and/or has
shape edge, please install it carefully to
avoid hurt you and people around you.
Caution:
Do not stand on or climb on the shelving unit.
Place heavier items on lower shelves
and lighter ones on top shelves.
C D
x 4 x 4
Top Pole Bottom
(with pole Pole(with
cap and threaded
pole connector insert
(2 locking, 2 non-locking)
preassembled) preassembled)
(for mobile option)
Threaded insert
(used if making two 3-tier shelving units)
x 2
CC
Black plastic spacer
(NOTE: Discard the black plastic spacers I.
Screw
These between each shelf are only for packing
purpose , not for assembling.)
ASSEMBLY INSTRUCTIONS
1. Stationary Option: Screw each
feet leveler (F) into the bottom of
each bottom pole (D). Turn clock-
wise to screw in place.
Mobile Option: Screw each wheel
(E) into the bottom of each bottom
pole (D). Turn clock-wise to screw
in place.
Attention: The wheel (E) must be
fully screwed to the botton pole
(D) by wrench
2. With the tapered end facing up,
snap the two halves of a tapered
lock (B) at the desired height on
bottom pole (D). Repeat for the
remaining bottom poles (D),
making sure the tapered locks (B)
are installed at the same grooved
line on each bottom pole (D).
Attention：The tapered must be fixed to the groove
on the pole, and make sure the tapered does not
slip before installing the shelf
3. Rest shelf (A) on its side, then
insert the bottom poles (D) through
the corner holes of the shelf (A).
E
x 4
Wheel
4. Turn assembly upright and push
tapered locks (B). Note: Make sure
the lip of shelf (A) is facing down
H
and the levelers (F) on bottom
x 4
5. Repeat steps 2-4 for the second
shelf (A).
I
x 20
6. Screw top pole (C) onto bottom
1
pole (D). Hand tighten.
D D
B
E
F
MOBILE STATIONARY
7-1 . Repeat steps 2-4 for the remaining
2
shelves (A).
D
D
Refer to image 7-1 for the
assembled unit of stationary option.
B B
7-2 . Repeat steps 2-4 for the remaining
shelves (A).
Refer to image 7-2 for the
3
assembled unit of mobile option.
D
A
D
D
D
8. OPTIONAL:Screw each threaded
insert (H) into the bottom of each top
4 pole (C). Repeat 1-4 to make a 3 –tier
shelving unit with wheel (E).
Insert each pole cap (G) into the top
of each bottom pole (D). Repeat 1-4
to make another 3 –tier shelving unit
with feet leveler (F).
9. OPTIONAL: Move unit to desired
5
location and mark spot through top
shelf wire on each side of unit. Drill
1/4 in. holes at each marked spot,
then insert plastic anchors (BB) into
holes. Insert screws (CC) through
the washers (AA) then through the
back of the top shelf wire and into
the plastic anchors (BB).
6
C
C
C
C
7-1
7-2
8
C
E
G
D
F
9
AA
BB
CC
XFC143C-N / XFC113B-N
