J.W. Speaker 6145 J Series Instruction Sheet

Regulatory Compliance
Pre-Installation Guidelines
1. Read all safety notes and mounting guidelines before installing
the product. Verify that all parts listed under "In the Box" are
present and complete.
2. Inspect the product for damage. DO NOT install the product if
there is any damage. Contact the authorized retailer where you
purchased it to initiate a warranty claim if there is damage.
3. Verify that all power supply and/or charging systems comply to
the specified voltage limits for the light.
J.W. Speaker Corporation • Germantown, WI U.S.A. • www.jwspeaker.com • speaker@jwspeaker.com • 262.251.6660
Rev: 05/27/2016
PRE-INSTALLATION INFORMATION
Estimated Time
Tools Needed
In the Box
Wire Functions
Input Voltage
Operating Voltage
INSTRUCTIONS BEGIN ON THE NEXT PAGE
Model 6145 J Series
LED Fog Light Instruction Sheet
60 minutes
#2 Phillips Screwdriver
Flat Blade Screwdriver
(x2) Model 6145 J Series Fog Lights
(x2) Plastic Housing Buckets
(x2) Wire Harnesses
C
B
A. (x2) Plastic Nuts
A
B. (x2) Adjustment Screws
C. (x2) Springs
For individual lights, one of each item listed
above is packed with the light.
Black = Ground
Red = Power
12V DC
10-15V DC
To properly install this light you should have a good
understanding of automotive electrical procedures and
systems, and proficiency in the installation of headlights.
IF YOU DO NOT, PLEASE SEEK PROFESSIONAL ASSISTANCE.
PRODUCT WARRANTY:
If you have issues with a J.W. Speaker
product, please contact the authorized
retailer where you purchased it.
Page 1
6544020c
