- Page 3 Step 1:Put two Part C together and put one Part A in Step 2:Use one Nut③ and Srew② to connect two Part C,and the middle of them,then use four Screw① to tighten tighten them.Then use two Screw① to tighten the Part J with two Part C and Part A.
- Page 4 Step 5:Insert Part G to the middle part of the two attached part C. Step 6:Put the canopy fabric (Part P&Q) on the frame, The other three Part G should be done as this. extend it fully. Then insert the other head of Part E to Part L.Finally,Insert Part M Put the heads of tubes(Part K) into the corner pocket of (the steel hook) to the hole of Part L and turn it to tighten it.
