Fulcrum LIGHT IT! 30050-308 Instructions

10-LED Anywhere Sensor Light:
INSTALLING THE BATTERIES
Remove the battery cover and install 3 AA batteries matching the polarity as shown in the
■
battery compartment.
AUTOMATIC OPERATION
Move the mode switch to the Auto mode to high (200 lumens) or low (100) lumens to
■
extend battery life.
The light will turn on whenever motion is detected (dim or dark settings only).
■
Light will automatically turn off after 30 seconds if no motion is detected.
■
MANUAL OPERATION
Move the mode switch to the manual position. Use the power switch to turn on the light.
■
Press #1 high (200 lumens)
■
Press #2 low (100 lumens)
■
Press #3 off
■
INSTALLATION
Mounting Light Only
a. Carefully measure and mark the location for 2 holes (9-3/16" on center).
b. Drill a 3/16" pilot hole.
c. Attach screws and slide the light into place.
d. Do not use double-sided tape
Mounting Corner Bracket with Screws
Recommended for textured or rough surfaces.
a. Place the corner bracket in the desired location and mark the holes.
b. Attach the screws and slide the corner bracket into place.
Mounting Corner Bracket with Double-Sided Tape
Option for smooth surfaces.
a. Peel paper off the tape and apply to the bracket.
b. Make certain that surfaces are smooth, clean and dry.
c. Peel paper off the tape and press firmly into place.
d. Please note that tape may damage delicate surfaces.
Mounting in Closets (Recommended)
Install the corner bracket on the inside trim above the closet door using either tape or
screws. This creates an ideal angle that will direct light on the clothing rod and/shelves.
Instructions
10-LED Anywhere Light – front
Sensor
10-LED Anywhere Light – back
place tape here
or here
Optional Angle Mounting Bracket – back
WARNING
Do not look directly into the light.
■
Do not shake or drop the light.
■
Do not expose the unit to static electricity.
■
Do not mix battery types (carbon, alkaline, lithium, or NiMH).
■
Please note: circuit requires 90-180 seconds to stabilize after the batteries are inserted.
■
Replace batteries when LEDs become dim.
■
Lamp
Lumens
Auto Shut Off
Sensor Range
Sensor Detection Angle
Battery Life – Sensor
Battery Life – Manual
Mounting Accessories Double-sided tape (4), screws (2), drywall anchors (2)
TWO YEAR LIMITED WARRANTY
For more information visit us at LightitLED.com or email us at info@LightitLED.com
Mode Switch
(manual or auto
operation)
Battery
Compartment
place tape here
or here
10 SMD bright white LEDs (6500K)
200 (high), 100 (low)
30 seconds
10 Feet
90 Degrees
High - 1000 activations, Low - 2000 activations
High - 9 hours, Low - 18 hours
