Fulcrum LIGHT IT! 20033-107 Instructions And Installation

Garden & Path Light
Features & General Information
The Garden & Path Light is a battery-operated outdoor light
that installs in minutes and is perfect for lighting paths,
porches, decks, sheds, garages, doors, fences...anywhere
you need light outdoors for added safety, security, or
convenience. The Garden & Path Light is completely
weather-proof and can safely be mounted outdoors without
special tools or the expense of hiring an electrician. It works
great indoors too!
The Garden & Path Light has a built-in motion sensor which
automatically turns on the light at night whenever a moving
heat source is detected. The light comes on for approximately
20 seconds and remains on as long as motion continues to
be detected in the area. The Garden & Path Light also has a
photo sensor which prevents the light from being activated
during the day or when the area is already illuminated by
another light source.
The six ultra-bright COB LEDs™ will last for more than
100,000 hours and will never need to be replaced. And unlike
conventional LEDs which light only a small surface, COB
LEDs cast an ultra-wide, glare-free beam to help light your
path or to provide convenient hands-free illumination in
those hard-to-see areas.
Instructions and Installation
Battery Installation
Slide the light off the wall mounting plate as shown in the picture below.
Slide open the battery door located on the back of the light in the direction indicated by the
arrow on the battery door. Remove the tape and screws and insert 4 AA alkaline batteries
according to the polarities shown inside the battery compartment. Replace the battery door and
slide it all the way closed.
Selecting a Location
The motion sensor's maximum detection distance is 10 feet and has a detection angle of 100˚.
The Garden & Path Light should not be installed near heaters, heat vents, or other heat sources.
Reflective surfaces (light colored walls, mirrors, etc.) may trigger the motion sensor resulting in
false activation. Also, be aware that pets can activate the motion sensor and that in some
locations external factors such as automobiles and pedestrians may also need to be considered.
Suggestion: Before installing the Garden & Path Light, load batteries and select the optimal
coverage area by trying different heights. We also suggest putting the light on a shelf or
